· Product image is representative; revision or series may vary. Contact us to request a specific version.
Require for Quote:
Need more help? You may also find the answer in our FAQ section
We provide 1 year warranty for all remaining parts.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online.
If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.
Amikon offers a wide range of components, products and services related to industrial automation. We have a large surplus of stocks and are also distributors of new products from a variety of quality manufacturers.
Technical specifications for DS2020DACAG2
-
Product ModelDS2020DACAG2
-
Product ParametersPower Conversion Module
-
Tariff Code8537101190
-
Country of originUSA
-
Place of shipmentXiamen, China
-
Estimated Shipping Size19.3x27x27cm
-
ManufacturerGeneral Electric
-
Weight19.95 kg
-
Input Voltage105-132 V ac or 210-265 V ac, 47 to 63 Hz
-
Output Voltage90 to 145 V dc with a load of 1 to 9.5 A
-
Output Current Rating9.5 A dc, -30 to 45°C (-22 to 113 °F)
-
Output Ripple Voltage4 V p-p
-
Temperature-30 to 60°C (-22 to +140 °F) free convection
-
Humidity5 to 95%, non-condensing
Description
AC/DC POWER CONVERSION ASSEMBLY
115/230 VAC INPUT
50/60 HZ
125 VDC OUTPUT
FOR SPEEDTRONIC MARK V/VI-E / EX2100 SYSTEMS
REPLACES DS2020DACAG1
115/230 VAC INPUT
50/60 HZ
125 VDC OUTPUT
FOR SPEEDTRONIC MARK V/VI-E / EX2100 SYSTEMS
REPLACES DS2020DACAG1
Information
Overview
Manuals
Technical notes
Product Applications
Key Instructions & Specifications
Features:
- AC-DC Power Conversion Assembly
- Mark VIe and EX2100 Control Systems
- 125 VDC power supply
- HART Modem per Channel for Fast Performance
The DS2020DACAG2 GE AC/DC Converter Board may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
GE DS2020DACAG2 AC/DC Converter Board Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The DS2020DACAG2 is an AC to DC Power Conversion assembly used in GE Energy Mark VIe and EX2100 Control Systems.It serves as a drop-in and fully backward-compatible replacement for the earlier model DS2020DACAG1. The DS2020DACAG2 is used in systems with a primary power source of 125VDC or those operating without a battery.The DS2020DACAG2 provides local energy output to extend ride-through time during control power loss
- Turbine Control Systems:GE EX2100 & Mark V/VIe voltage regulation
- Power Conversion:115/230 VAC to regulated 125 VDC output
- Energy Storage & Ride-Through:Local storage maintains control during power interruptions
- Redundant Power Supply:Parallelable to 16.5A for fault-tolerant power
- Component Powering:Solenoids, relays, flame sensors & motor controls
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Input/Output: Accepts 115/230 VAC (50/60 Hz) and provides a 125 VDC nominal output.
Installation: The module is typically floor-mounted within a drive cabinet using four specialized brackets and bolts to ensure stability.
Operating Environment: It must be used in non-corrosive, non-flammable environments with a temperature range of -30°C to +65°C (-22°F to +149°F) and relative humidity between 5–95% (non-condensing).
Parallel Operation: Multiple units can be connected in parallel to increase the output current capacity, with a maximum of 16.5 ADC when paralleled (compared to 9.5 ADC for a single unit).
- What happens next
- Get the quote now Write Email to INFO@AMIKON.CNEmail confirmation You will get an email confirming that we have received your enquiry.Dedicated Account Manager One of our team will be in touch to confirm your part(s) specification and condition.Your quote You will receive a comprehensive quote tailored to your specific needs.Need Moore Help? Get fast and efficient help from our experienced sales or customer service teams.
- Delivery and payment
- Delivery
Logistic partners UPS, FedEx and DHL
International delivery available
Same day dispatch from warehouse inventory
Warranty
All parts new original are covered by Amikon 12 month warranty
Returns
No hassle returns policy
Dedicated customer support team
Payment options
We accept Bank transfers and the following methods of payment:
For more information, please visit our dedicated payments page.
- Why Choose Amikon Limited?
When it comes to industrial automation, reliability, speed, and trust matter. At Amikon Limited, we go beyond just supplying parts — we deliver confidence.
- ● Extensive Inventory Reach: Nearly 1 million automation parts at your fingertips, including legacy and obsolete models.
- ● 20+ Years of Expertise: Trusted by engineers, project managers and government companies worldwide for our professional service.
- ● Quality You Can Trust: Each unit is strictly inspected by the warehouse staff to ensure product quality
- ● Fast Global Shipping: We help you minimize downtime with express logistics worldwide.
- ● 1-Year Warranty Available: Peace of mind with every purchase backed by one year warranty guarantee.
Whether you're maintaining legacy systems or building future-ready projects, Amikon Limited is your dependable partner in precision and performance.
FAQs
-
What is the DS2020DACAG2？
+The GE DS2020DACAG2 is an AC-to-DC Power Conversion Module (also known as a transformer assembly) within the Speedtronic Mark V series, designed to convert alternating current (VAC) to direct current (VDC) -
What DS2020DACAG2 are the Input/Output Specifications?
+The module supports 115VAC or 230VAC inputs and provides a 107VDC output. -
Can two DS2020DACAG2 units be connected to different sources?
+While they are used in high-reliability applications, it is generally advised to check specific documentation for parallel or dual-source configurations. -
What is the operating environment?
+The module must be used in environments with temperatures between -30°C and +65°C, with a relative humidity of 5%–95% (non-condensing). -
Is this product brand new?
+Yes, GE DS2020DACAG2 is brand new, original, unused, and factory sealed -
How do I get the price of DS2020DACAG2 ?
