- IS200TVBAH2ACC
In Stock
Ships by Sunday, August 16
Fast Shipping Available
· Product image is representative; revision or series may vary. Contact us to request a specific version.
We provide 1 year warranty for all remaining parts.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online.
If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.
Amikon offers a wide range of components, products and services related to industrial automation. We have a large surplus of stocks and are also distributors of new products from a variety of quality manufacturers.
Technical specifications for IS200TVBAH2ACC
-
Product ModelIS200TVBAH2ACC
-
Spare ModelIS200TVBAH2A
-
Product ParametersVibration Input Terminal Board
-
Tariff Code8537101190
-
Country of originUSA
-
Place of shipmentXiamen, China
-
In stock1 unit
-
Estimated Shipping Size33x17.7x8.2cm
-
ManufacturerGeneral Electric
-
Weight0.65 kg
-
Input Impedance1.5 MΩ
-
Isolation1500 V DC
-
Power Supply+28 V DC
-
Operating Temp–40 °C to +85 °C
-
Storage Temp–55 °C to +90 °C
-
Humidity5 – 95 % RH non-condensing
Description
The IS200TVBAH2ACC is a vibration input terminal board from the GE Mark VI/VIe Speedtronic Turbine Control System family, manufactured by General Electric in the United States. It serves as the field wiring interface between vibration monitoring sensors and the Mark VI/VIe control system I/O packs.
The terminal board accepts signals from eddy current proximity probes, seismic velocity transducers, and accelerometers used for monitoring shaft vibration, bearing vibration, and casing vibration on gas turbines, steam turbines, compressors, and generators. Input signals are buffered, filtered, and conditioned before transmission to the Mark VI/VIe I/O packs for analog-to-digital conversion and processing by the control algorithms.
The terminal board accepts signals from eddy current proximity probes, seismic velocity transducers, and accelerometers used for monitoring shaft vibration, bearing vibration, and casing vibration on gas turbines, steam turbines, compressors, and generators. Input signals are buffered, filtered, and conditioned before transmission to the Mark VI/VIe I/O packs for analog-to-digital conversion and processing by the control algorithms.
Information
Overview
Manuals
Application Notes
Product Applications
Cable & Field Connections
Features:
- Interfaces multiple vibration sensor types
- Supports proximity probes, accelerometers, and seismic sensors
- Signal conditioning and buffering for stable transmission
- Conformal-coated PCB for harsh environments
The board is designed to connect multiple types of vibration measurement devices, including proximity probes, seismic velocity sensors, accelerometers, and Velomitor-type transducers. It provides signal termination, biasing, and buffering to maintain stable signal quality under industrial electrical noise conditions commonly found in turbine enclosures and power generation environments.
The IS200TVBAH2ACC GE Vibration Input Terminal Board may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
GE IS200TVBAH2ACC Vibration Input Terminal Board Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
In typical system architecture, the IS200TVBAH2ACC receives raw analog signals from field instrumentation and routes conditioned outputs through dedicated connectors to the Mark VIe control system. A Keyphasor input channel is commonly used as a reference signal for shaft speed and phase measurement, which is critical for rotor dynamics analysis and protection logic.
The module is constructed as a rugged industrial PCB assembly with conformal coating to improve resistance against moisture, dust, and corrosive gases. It is designed for continuous operation in high-vibration and high-temperature environments typically found in gas turbines, steam turbines, and large rotating machinery installations.
- Turbine Health Monitoring: Tracks real-time vibration profiles to spot abnormalities early
- Gas Turbine Controls: Embedded in GE-compatible drive systems for critical safety baselines
- Steam Turbine Controls: Deployed to minimize risk of catastrophic component failure
- Wind Turbine Drives: Used in wind hubs for continuous rotor and drivetrain feedback
- Machinery Protection: Monitors structural movement of bearings, shafts, and rotor conditions
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Sensor Wiring: Connect up to 14 field sensors directly to the two 24-terminal blocks. Each terminal accommodates up to #12 AWG wire and is secured with two screws.
Shielding: Terminate all cable shields directly to the chassis ground bus bar or the shield termination attachment points located directly next to the terminal blocks.
Buffered Outputs: The board features front-edge connectors (such as 37-pin, 25-pin, 9-pin, and BNC connectors). These allow you to hook up third-party apparatus or Bently Nevada monitoring racks in parallel.
Alternative Names
IS200TVBAHZACC
IS20OTVBAH2ACC
IS2O0TVBAH2ACC
1S200TVBAH2ACC
IS2OOTVBAH2ACC
Technical notes
Physical dimensions are approximately 254 mm × 102 mm × 25 mm with a weight of 0.5 kg. The board mounts on DIN rail or panel within the Mark VI/VIe control cabinet. Field wiring connects via screw terminals accepting wire sizes from 0.2 to 2.5 mm² (24 to 14 AWG). Connection to the I/O pack is made via ribbon cable or backplane connector.
FAQs
-
Can the IS200TVBAH2ACC be hot-swapped?
+No. The board must be de-energized before removal to avoid damaging circuitry or creating transients. -
Are the buffered outputs isolated from primary control signals?
+Yes. Buffered outputs via BNC and D-sub connectors are isolated, allowing for safe connection of diagnostic tools. -
What transducers are accommodated by the IS200TVBAH2A PCB's Vibration Inputs?
+The IS200TVBAH2ACC unique Vibration Inputs accomodate proximitor, seismic, velomiter, and accelerometer styles of transducers. -
How many N24 buffered outputs are offered on the IS200TVBAH2ACC base board?
+The IS200TVBAH2A offers a series of fourteen total N24 buffered outputs.
