Foxboro

Input Module

Input16 group isolated and independent channels
Input Range (each channel)0 to 20.4 mA DC (each channel current limited to33 mA)
Accuracy (includes linearity)±0.03% of span
Accuracy temperature coefficient: ±50 ppm/° C
Common Mode Rejection>100 db at 50 or 60 Hz
Normal Mode Rejection>35 db at 50 or 60 Hz
Input Channel Impedance61.9 Ω nominal
INPUT VOLTAGE RANGE (REDUNDANT)24 V DC +5%, -10%
CONSUMPTION7 W (maximum) at 24 V DC11 W (maximum) at 24 V DC with all inputs at20.4 mA (internal power)

POWER MODULE

Support for 10 Mbps Ethernet trunk Fieldbus
Support for DIN rail mounted FBMs
Optional redundancy
Compact, rugged design
Easy to install and configure

Fieldbus Communication Module

INPUT VOLTAGE RANGE (REDUNDANT)24 V dc +5%, -10%
CONSUMPTION7 W (maximum) at 24 V dc
HEAT DISSIPATION7 W (maximum) at 24 V dc
Vibration0.75 g (5 to 200 Hz)
TEMPERATURE-40 to +70°C (-40 to +158°F)
RELATIVE HUMIDITY5 to 95% (noncondensing)
ALTITUDE-300 to +12,000 m (-1,000 to +40,000 ft)

Totalizer- Model 75TUA

I/A Series FieldBus Isolator

I/O Module

RTD Module

P0400YD
DISCONTINUED BY MANUFACTURER
PROCESSOR MODULE
RTD INPUT

Thermacouple / MV Input

Input Module

Relay Module
