Technical specifications for IC200MDL750
-
Product ModelIC200MDL750
-
Product ParametersOutput 12/24VDC POS LOGIC 0.5A per point (2 groups of 16) 32 points
-
Tariff Code8537101190
-
Country of originUSA
-
Place of shipmentXiamen,China
-
Estimated Shipping Size11x5.8x6.7cm
-
ManufacturerGeneral Electric
-
Weight0.14 kg
-
Output voltage+10.2 to +30VDC, +12/24VDC nominal
-
Output voltage drop0.3V maximum
-
Output leakagecurrent0.5mA at 30VDC maximum
-
On response time0.2ms, maximum
-
Off response time1.0ms maximum
-
External power supply+10.2 to +30VDC, +12/24VDC nominal
Description
IC200MDL750
OUTPUT MODULE
VERSAMAX
DISCRETE
24 VDC POSITIVE LOGIC
0.5 AMP PER POINT
32 POINT
OUTPUT MODULE
VERSAMAX
DISCRETE
24 VDC POSITIVE LOGIC
0.5 AMP PER POINT
32 POINT
Revisions
Revision Part #
Also known as
Information
Overview
Manuals
Technical notes
Product Applications
LED Indicators
Features:
- Discrete output modul
- 12/24VDC Positive Logic 0.5 Amp
- 32 Points
The IC200MDL750 is a 32-Point discrete output module from the VersaMax I/O series formerly produced by GE Intelligent Platforms, now under Emerson Automation. This module has Thirty-Two (32) output channels that supports positive logic wiring configuration, in Two (2) groups of Sixteen (16) channels per group. Each input channel of this module is rated 12/24 VDC nominal output with output signal range of 10.2-30 VDC along an output current of 0.5 mA per point. This module has a backplane current draw of 90 mA.
The IC200MDL750 GE Discrete output module may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
GE IC200MDL750 Discrete output module Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The IC200MDL750 is a high-density digital output module that is manufactured by Emerson Automation, formerly by GE Intelligent Platforms (GE IP). This module mainly features Thirty-Two (32) output channels in Two (2) groups of Sixteen (16) output channels each. This module is typically utilized to actuate or energize electrical loads such as solenoid actuated devices, relay coils, pilot lamps and other devices with dual-state operation only particularly, binary or On and Off. It is compatible for use with 24 VDC rated devices as the IC200MDL750’s nominal voltage output is 12 / 24 VDC with an output voltage range of 10.2 - 30 VDC along an output current of 0.5 A per channel. The IC200MDL750 is part of the VersaMax I/O platform, designed to be used as a component module of a distributed I/O architecture. It requires use of a carrier base that hosts the wiring terminals intended for the module. With the carrier base, the module can be installed in horizontal or vertical orientation, onto a standard 35 mm DIN rail.Similar to the other I/O modules, each output channel is provided with an individua LED status indicator that is used to locally monitor the activity of the module per channel. In addition, an OK LED is also provided, depicting the active supply of power from the backplane which is maximum of 90 mA.
- Factory Automation:Synchronizes multiple machines on production lines
- Material Handling:Large-scale conveyors & sorters spanning wide areas
- Automotive Plants:High-speed discrete I/O for robotic assembly & painting
- Gas Monitoring & Safety:SIL 1/2 hazardous area monitoring & gas detection
- Process Control:Modular distributed control for light chemical/water treatment
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Individual green LEDs indicate the on/off state of the output points. Operation ofthese LEDs is dependent on field power but independent of load conditions.The green FLD PWR LED is on when field power is applied to the module.The green OK LED is on when backplane power is present to the module
FAQs
-
What is the IC200MDL750?
+It is a VersaMax 32-point, 12/24VDC positive logic discrete output module. -
What is the maximum load current?
+The module handles a maximum of 0.5A per point. -
Does it support channel isolation?
+No, it does not support isolated individual channels. However, it can isolate each of the two groups of 16 points.
