- Bently Nevada
- 7200 Proximity Transducer Systems
- 21504-00-08-10-02
In Stock
Ships by Tuesday, July 28
Fast Shipping Available
We provide 1 year warranty for all remaining parts.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online.
If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.
Amikon offers a wide range of components, products and services related to industrial automation. We have a large surplus of stocks and are also distributors of new products from a variety of quality manufacturers.
Technical specifications for 21504-00-08-10-02
-
Product Model21504-00-08-10-02
-
Product Parameters5mm and 8mm Standard Mount Probe
-
Tariff Code8537101190
-
Country of originUSA
-
Place of shipmentXiamen, China
-
In stock1 unit
-
Estimated Shipping Size8cm x 6cm x 5cm
-
ManufacturerBently Nevada
-
Weight0.4 kg
-
Unthreaded Length Option0.0 inches
-
Overall case length option0.8 inches
-
Total length option1 metre
-
Connector optionWith miniature male coaxial connector
-
Diameter8mm
-
Input power-17.5 Vdc to -26 Vdc
Description
The Bently Nevada 21504-00-08-10-02 5mm and 8mm Standard Mount Probe is an eddy current proximity probe for the 7200 Proximity Transducer System. The Bently Nevada 21504-00-08-10-02 provides non-contact measurement of shaft displacement, vibration, and relative position in rotating machinery applications. The probe uses an 8 mm sensing tip diameter and a standard mounting configuration with a 3/8-24 UNF thread, allowing installation in a wide range of industrial machinery monitoring systems.
The Bently Nevada 21504-00-08-10-02 is configured with an unthreaded length option of 00, an overall case length of 0.8 inch, and a total probe length of 1.0 metre (39 inches). The Bently Nevada 21504-00-08-10-02 includes a miniature male coaxial connector, providing a direct connection interface for compatible proximity monitoring equipment. The 1.0 m cable length allows flexible installation between the probe location and the monitoring system interface.
The Bently Nevada 21504-00-08-10-02 is configured with an unthreaded length option of 00, an overall case length of 0.8 inch, and a total probe length of 1.0 metre (39 inches). The Bently Nevada 21504-00-08-10-02 includes a miniature male coaxial connector, providing a direct connection interface for compatible proximity monitoring equipment. The 1.0 m cable length allows flexible installation between the probe location and the monitoring system interface.
Information
Overview
Manuals
Application Notes
Product Applications
Gap Adjustment
Features:
- Non-Contacting Gap-to-Voltage Eddy Current Measurement
- 80 mils (2.0 mm) Linear Measuring Range
- 8 mm Tip Diameter with 3/8-24 UNF Mounting Thread
- Wide Frequency Response (0 to 10 kHz)
- PPS (Polyphenylene Sulfide) Probe Tip Construction
21504-00-08-10-02 operates on the eddy current principle, where high-frequency electromagnetic energy from the probe tip induces eddy currents in the conductive target surface. The loss of signal strength in the return path is detected and conditioned by the associated Proximitor sensor, producing a linear DC voltage output. This non-contacting measurement method of 21504 eliminates mechanical wear and provides accurate static (position) and dynamic (vibration) measurements for shaft position, radial vibration, and axial displacement monitoring on rotating and reciprocating machinery.
The 21504-00-08-10-02 Bently Nevada 5mm and 8mm Standard Mount Probe may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
Bently Nevada 21504-00-08-10-02 5mm and 8mm Standard Mount Probe Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
21504-00-08-10-02 features an 8 mm nominal tip diameter with a 3/8-24 UNF-2A threaded body for standard mount applications. The overall case length of 21504-00-08-10-02 is 0.8 inches (20 mm), with an unthreaded length of 0.0 inches. The total cable length of 21504-00-08-10-02 is 1.0 meter (3.3 feet) with a tolerance of +0.25 meter / -0.10 meter. The probe includes a miniature male coaxial connector for connection to the extension cable or Proximitor sensor. No lead armor is included with this configuration of 21504.
- Oil/Gas/Petrochemical: Monitors critical machinery processing volatile hydrocarbons in hazardous explosive zones
- Power Generation: Tracks turbine/generator shaft movements in thermal, nuclear, and hydro plants
- Chemical Processing: Resists corrosive vapors with PPS thermoplastic housing
- Water/Wastewater: Operates reliably in moisture/humidity/outdoor spaces with IP66 washdown protection
- Mining/Heavy: Withstands dust, abrasive particles, and extreme mechanical vibration
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Target Distance: The linear range of the 7200 8mm probe typically centers around a specific voltage output.
Voltage Check: Connect a digital multimeter to the COM and OUT terminals of the Proximitor (which requires -18 Vdc to -24 Vdc input).
Setting the Gap: Thread the probe in until it touches the shaft, then back it out to achieve a static gap voltage of -10 Vdc ± 0.2 Vdc (or about 2.54 mm / 100 mils distance from the target).
Alternative Names
21504-00-08-10-0Z
21504-00-08-10-O2
21504-00-08-1O-02
21504-00-08-I0-02
21504-00-0B-10-02
21504-00-O8-10-02
21504-OO-08-10-02
2150A-00-08-10-02
2I504-00-08-10-02
21504 00 08 10 02
21504 00 08 10 0Z
21504 00 08 10 O2
21504 00 08 IO 02
21504 00 OB 10 02
21504 OO 08 10 02
215O4 00 08 10 02
2I504 00 08 10 02
Technical notes
The Bently Nevada 21504-00-08-10-02 operates using an eddy current sensing principle to detect changes in the distance between the probe tip and the rotating shaft surface. The Bently Nevada 21504-00-08-10-02 provides a calibrated measurement range of 80 mils (2.0 mm) and operates with a supply voltage range of -17.5 VDC to -26 VDC with a maximum current consumption of 12 mA. The probe output voltage changes proportionally with shaft displacement, allowing accurate vibration and position monitoring.
FAQs
-
What is the 21504-00-08-10-02?
+The Bently Nevada 21504-00-08-10-02 is an 8mm standard mount proximity probe belonging to the legacy 7200 Series Proximity Transducer System -
How does the Bently Nevada 21504 probe work?
+It utilizes the eddy current principle. The Proximitor (sensor) sends a radio frequency signal to a coil in the probe tip, which generates a magnetic field. -
What applications is this probe used for?
+It is routinely used for radial vibration, axial thrust position, average radial position, and eccentricity measurements on critical rotating machinery like gas/steam turbines, compressors, pumps, and centrifuges -
What is the fundamental working principle of this probe?
+The probe uses the eddy current effect. An internal coil generates a radio frequency (RF) field. As a conductive material (e.g., a turbine shaft) moves closer, it induces eddy currents, altering the voltage. This outputs a signal directly proportional to the distance.
