- IC755CSS12CDB
In Stock
Ships by Friday, August 7
Fast Shipping Available
· Product image is representative; revision or series may vary. Contact us to request a specific version.
We provide 1 year warranty for all remaining parts.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online.
If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.
Amikon offers a wide range of components, products and services related to industrial automation. We have a large surplus of stocks and are also distributors of new products from a variety of quality manufacturers.
Technical specifications for IC755CSS12CDB
-
Product ModelIC755CSS12CDB
-
Product ParametersOPERATOR INTERFACE
-
Tariff Code8537101190
-
Country of originUSA
-
Place of shipmentXiamen, China
-
In stock1 unit
-
Estimated Shipping Size31.4x24.8x6.5cm
-
ManufacturerGeneral Electric
-
Weight3 kg
-
ProcessorFreescale i.MX535 (1 GHz ARM Cortex A8)
-
RAMDDR3 SDRAM 1 GB
-
Operating SystemMicrosoft Windows Embedded Compact 7
-
Touch Panel TypeProjected Capacitive 2-Point
Description
The IC755CSS12CDB is a QuickPanel+ device that is currently manufactured by Emerson Automation. This product has compact assembly and able to function as a Human Machine Interface (HMI), a Programmable Logic Controller (PLC), a process controller, machine gateway and data historian. The IC755CSS12CDB is powered by an input supply voltage of 12-30 VDC with maximum power consumption of 30 Watts. It has a graphic display measuring 12 inches and resolution of 800 x 600 pixels with dedicated 2D / 3D graphics accelerator and NEON SIMD Media accelerator while the provided operator interface is a projected 2-point capacitive touch screen interface.
The IC755CSS12CDB hosts a Microsoft Windows Compact Embedded (CE) version 7 Operating System (OS). It is equipped with an Freescale i.MX535 processor with clockspeed of 1GHz. This OS enables a variety of PC like function such as remote connectivity using VNC, web browser, intranet, SNMP, File Transfer Protocol (FTP) and HTTP. To function as a controller, the IC755CSS12CDB supports the defined programming language by IEC 61131-3 which are Ladder Diagram (LD), Function Block Diagram (FBD), Structured Text (ST), Instruction List (IL) and Sequential Function Chart (SFC). With the same database located within the same hardware, integration and communication is greatly simplified.
The IC755CSS12CDB hosts a Microsoft Windows Compact Embedded (CE) version 7 Operating System (OS). It is equipped with an Freescale i.MX535 processor with clockspeed of 1GHz. This OS enables a variety of PC like function such as remote connectivity using VNC, web browser, intranet, SNMP, File Transfer Protocol (FTP) and HTTP. To function as a controller, the IC755CSS12CDB supports the defined programming language by IEC 61131-3 which are Ladder Diagram (LD), Function Block Diagram (FBD), Structured Text (ST), Instruction List (IL) and Sequential Function Chart (SFC). With the same database located within the same hardware, integration and communication is greatly simplified.
Revisions
Revision Part #
Also known as
Information
Overview
Manuals
Application Notes
Product Applications
Electrical Connections
Features:
- Freescale i.MX535 1GHz based on ARM Cortex A8
- 2D/3D Graphics Processing Unit
- 32KB Level 1 Instruction/Data Caches
- 256KB Level 2 Unified Instruction and Data Cache
- NEON SIMD Media Accelerator
The terminal features a 12.1-inch color TFT LCD display with a resolution of 800 × 600 pixels (SVGA) and 24-bit color depth supporting 65,536 colors. The display is equipped with a projected capacitive 2-point multi-touch screen that supports gloved and wet-finger operation, enabling intuitive operator interaction in industrial environments. The unit carries a GE Monogram Bezel design.
At the core of the device is a Freescale i.MX535 processor running at 1 GHz on the ARM Cortex-A8 architecture, paired with 1 GB of DDR3 SDRAM, 512 MB of SLC NAND flash, and 512 KB of battery-backed SRAM. A dedicated 2D/3D GPU with NEON SIMD media accelerator and 32 KB L1 / 256 KB L2 caches provides hardware-accelerated graphics rendering for responsive HMI performance. The system runs Microsoft Windows Embedded Compact 7, a full 32-bit operating system with graphical user interface that boots immediately upon power-up
The IC755CSS12CDB GE QuickPanel+ View & Control operator interface terminal may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
GE IC755CSS12CDB QuickPanel+ View & Control operator interface terminal Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The QuickPanel+ integrates view, control, and data historian capabilities in a single hardware platform. As a controller, it supports programming in all five IEC 61131-3 languages: Ladder Diagram (LD), Function Block Diagram (FBD), Structured Text (ST), Instruction List (IL), and Sequential Function Chart (SFC). The shared database residing on the same hardware greatly simplifies integration and communication between HMI and control functions.
Communication interfaces include dual 10/100 Mbps Ethernet ports (RJ-45) for network connectivity, two serial ports (RS-232 and RS-422/485/232), two USB 2.0 host ports (Type-A), one USB 2.0 device port (Mini Type-B), and an SD/SDHC card slot for external storage expansion. A 3.5 mm stereo line-out jack provides audio output. The terminal supports remote programming and diagnostics via VNC, Web browser, intranet, SNMP, FTP, and HTTP.
- Automated Assembly/Packaging: Primary interface for managing motion control, production quotas, and line speeds
- Food/Beverage/Pharma: Manages batch recipe sequencing and monitors critical regulatory data
- Water/Wastewater: Provides process visualization and data history for remote pumping/filtration
- Building Automation/HVAC: Centralized display and control gateway for facility-wide environmental monitoring
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Power: Wire the supplied plug using a regulated 24 VDC power supply. Ground the unit properly using the designated frame ground terminal to reduce electromagnetic interference (EMI).
Ethernet: The unit features two 10/100Base-T Fast Ethernet RJ-45 ports for device communication and remote programming via VNC.
Serial Ports: One dedicated RS-232 and one RS-485 port are available for older peripheral devices or industrial protocols.
USB & Storage: Standard USB ports and an SD/SDHC memory card slot are available on the rear (or under the front access door) for data logging, keyboard connection, or firmware updates.
Alternative Names
1C755CSS12CDB
1C755CSSI2CD8
IC755CSS12CD8
IC755CSSI2CDB
Technical notes
The IC755CSS12CDB is compatible with PACSystems RX3i, RX7i, and Series 90 PLCs, and supports industrial protocols including Modbus RTU/TCP, Ethernet/IP, PROFINET, and DF1. Third-party component compatibility is supported.Power is supplied via 24 VDC ±20% (19.2–28.8 VDC) with a maximum consumption of 30 W (some configurations up to 60 W). The unit features a tri-color LED indicator (Amber/Green/Red) and an on-board buzzer for status and alarm indication.
FAQs
-
What is the IC755CSS12CDB ?
+The GE IC755CSS12CDB is a 12-inch QuickPanel+ operator interface by GE Fanuc (now Emerson). It functions as an all-in-one HMI, controller, and data historian. -
Is the touchscreen multi-touch?
+Yes, it utilizes a projected capacitive (PCAP) touchscreen that supports 2-point multi-touch and can be operated while wearing gloves or with wet fingers -
What processor and operating system does it use?
+It is powered by a Freescale i.MX535 (1 GHz ARM Cortex-A8) processor and runs on Microsoft Windows Embedded Compact 7. -
How much memory does it have?
+It comes with 1 GB of DDR3 SDRAM, 512 MB of SLC NAND Flash, and 512 KB of battery-backed SRAM for retentive data storage.
