SP2401
Need Help? Contact US!
Call us: +86-18020776786
Proper, Ready.
Delivery time
Please indicate your delivery time
Product Information
Product Describe
SERVO DRIVE
VARIABLE FREQUENCY
3 PHASE
380/480 VAC
10 HP NORMAL DUTY
15.3 AMP
IP20
50/60 HZ
OPEN LOOP VECTOR CONTROL
CLOSED LOOP INDUCTION MOTOR CONTROL
VARIABLE FREQUENCY
3 PHASE
380/480 VAC
10 HP NORMAL DUTY
15.3 AMP
IP20
50/60 HZ
OPEN LOOP VECTOR CONTROL
CLOSED LOOP INDUCTION MOTOR CONTROL
Technical specifications for SP2401
-
Product ModelSP2401
-
Product ParametersControl Techniques Unidrive
-
Tariff Code8537101190
-
Country of originUSA
-
Place of shipmentXiamen, China
-
Estimated Shipping Size15.5x22x38cm
-
ManufacturerEmerson
-
Weight8.16 kg
-
Number Of Input Phases3 ph
-
Drive Supply Voltage380/480 V ac
-
Horsepower Rating Normal Duty10 hp
-
Output Current Normal Duty15.3 A
-
Motor Phase3 ph
-
Horsepower Rating Heavy Duty7-1/2 hp
-
Output Current Heavy Duty13 A
-
Peak Current22.7 A
-
Peak Current Normal Duty16.8 A
-
Input Frequency Rating50/60 Hz
-
Factory New
These are new and current items that are procured from the manufacturer. -
New No Package
These parts are new. They have not been used, but their original packaging is no longer available. -
New In Opened Package
These parts are new. They have not been used, but their original packaging has been opened or the packaging is significantly aged. -
New In Sealed Package
Parts are new. They have not been used and still have their original package seal intact. -
New in Original Package
These parts are new. The packages were not originally sealed by their original manufacturer.
Warranty Period & Disclaimer
Amikon is not an authorized distributor unless otherwise specified, representative, or affiliate of the manufacturer of this product. All trademarks and documents are the property of their respective owners and are provided for identification and informational.
FAQs
-
What is SP2401?+The Emerson SP2401 is a 10 HP AC variable speed drive from the Unidrive SP (SP2401) range. It is for panel mounting and is known for its versatility in both servo and VFD applications
-
What is the difference between SP2401 and UNI2401?+The SP2401 is an older version that is largely considered a legacy product. While functionally similar, migrating to the newer UNI2401 often requires a panel redesign because wiring terminals and module positions may differ. Furthermore, the SP2401 uses SyPTPro software, whereas the newer models utilize Connect or CTSoft.
-
Does the SP2401 come with a keypad?+No, standard units (SP2401) often come without a keypad, allowing them to be installed in high-volume applications or areas where unauthorized access to settings needs to be restricted. SM-Keypad (LED) or SM-Keypad Plus (LCD) are compatible options.
-
What are the primary specifications of the SP2401?+The SP2401 is a Size 2 panel-mounted AC drive. It features a 3-phase 380–480V input and provides 7.5 kW (10 HP) for normal duty or 5.5 kW (7.5 HP) for heavy duty.
Get a quick price fo SP2401
whatsapp
Inquiry
Our customer support team is always on call to help you with any form of consultation. You can inquire by phone or use us on the product page and "contact us" View Amikon terms and conditions
Product
MORE INFORMATION
Overview
Manuals
Technical notes
Product Applications
Key Installation Steps
Features:
- Universal Multi-Mode Control
- Integrated Safety Interface
- High Power-to-Size Ratio
- Flexible SM-Slot Expansion
- Smartcard Parameter Cloning
- Advanced Onboard Logic
The SP2401 Emerson VARIABLE FREQUENCY SERVO DRIVE may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
Emerson SP2401 VARIABLE FREQUENCY SERVO DRIVE Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The SP2401 model is specifically optimized for applications requiring precise torque and speed regulation. By utilizing the built-in Rotor Flux Control (RFC) or closed-loop vector modes, the drive provides exceptional dynamic response and high starting torque, even at zero speed. Its modularity is a key advantage; with three expansion slots, the drive can be customized with various "SM" modules to support protocols like EtherCAT, Profibus, or Ethernet/IP, and can interface with almost any feedback device, including incremental, SinCos, or absolute encoders.
- Manufacturing & Automation:Conveyors, production lines & automated machinery
- High-Speed Machines:Textile, printing & converting equipment
- Heavy-Duty Processing:Metal, plastics/rubber extrusion & pulp/paper
- Motion Control & Robotics:CNC spindles, servo axes & robotics
- Material Handling:Cranes, hoists and lifts.
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Mechanical Installation: Panel-mount the drive (15.4 lbs) in a vertical position.
Electrical Installation: Connect 3-phase input and connect to a 3-phase AC motor.
External Supplies: A 24Vdc supply must be connected to the +24V external input on the control terminal block for the control circuitry.
