330930-065-05-05
Need Help? Contact US!
Call us: +86-18020776786
Proper, Ready.
Delivery time
Please indicate your delivery time
Product Information
Product Describe
065 6.5 meters (21.3 feet)
05With stainless steel armor
without FEP jacket
withconnector protector
05 Multiple Approvals
05With stainless steel armor
without FEP jacket
withconnector protector
05 Multiple Approvals
Technical specifications for 330930-065-05-05
-
Product Model330930-065-05-05
-
Product Parameters3300 NSv Extension Cable
-
Tariff Code8537101190
-
Country of originUSA
-
Place of shipmentXiamen, China
-
Estimated Shipping Size27x27x2cm
-
ManufacturerBently Nevada
-
Weight0.55 kg
-
Cable Length Option6.5 meters (21.3 feet)
-
Connector and Cable OptionWith stainless steel armor without FEP jacket withconnector protector
-
Agency Approval OptionMultiple Approvals
-
Output resistance50 Ω
-
Extension cable capacitance69.9 pF/m (21.3 pF/ft)typical
-
Factory New
These are new and current items that are procured from the manufacturer. -
New No Package
These parts are new. They have not been used, but their original packaging is no longer available. -
New In Opened Package
These parts are new. They have not been used, but their original packaging has been opened or the packaging is significantly aged. -
New In Sealed Package
Parts are new. They have not been used and still have their original package seal intact. -
New in Original Package
These parts are new. The packages were not originally sealed by their original manufacturer.
Warranty Period & Disclaimer
Amikon is not an authorized distributor unless otherwise specified, representative, or affiliate of the manufacturer of this product. All trademarks and documents are the property of their respective owners and are provided for identification and informational.
FAQs
-
What is the function of this cable 330930-065-05-05?+It is used to connect a 3300 NSv probe and a 3300 XL NSv proximity sensor.
-
What is the primary application for this cable?+It is for the 3300 XL NSv system, which is ideal for centrifugal air compressors, refrigeration compressors, and machines with tight installation requirements where standard 5mm or 8mm probes cannot fit.
-
What is the Bently Nevada 330930-065-05-05?+It is a 3300 NSv Extension Cable used specifically with the 3300 XL NSv proximity probe and Proximitor sensor system
-
Are these cables compatible with older systems?+Yes, the 330930 NSv extension cables are mechanically and electrically compatible and interchangeable with the previous 3300 RAM proximity probe and extension cable systems.
Get a quick price fo 330930-065-05-05
whatsapp
Inquiry
Our customer support team is always on call to help you with any form of consultation. You can inquire by phone or use us on the product page and "contact us" View Amikon terms and conditions
Product
MORE INFORMATION
Overview
Manuals
Technical notes
Product Applications
System Calibration & Verification
Features:
- For use in Tight Installation Requirements
- Replaces 3300 RAM Transducer Systems and 3000-Series or 7000-Series 190 Transducer System
- Average Scale Factor of 7.87 V/mm (200 mV/mil)
The 3300 XL NSv Transducer System has an Average Scale Factor of 7.87 V/mm (200 mV/mil), which is the most common output for eddy current transducers. Its enhanced side-view and small target characteristics give it a shorter linear range than the 3300 XL-series 5 and 8 mm Transducer System. With The 1.5 mm (60 mils) of linear range exceeds the linear range of the 3000-series 190 Transducer System.
The 330930-065-05-05 Bently Nevada 3300 XL NSv Proximity Extension Cable may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
Bently Nevada 330930-065-05-05 3300 XL NSv Proximity Extension Cable Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The 3300 XL NSv Proximitor Sensor has similarfeatures to those found in the 3300 XL 8 mmProximitor Sensor. Its thin design allows the userto mount it in either a high-density DIN-railinstallation or a more traditional panel mountconfiguration. Improved RFI/EMI immunityallows the 3300 XL NSv Proximitor Sensor toachieve European CE mark approvals withoutany special mounting considerations. This RFIimmunity also prevents nearby high frequencyradio signals from adversely affecting thetransducer system. SpringLoc terminal strips onthe Proximitor Sensor require no specialinstallation tools and facilitate faster, highlyrobust field wiring connections.
- Power Generation Plants:Monitors cooling tower fans in fossil/hydro plants
- Petrochemical & Refining Facilities:Critical for fin-fans; hazardous area approved (-04)
- Chemical Manufacturing:Monitors agitators, mixers & slow-speed reactor cooling
- Steel & Metal Smelters:Large ventilation/cooling fans managing extreme temps
- Pulp & Paper Mills:Slow-speed fans & high-humidity wastewater aerators
- Food & Beverage Processing:Large-scale refrigeration for temperature-controlled lines
- Mining & Mineral Processing:Ventilation fans in mines & cooling for processing machinery
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Linear Range: The 3300 XL NSv system typically has a linear range of 1.5 mm (60 mils).
Gap Setting: For radial vibration, a common recommended gap setting is approximately -9 Vdc.
Target Material: By default, these systems are calibrated for AISI 4140 steel targets. Using other materials may require recalibration or a change in scale factor.
