- 3300 XL 8mm Proximity Transducer
- 330104-00-05-90-02-05
In Stock
· Product image is representative; revision or series may vary. Contact us to request a specific version.
We provide 1 year warranty for all remaining parts.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online.
If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.
Amikon offers a wide range of components, products and services related to industrial automation. We have a large surplus of stocks and are also distributors of new products from a variety of quality manufacturers.
Technical specifications for 330104-00-05-90-02-05
-
Product Model330104-00-05-90-02-05
-
Product ParametersX3300 XL 8 mm Proximity Probes
-
Tariff Code8537101190
-
Country of originUSA
-
Place of shipmentXiamen, China
-
In stock1 unit
-
Estimated Shipping Size28x28x4cm
-
ManufacturerBently Nevada
-
Weight0.95 kg
-
Unthreaded Length Option0 mm
-
Overall Case Length Option50 mm
-
Total Length Option9.0 meters (29.5 feet)
-
Connector and Cable-Type OptionMiniature coaxial ClickLocconnector standard cable
-
Agency Approval OptionCSA, ATEX, IECEx Approvals
Description
The BENTLY NEVADA 330104-00-05-90-02-05 3300 XL 8 mm Proximity Probe is an industrial non-contact displacement sensor used for monitoring the position and movement of conductive machine components, particularly rotating shafts. It forms part of the Bently Nevada 3300 XL 8 mm Proximity Transducer System, which consists of a compatible 3300 XL 8 mm probe, extension cable, and Proximitor Sensor. The system can measure both static shaft position and dynamic vibration signals.
This probe features an M10 × 1 metric threaded body and a standard mounting configuration. The 00 option specifies a 0 mm unthreaded length, while the 05 option specifies a 50 mm overall case length. The 90 option specifies a 9.0 m / 29.5 ft total probe length, making this configuration suitable for installations requiring a long-distance connection between the probe and the associated monitoring electronics.
The 3300 XL 8 mm system delivers the most advancedperformance in our eddy current proximity transducersystems. The standard 3300 XL 8 mm 5-meter system alsofully complies with the American Petroleum Institute’s (API)670 Standard for mechanical configuration, linear range,accuracy, and temperature stability. All 3300 XL 8 mmproximity transducer systems provide this level ofperformance and support complete interchangeability ofprobes, extension cables, and Proximitor sensors, eliminatingthe need to match or bench calibrate individual components.
This probe features an M10 × 1 metric threaded body and a standard mounting configuration. The 00 option specifies a 0 mm unthreaded length, while the 05 option specifies a 50 mm overall case length. The 90 option specifies a 9.0 m / 29.5 ft total probe length, making this configuration suitable for installations requiring a long-distance connection between the probe and the associated monitoring electronics.
The 3300 XL 8 mm system delivers the most advancedperformance in our eddy current proximity transducersystems. The standard 3300 XL 8 mm 5-meter system alsofully complies with the American Petroleum Institute’s (API)670 Standard for mechanical configuration, linear range,accuracy, and temperature stability. All 3300 XL 8 mmproximity transducer systems provide this level ofperformance and support complete interchangeability ofprobes, extension cables, and Proximitor sensors, eliminatingthe need to match or bench calibrate individual components.
Information
Overview
Manuals
Application Notes
Product Applications
Critical Installation Constraints
Features:
- Armored and Unarmored Options
- Multiple Connector Options
- Complete Interchangeability of Units and Cabling
The 330104-00-05-90-02-05 Bently Nevada 3300 XL 8 mm Proximity Probes may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
Bently Nevada 330104-00-05-90-02-05 3300 XL 8 mm Proximity Probes Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The 3300 XL probe and extension cable alsoreflect improvements over previous designs. Apatented TipLoc molding method provides amore robust bond between the probe tip andthe probe body. The probe’s cable incorporatesa patented CableLoc design that provides 330N (75 lbf) pull strength to more securely attachthe probe cable and probe tip.You can also order 3300 XL 8 mm probes andextension cables with an optional FluidLoccable option. This option prevents oil and otherliquids from leaking out of the machine throughthe cable’s interior.
- Axial (Thrust) Position:Measures shaft axis movement to prevent internal contact
- Radial Vibration and Position:Monitors side-to-side shaft movement within bearings
- Differential Expansion:Measures rotor-casing growth difference for steam turbines
- Rod Drop/Position:Monitors reciprocating compressors for rider band wear
- Speed and Phase Reference:Keyphasor sensor for tacho & zero-speed
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Target Material: The standard system is calibrated for AISI 4140 steel. Using other materials will require recalibration or will change the scale factor.
Clearance & Cross-talk: To avoid interference (cross-talk) between two probes, maintain a minimum tip separation of 40 mm (1.6 in) for axial measurements or 38 mm (1.5 in) for radial vibration.
Grounding: Establish a single-point grounding strategy, typically at the monitor panel, to prevent ground loops that cause erratic readings.
Alternative Names
330104-00-05-90-02-O5
330104-00-05-90-0Z-05
330104-00-05-90-O2-05
330104-00-05-9O-02-05
330104-00-O5-90-02-05
330104-OO-05-90-02-05
3301O4-00-05-90-02-05
330I04-00-05-90-02-05
33O104-00-05-90-02-05
330104 00 05 90 02 05
330104 00 05 90 02 O5
330104 00 05 90 0Z 05
330104 00 05 90 O2 05
330104 00 05 9O 02 05
330104 00 O5 90 02 05
330104 OO 05 90 02 05
3301O4 00 05 90 02 05
330I04 00 05 90 02 05
33O104 00 05 90 02 05
330104-00-05-90-02-00
330104-00-05-90-02-CN
Technical notes
The 330104-00-05-90-02-05 carries CSA, ATEX, and IECEx agency approvals (option -05), making it suitable for use in hazardous area environments. The 330104-00-05-90-02-05 operates within a temperature range of -52°C to +177°C (-62°F to +350°F) for standard applications, and is fully interchangeable with other 3300 XL 8 mm system components, eliminating the need to match or bench calibrate individual components.
FAQs
-
What is 330104-00-05-90-02-05?
+The Bently Nevada 330104-00-05-90-02-05 is a specific configuration of the 3300 XL 8 mm Proximity Probe, used for vibration and position monitoring in industrial machinery. -
What is the nominal resistance of this probe?
+The nominal probe DC resistance is 9.87 Ω ± 0.50 Ω. -
What is the sensitivity of the 3300 XL 8mm system?
+The system provides a standard sensitivity of 7.87 V/mm (200 mV/mil). -
What is the application of this probe?
+It is used for measuring static (position) and dynamic (vibration) values on rotating machinery, such as radial vibration and axial position, using eddy current technology.
