Output Module
Brand:GE Fanuc
Series:Field Control
Part Number:IC670MDL730
Product Description:Discrete Output Module
Output Voltage Range:17.5-29.5 Volts DC
Number of Outputs:8
Number of Groups:1
Group to Group Isolation:None
LED Indicators:3
Current Drawn From Power Supply:125 mA
INPUT MODULE
Series:Field Control
Manufacturer:GE Fanuc
Part Number:IC670MDL640
Rated Voltage:24 Volts DC
Input Voltage Range:0 to 30 Volts DC
No. of channels:Sixteen (16)
Number of Points:16
Input signal, nominal:24 VDC
Current (User Input):7.5 milliamps per point at 24 Volts DC
Input signal, range:0-30 VDC
Input current:7.5 mA
Input Impedance:3K typical
Input grouping:Single group
On-state Current:3.0 mA to 8 mA
Off-state Current:0 to -5VDC
DISCRETE INPUT MODULE
Series:Field Control
Part Number:IC670MDL330
Product Type:Output Module
Number of Outputs:16
Output signal, nominal:12-120 VAC
Discrete Outputs:Yes
Output signal, range:10-132 VAC
Voltage Type:AC
Output current:1 A per point; 4 A per module
Voltage Rating:12 to 120 Volts AC
Current Rating:1 Amp
Discrete Output Data:2 Bytes or 16 Bits
Output grouping:Single group
Output Voltage Drop:2.0 volts maximum
DISCRETE INPUT MODULE
Series:Field Control
Manufacturer:GE Fanuc
No. of channels:Sixteen (16)
Part Number:IC670MDL240
Series:Field I/O control
Input signal, nominal:120 VAC
Product Type:Input Module
Input signal, range:0-132 VAC
Number of Inputs:16
Input current:15 mA at 120 VAC
Voltage Type:AC
No of Channels:Sixteen (16)
Frequency:47 to 63 Hertz
Discrete Input Data:16 Bits (2 Bytes)
Input grouping:Single group
15 mA per channel:77 mA
ON state voltage:70-132 VAC
Nominal input voltage:115 VAC
INTERFACE MODULE
Series:Field Control
Manufacturer:GE Fanuc
Part Number:IC670GBI002
Series:Field I/O control
Type:Bus interface unit
Product Description:Bus Interface Unit (BUI)
Nominal Rated Voltage:115 Volts AC, 125 Volts DC
Supply Voltage range:18-30 VDC
Nominal supply voltage:24 VDC
Frequency:47 to 63 Hertz
Power consumption:16.8 Watts
Inrush Current:15-50 Amps peak, 3 mS maximum
Power Supply Output:6.5 VDC ±5%
Current output to modules:1.4 A
Holdup time:10 ms
Holdup Time:20 milliseconds (maximum)
I/O terminal block
Brand:GE Fanuc
Series:Field Control
Part Number:IC670CHS002
Type of Component:I/O Terminal Block
Number of Terminals:37
Maximum Current on Terminals:10 Amperes
Hot Swap Compatible:Yes
Number of Modules per Block:2 modules
I/O Carrier Module
Series:Field Control
Part Number:IC670CHS001
Type of Component:I/O Base, Barrier Style
Number of Terminals:37
Product Description:I/O Carrier Module
Carrier module terminals:Barrier style
Terminal Torque:8 pounds on an inch
No. of Terminals:37 terminals
No of wires per terminal:up to Two (2) wires
Compatible BIU Version:Bus Interface Unit version 2.1
Tightening torque:8 in-lb.
Mounting DIN:Rail / Panel mount
Mounting orientation:Horizontal
I/O EXPANSION CABLE
Brand:GE Fanuc
Series:Field Control
Part Number:IC670CBL002
Type of Component:Expansion connection cable
ESD Protection:Braided drain wire connected to ground or chassis
Length in Centimeters:54.61
Length in Inches:21
Number of Cables per Field Control Station:1
ANALOG INPUT MODULE
Brand:GE Fanuc
Series:Field Control
Part Number:IC670ALG630
Number of Channels:8
Thermocouple Types:J, K, T, E, S R, B, N, G, C, D, Platinel II
Converter Resolution:15 bits + sign
Maximum Voltage Between Channels:250 VAC
Current Drawn from BIU Power Supply:195 mA maximum
Analog Output Module
Series:Field Control
Manufacturer:GE Fanuc
Wiring configuration:Single-ended
Part Number:IC670ALG330
Output signal, nominal:0-20 mA
Product Type:Output Module
Output signal, range:0.0-20.48 mA
Signal Type:Analog
Current or Voltage Outputs:Current Outputs
Conversion resolution:16 bits
Number of Channels:8
Output load capacitance:2000 pF, maximum
Current Range:0 to 20.48 milliamps
Output load inductance:0.5H, maximum
Number of LEDs:1
Update time:1.5mS typical
Magnitude data size:14 bits
Linearity:1 LSB resolution value
Supply Voltage range:18-30 VDC
Nominal supply voltage:24 VDC
Current draw from Bus Interface Unit (BIU):85 mA
Current drawn from external power:250 mA
Analog Output Module
Series:Field Control
Manufacturer:GE Fanuc
Part Number:IC670ALG320
Wiring configuration:Single-ended
Description:Analog output module
Current:4-20 mA
No of Channels:Four (4) Current / Voltage Source outputs
Voltage:0-10 Volts
Output signals:0-20 mA; 4-20 mA; 0-10 VDC; 0-12.5 VDC
ADC Conversion resolution:12 bits
Output Data:4 words
Isolation:1500 VAC for 1 minute, 250 VAC continuous
External Power supply:20-29 VDC, 5 % maximum ripple
Isolation to Ground and Logic:1500 Volts AC
Nominal Supply voltage:24 VDC
Digital Resolution:12 bits, typical
Linearity:1 LSB resolution value
Current Drawn from BIU power supply:51 mA, maximum
Input Types:Isolated and Differential
Output grouping:Single group
Output wiring:Single-ended
ANALOG INPUT MODULE
Series:Field Control
Manufacturer:GE Fanuc
Part Number:IC670ALG240
Description:Analog input module
Channels:16
Input Current:0-25 milliamperes
Wiring configuration:Single-ended
Frequency:50/60 Hertz
Input signal, nominal:0-20 mA
Input signal, range:0.0-20.48 mA
Ripple:10% max.
