Technical specifications for DS200SDCCG1AGD
-
Product ModelDS200SDCCG1AGD
-
Spare ModelDS200SDCCG1A
-
Product ParametersDRIVE CPU BOARD
-
Tariff Code8537101190
-
Country of originUSA
-
Place of shipmentXiamen, China
-
In stock1 unit
-
Estimated Shipping Size28x21.3x3cm
-
ManufacturerGeneral Electric
-
Weight0.55 kg
-
Total Card Connections8 connections
-
LED Indicators10 LEDs
-
Control Power Input24 V DC
-
Power Consumption (I/O section)20.6 W
-
Operating Temperature-40°C to +70°C
-
Storage Temperature-55°C to +125°C
-
Humidity≤95% RH (non-condensing)
Description
GE Drive Control Board DS200SDCCG1AGD is one of the primary controllers for the drive made for use in the Mark V series. The Mark V Series is one of the more recently-developed product series utilizing General Electric's patented style of Speedtronic technology in its assembly. This DS200SDCCG1AGD Drive Control Board's Mark V Series has specific applications in the management and control systems of relevant gas, steam, and wind turbines supporting General Electric products.
While this DS200SDCCG1AGD printed circuit board is definable as a Drive Control Board, its is by no means the original product with its specific functionality to exist within the Mark V Turbine Control System Series; that would be the DS200SDCCG1 Drive Control Board pointedly missing this DS200SDCCG1AGD product's three significant revisions.
While this DS200SDCCG1AGD printed circuit board is definable as a Drive Control Board, its is by no means the original product with its specific functionality to exist within the Mark V Turbine Control System Series; that would be the DS200SDCCG1 Drive Control Board pointedly missing this DS200SDCCG1AGD product's three significant revisions.
Alternative Names
DS200SDCCG1A
DSZ00SDCCG1AGD
DS2OOSDCCG1AGD
DS200SDCCGIAGD
DS2OOSDCCGIAGD
DSZ00SDCCGIAGD
Information
Overview
Manuals
Engineering Considerations
Product Applications
Handling & Electrical Safety
Features:
- Three Microprocessors with Shared RAM Access
- Ten LED Fault Code Display
- Auxiliary Board Mounting Support
- Three Significant Revisions from Parent Board
The GE DS200SDCCG1AGD operates with high voltage. High voltage exists in the boards and all components of the GE DS200SDCCG1AGD. Care must be taken when opening the board cabinet door on the GE DS200SDCCG1AGD. Nothing in the cabinet should be touched while power is applied to the GE DS200SDCCG1AGD. Nothing should fall in the cabinet while the door is open on the GE DS200SDCCG1AGD. The door should be closed when inspection is complete on the GE DS200SDCCG1AGD.
The DS200SDCCG1AGD GE Drive Control Board may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
GE DS200SDCCG1AGD Drive Control Board Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Processing Power: The board is equipped with three 16-bit microprocessors and RAM, allowing simultaneous data access by multiple processors for fast, real-time drive regulation.
Daughterboard Integration: Several auxiliary boards can be mounted directly on the face of the PCB to expand the processing or auxiliary functions.
Environmental Coating: Boards come with a normal coating to shield components from dust, humidity, and chemical exposure in industrial environments
- Wind Energy Systems:Top Box Module: nacelle/hub signals to ground controller
- Power Generation Plants:Manages electrical loads & protection loops
- Industrial Automation & Process Industries:Interfaces with GE Mark VIe DCS
- Marine & Offshore:Heavy maritime power & offshore energy
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
ESD Protection: Leave the replacement board in its static-protective bag until you are ready to install it. Always ground yourself using an anti-static strap when handling components.
Power Check: Verify that all power sources are completely off before making any wire connections.
Live Cabinet Danger: Do not touch anything inside the cabinet while the drive is powering up. Avoid dropping screws or debris into the cabinet during installation.
Technical notes
The GE DS200SDCCG1AGD supports auxiliary boards mounted on its face. The auxiliary boards on the GE DS200SDCCG1AGD provide added efficiency or processing functions. The auxiliary boards on the GE DS200SDCCG1AGD include the DS215SLCC or 531X306LCC LAN Communications Card. The auxiliary boards on the GE DS200SDCCG1AGD include the 531X309SPC Signal Processor Card. The auxiliary boards on the GE DS200SDCCG1AGD include the DS200SPCB Multibridge Signal Processor Card.
FAQs
-
What is the DS200SDCCG1AGD？
+The GE DS200SDCCG1AGD is a Drive Control Board primarily used in GE’s Mark V series turbine and drive control systems. It acts as the central processor for AC2000, DC2000, and EX2000 drive applications -
What are the main microprocessors on the board?
+The board contains three primary microprocessors that process data, regulate the drive based on configuration parameters, and execute control commands. -
What system components connect via the 3PL connector?
+The 3PL connector acts as a primary communication bridge to route signals between the control card and adjacent power boards or signal distribution boards. -
Can this board replace other SDCC versions?
+Yes. While basic SDCC boards are confined to a single drive type, the G1AGD revision is a multi-application board that aggregates functions for AC, DC, and exciter frameworks alike.
