Technical specifications for PR6423/01K-010 CON021
-
Product ModelPR6423/01K-010 CON021
-
Spare ModelPR6423/01K-010
-
Product ParametersEddy Current Displacement Transducer
-
Tariff Code8537101190
-
Country of originGermany
-
Place of shipmentXiamen, China
-
Estimated Shipping Size28x24x4cm
-
ManufacturerEpro
-
Weight0.45 kg
-
Static±1.0 mm (.04 in)
-
Dynamic0 to 500μm (0 to 20 mil)
-
Sensitivity8 V/mm
-
Measuring error after calibration< ±1% linearity error
-
Zero point200 mV / 100˚ K
-
Sensitivity< 2% / 100˚ K
-
Long term drift0.3% max
-
Influence of supply voltage< 20 mV/V
-
Operating temperature range-35 to +180˚ C (-31 to 356˚ F)
-
Temperature range for storage-40 to +70˚ C (-40˚ to 158˚ F)
-
Maximum cable temperature+200˚ C (392˚ F)
Description
Measuring range: 2 mm, max. 4 mm
Sensor head diameter: 8 mm
Frequency range: 0 ... 20 kHz (-3 dB)
Operational temperature: –35...+180 °C
Extended ranges up to 4 mm available
by converter configuration
Various threads and body lengths
Cable length selectable 4...10 m
ATEX certified
Sensor head diameter: 8 mm
Frequency range: 0 ... 20 kHz (-3 dB)
Operational temperature: –35...+180 °C
Extended ranges up to 4 mm available
by converter configuration
Various threads and body lengths
Cable length selectable 4...10 m
ATEX certified