Maximum current input:35 mA
Common Mode Rejection:86 dB
ADC Conversion resolution:16 bits
Hardware Filter:RC 2nd order
External Power supply:20-28 VDC
Nominal Supply voltage:24 VDC
Input grouping:Single group
CURRENT SOURCE ANALOG INPUT MODULE
Series:Field Control
Manufacturer:GE Fanuc
Part Number:IC670ALG230
No. of channels:Eight (8)
Description:Input module
Wiring configuration:Single-ended
Input signal, nominal:0-20 mA
Isolation to Case:250 Volts AC continuous
Input signal, range:0.0-25 mA mA
Input Impedance:2.87 kiloohms
Analog resolution:5.0 µA
On-state Voltage:15-30 Volts DC
Conversion resolution:12 bits
Off-state Voltage:0-5 Volts DC
External Power supply:18-30 VDC
Current from BIU:100 milliamperes
Analog resolution:5.0 microAmps
Nominal Supply voltage:24 VDC
Input Impedance:249.75 to 250.25 Ohms
Input grouping:Single group
Genius Block I/O module
Brand:GE Fanuc
Series:Genius I-O
Part Number:IC660TSS100
Product Type:Terminal assembly
Storage Temperature:-40 to 212 degrees Fahrenheit
Relative Humidity:5 to 95%
Vibration:5 to 10 Hertz
Genius Block I/O module
Series:Genius I-O
Part Number:IC660TSD100
Product Type:Terminal assembly
Operating Temperature:32 to 140 degrees Fahrenheit
Number of Circuits per I/O Block:8
Supported Memory:EEPROM
Genius Block I/O module
Brand:GE Fanuc
Series:Genius I-O
Part Number:IC660TSD021
Product Type:Terminal assembly
Compatibility:IC660BBD021 I/O Block
Solid-State Sensors:Supported
Relative Humidity:5 to 95%
Input Filter Time:5 to 100 milliseconds
Genius Block I/O module
Series:Genius I-O
Part Number:IC660TSD020
Product type:Terminal assembly
3-Wire Solid-State Sensors:Supported
Operating Temperature:0 to 60 degrees Celsius
Inrush Current:10 Amps
Genius Block I/O module
Series:Genius I-O
Part Number:IC660TSA100
Product Type:Terminal assembly
Operating Temperature:0 to 60 degrees Celsius
Heat Dissipation Rating:6 Watts
Genius Block I/O module
Series:Genius I-O
Part Number:IC660TSA020
Product Type:Terminal assembly
Operating Temperature:0 to 60 degrees Celsius
Wire Gauge:12 AWG Wire
Genius Block I/O module
Brand:GE Fanuc
Series:Genius I-O
Part number:IC660TBR101
Product type:Terminal assembly
Compatibility:IC660BBR101
Relay type:Normally open
Genius Block I/O module
Brand:GE Fanuc
Series:Genius I-O
Part Number:IC660TBR100
Product type:Terminal assembly
Compatibility:IC660BBR100
Operating temperature:0 to 60 degrees Celsius
Block Circuit Type:Normally Closed
Genius Block I/O module
Series:Genius I-O
Part Number:IC660TBD120
Block Type:High-speed counter
Operating Voltage:93 to 132 Volts AC / 10 to 30 Volts DC
Frequency/Ripple:47 to 63 Hertz / 10% maximum
Required AC Power:60 milli Amps typical / 250 milli Amps maximum
Genius Block I/O module
Series:Genius I-O
Part Number:IC660TBD110
Block Type:16 circuits, inputs only
Rated Voltage:115 Volts AC Volts
Operating Voltage:93 to 132 Volts AC
Frequency:47 to 63 Hertz
Power Supply Dropout Time:1 cycle
Input to Ground Isolation:1500 Volts
Genius Block I/O module
Series:Genius I-O
Part Number:IC660TBD025
Block Type:DC 32 circuit discrete input and output
Rated Voltage:5/12/24 Volts DC
Operating Voltage:4.9 to 5.3 Volts DC
Ripple:10% maximum (12/24 Volts) / 1% maximum (5 Volts)
Heat Dissipation (Maximum):18 Watts maximum
Block to Block Isolation:850 Volts
Genius Block I/O module
Series:Genius I-O
Part Number:IC660TBD024
Block Type:DC 32 circuit discrete input and output
Rated Voltage:12/24 Volts DC
Operating Voltage:10 to 30 Volts DC
Ripple:10% maximum
Heat Dissipation (Maximum):18 Watts maximum
Block to Block Isolation:850 Volts
