- DS200DCFBG1BNC
In Stock
Ships by Sunday, June 28
Fast Shipping Available
· Product image is representative; revision or series may vary. Contact us to request a specific version.
Require for Quote:
Need more help? You may also find the answer in our FAQ section
We provide 1 year warranty for all remaining parts.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online.
If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.
Amikon offers a wide range of components, products and services related to industrial automation. We have a large surplus of stocks and are also distributors of new products from a variety of quality manufacturers.
Technical specifications for DS200DCFBG1BNC
-
Product ModelDS200DCFBG1BNC
-
Spare ModelDS200DCFBG1B
-
Product ParametersDC Power Supply Feedback Board
-
Tariff Code8537101190
-
Country of originUSA
-
Place of shipmentXiamen, China
-
In stock1 unit
-
Estimated Shipping Size27.8x21.2x4cm
-
ManufacturerGeneral Electric
-
Weight0.8 kg
-
AC Input38 – 115 VAC
-
Fan Output+24 Vdc switched
-
Isolation2.5 kVac input-to-output
-
Operating Temperature–40 °C … +70 °C
-
Storage Temperature–40 °C … +80 °C
-
Humidity95 % RH non-condensing
Description
The GE DS200DCFBG1BNC DC Feedback Power Supply Board is a power management and monitoring module developed for the GE Mark V Speedtronic control platform. The board is responsible for generating and distributing regulated DC voltages required by various control modules while simultaneously monitoring DC system conditions to support safe and reliable equipment operation.
Within a Mark V turbine control system, the DS200DCFBG1BNC serves as a central power interface, supplying stable voltage levels to processors, communication modules, and control circuits. The board incorporates DC feedback circuitry that continuously monitors power system conditions and provides operational data used by the control system for diagnostics, alarm generation, and protective actions.
Within a Mark V turbine control system, the DS200DCFBG1BNC serves as a central power interface, supplying stable voltage levels to processors, communication modules, and control circuits. The board incorporates DC feedback circuitry that continuously monitors power system conditions and provides operational data used by the control system for diagnostics, alarm generation, and protective actions.
Alternative Names
DS200DCFBG1B NC
DS200DCFBGIBNC
DS2OODCFBG1BNC
DSZ00DCFBG1BNC
DSZ00DCFBGIBNC
DS2OODCFBGIBNC
Information
Overview
Manuals
Application Notes
Product Applications
Core Protection Functions
Features:
- Power Supply Board
- Speedtronic Mark V control system
- Gas turbine control system
The DS200DCFBG1BNC GE Power supply board may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
GE DS200DCFBG1BNC Power supply board Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Beyond power distribution, the DS200DCFBG1BNC incorporates comprehensive AC and DC monitoring circuits. These circuits continuously measure critical operational parameters including armature current and voltage, motor field current, AC line current, and AC line voltage magnitude and phase sequence. Voltage-controlled oscillator (VCO) circuits on the board transform these analog measurements into frequency signals ranging from 0 to 500 kHz, with a nominal output of 250 kHz. These frequency-encoded signals are transmitted via connector 1PL to the Speedtronic Drive Control Card (SDCC) or Large Drive Control Card (LDCC), providing real-time feedback for closed-loop control of the drive system.
- Wind power generation: Managing power control in large-scale wind energy automatic drive components
- Ship propulsion: Gas turbine propulsion systems for warships or large merchant ships
- Gas turbine/steam turbine control: Main control system of combined cycle power plants
- Generator excitation: Monitoring the magnetic field current of the generator and the voltage of the AC lines
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Overcurrent and Short Circuit Protection: The board is equipped to handle and protect against excessive current flow and short circuits to prevent damage to the drive's control-level components.
Overvoltage Protection: It includes dedicated voltage protection and suppression strategies, utilizing a combination of capacitors, transistors, resistors, and diodes to manage and suppress voltage spikes.
Power Fluctuation Protection: Designed to shield sensitive control electronics from voltage instability and various electrical disturbances common in industrial environments.
Surge Protection: Each module undergoes testing for surge protection (IEC 61000-4-5) to ensure it can withstand sudden electrical surges without failure.
Technical notes
The board receives its input power from the control power transformer (CPT) at 38 VAC to 115 VAC and converts it into five distinct output rails: +5 VDC at 4A for digital logic circuits, ±15 VDC at 0.8A for analog signal conditioning (with 0.25A available for external loads), and ±24 VDC (+3A / −1A) for field excitation and interface circuits. Additionally, it provides a 115 VAC output specifically for powering the enclosure cooling fans, ensuring adequate thermal management of the drive system.
- What happens next
- Get the quote now Write Email to INFO@AMIKON.CNEmail confirmation You will get an email confirming that we have received your enquiry.Dedicated Account Manager One of our team will be in touch to confirm your part(s) specification and condition.Your quote You will receive a comprehensive quote tailored to your specific needs.Need Moore Help? Get fast and efficient help from our experienced sales or customer service teams.
- Delivery and payment
- Delivery
Logistic partners UPS, FedEx and DHL
International delivery available
Same day dispatch from warehouse inventory
Warranty
All parts new original are covered by Amikon 12 month warranty
Returns
No hassle returns policy
Dedicated customer support team
Payment options
We accept Bank transfers and the following methods of payment:
For more information, please visit our dedicated payments page.
- Why Choose Amikon Limited?
When it comes to industrial automation, reliability, speed, and trust matter. At Amikon Limited, we go beyond just supplying parts — we deliver confidence.
- ● Extensive Inventory Reach: Nearly 1 million automation parts at your fingertips, including legacy and obsolete models.
- ● 20+ Years of Expertise: Trusted by engineers, project managers and government companies worldwide for our professional service.
- ● Quality You Can Trust: Each unit is strictly inspected by the warehouse staff to ensure product quality
- ● Fast Global Shipping: We help you minimize downtime with express logistics worldwide.
- ● 1-Year Warranty Available: Peace of mind with every purchase backed by one year warranty guarantee.
Whether you're maintaining legacy systems or building future-ready projects, Amikon Limited is your dependable partner in precision and performance.
FAQs
-
What is DS200DCFBG1BNC?
+The GE DS200DCFBG1BNC is a DC Feedback Power Supply Board used in the EX2000 series exciter and DC drive systems. -
What is the function of the DS200DCFBG1BNC?
+It serves as a DC feedback power supply board that provides control-level power to the drive, power to enclosure fans (115 VAC), and handles functions such as motor field power, system clock, and firing commands. -
What is the difference between DS200DCFBG1BNC and G1BKC?
+The DS200DCFBG1BKC is a version of the DS200DCFBG1BNC that includes specific product revisions (KC) for the Mark V series. -
Which systems use DS200DCFBG1BNC?
+It is used in various GE drives and excitation systems, including the EX2000, DC2000, CB2000, FC2000, GF2000, ME2000, and AC2000.
