Technical specifications for 330104-00-05-10-01-00
-
Product Model330104-00-05-10-01-00
-
Product Parameters3300 XL 8 mm Probe, M10 x 1 thread,with armor
-
Tariff Code8537101190
-
Country of originUSA
-
Place of shipmentXiamen, China
-
In stock1 unit
-
Estimated Shipping Size20.5x22.2x3.7cm
-
ManufacturerBently Nevada
-
Weight0.18 kg
-
Unthreaded Length Option0 mm
-
Overall Case Length Option50 mm
-
Total Length Option1.0 meter (3.3 feet)
-
Connector and Cable-Type OptionMiniature coaxial ClickLocconnector with connectorprotector, standard cable
-
Agency Approval OptionNot required
Description
The Bently Nevada 330104-00-05-10-01-00 is an 8 mm proximity probe from the 3300 XL series. It features an M10 × 1 threaded stainless steel case with a 0 mm unthreaded section and a 0.5 inch (12.7 mm) overall case length. The probe carries a 1.0 meter integral triaxial cable with flexible stainless steel armor and an FEP outer jacket, terminated with a miniature coaxial ClickLoc® connector.
The probe tip is 8 mm in diameter and constructed from polyphenylene sulfide (PPS). The probe operates on an eddy-current principle, providing a non-contact measurement of shaft position and vibration in rotating machinery. When paired with a 3300 XL extension cable and Proximitor® sensor, the system delivers a linear output of 7.87 V/mm (200 mV/mil) across a 2.0 mm (80 mil) linear range.
The 330104-00-05-10-01-00 is rated for operating temperatures from −51°C to +177°C. The probe case is sealed with a Viton® O-ring to contain differential pressure between the tip and case. All 3300 XL 8 mm probes, extension cables, and Proximitor® sensors are fully interchangeable within the series and require no individual component matching or bench calibration.
The probe tip is 8 mm in diameter and constructed from polyphenylene sulfide (PPS). The probe operates on an eddy-current principle, providing a non-contact measurement of shaft position and vibration in rotating machinery. When paired with a 3300 XL extension cable and Proximitor® sensor, the system delivers a linear output of 7.87 V/mm (200 mV/mil) across a 2.0 mm (80 mil) linear range.
The 330104-00-05-10-01-00 is rated for operating temperatures from −51°C to +177°C. The probe case is sealed with a Viton® O-ring to contain differential pressure between the tip and case. All 3300 XL 8 mm probes, extension cables, and Proximitor® sensors are fully interchangeable within the series and require no individual component matching or bench calibration.
Alternative Names
330104-00-05-10-01-0O
330104-00-05-10-O1-00
330104-00-05-1O-01-00
330104-00-O5-10-01-00
3301O4-00-05-10-01-00
33O1O4-00-05-10-01-00
330I04-00-05-I0-0I-00
330104-00-05-10-01-05
330104-00-05-10-01-CN
330104-00-05-10-01-BR
330104-00-05-10-01-RU
Information
Overview
Manuals
Application Notes
Product Applications
Connecting the Components
Features:
- Advanced Performance & API 670 Compliance
- Complete Interchangeability
- Patented TipLoc & CableLoc Design
- Corrosion-Resistant Gold-Plated ClickLoc Connectors
- Armor Protection for Enhanced Mechanical Durability
As part of the 3300 XL Proximity Transducer System, the probe operates with a compatible 3300 XL extension cable and Proximitor® Sensor to deliver highly accurate vibration and displacement measurements. The 3300 XL system is fully interchangeable, eliminating the need for field matching or recalibration of individual components while meeting the performance requirements of API 670.
The 330104-00-05-10-01-00 Bently Nevada 3300 XL 8 mm Probe, M10 x 1 thread,with armor may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
Bently Nevada 330104-00-05-10-01-00 3300 XL 8 mm Probe, M10 x 1 thread,with armor Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The Bently Nevada 330104-00-05-10-01-00 is a 3300 XL 8 mm armored proximity probe with an M10 × 1 threaded stainless steel housing, 50 mm case length, and 1.0 m integral armored cable. Designed for use with 3300 XL Proximitor® Sensors and extension cables, it provides high-accuracy, non-contact shaft vibration and position measurements for critical rotating machinery while supporting API 670-compliant monitoring systems.
- Fluid-Film Bearing Machines: Monitors shaft vibration and axial displacement in high-speed critical assets
- Steam/Water Turbines: Safeguards main shafts from failure due to excessive movement or imbalance
- Centrifugal/Reciprocating Compressors: Tracks radial vibration and thrust position under volatile pressure
- High-Power Pumps/Fans: Mitigates downtime by identifying misalignments and mechanical looseness
- Large Generators/Motors: Performs health diagnostics on massive power-generation rotors
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
The extension cable connects the tip of the Eddy Current Proximity Probe to the Proximitor Sensor.
ClickLoc™ Connectors: Align the keyed connectors and push together. They only require finger-tight torque until you hear or feel a "click".
No Tools Required: The specialized locking mechanism secures the connection and prevents loosening without the use of pliers or wrenches.
Technical notes
Typical applications include vibration monitoring, axial position measurement, and phase reference (Keyphasor®) measurement on turbines, compressors, motors, pumps, and other fluid-film bearing machinery. The probe is installed through an M10 × 1 threaded mounting hole and secured with a locknut. The recommended case torque is 11.2 N·m (100 in·lbf). The ClickLoc® connector ensures a secure, repeatable coaxial connection to the extension cable. The stainless steel armor provides mechanical protection for the cable in harsh industrial environments.
FAQs
-
What is the function of the extension cable?
+It bridges the physical gap between the proximity probe and the Proximitor sensor. By maintaining the total system length (typically 5 meters or 9 meters), it ensures accurate signal calibration, providing a voltage output proportional to the gap between the probe tip and the machine shaft. -
Can I use this with any Bently Nevada system?
+It is specifically designed for the 3300 XL Proximity System. It is not directly backward-compatible with older, legacy 3300 (non-XL) systems without recalibrating the Proximitor sensor. -
What is the maximum distance allowed in a Bently Nevada proximity system?
+The 3300 XL system is designed for a total electrical length of either 5 meters or 9 meters. For a 5-meter system, you would use a 1.0m probe + 4.0m extension cable, or a 0.5m probe + 4.5m extension cable (this exact model). -
Does it provide physical protection against harsh environments?
+Yes. The 01 option in the part number means the cable is wrapped in stainless steel armor, making it robust against physical abuse, high-vibration zones, and harsh industrial spaces.
