Technical specifications for IC200PWR102
-
Product ModelIC200PWR102
-
Product ParametersPower supply module
-
Tariff Code8537101190
-
Country of originUSA
-
Place of shipmentXiamen, China
-
Estimated Shipping Size12.8x5x5cm
-
ManufacturerGeneral Electric
-
Weight0.14 kg
-
Input Power27VA
-
Frequency47 to 63Hz
-
Holdup Time20ms
-
Output Voltage5VDC, 3.3 VDC
-
ProtectionShort circuit, overload
-
Total1.5A maximum
-
3.3VDC Output1.0A maximum
Description
IC200PWR102
POWER SUPPLY MODULE
120/240 VAC INPUT
27 VA INPUT POWER
5 VDC MAX OUTPUT
EXPANDED 3.3 VDC
1.5 AMP MAX OUTPUT
REPLACEMENT FOR IC200PWR101
POWER SUPPLY MODULE
120/240 VAC INPUT
27 VA INPUT POWER
5 VDC MAX OUTPUT
EXPANDED 3.3 VDC
1.5 AMP MAX OUTPUT
REPLACEMENT FOR IC200PWR101
Revisions
Revision Part #
Also known as
Information
Overview
Manuals
Technical notes
Product Applications
Wiring & Grounding
Features:
- 120/240VAC Expanded 3.3V Power Supply
- Dual Voltage Output Capability
- High Current Output Capacity
- Primary Station Power Supply
The IC200PWR102 is an expanded power supply module that is part of the VersaMax product family. This module is currently manufactured by Emerson Automation, formerly by GE Intelligent Platforms (GE IP). It is mainly used to deliver power to VersaMax backplane which is utilized by the installed modules to power up individual internal circuitries for operation. The IC200PWR102 is operable when connected to an external power supply that delivers 85-132 VAC (120 VAC, nominal) and 176 - 264 VAC (240 VAC, nominal), input frequency range of 47-63 Hz, and input power of 27 VA.
The IC200PWR102 GE Power supply module may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
GE IC200PWR102 Power supply module Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
120/240VAC Expanded 3.3 Power Supply IC200PWR102 provides backplane power forCPU, NIU, and I/O modules. It supplies up to 1.5 Amps output current via 3.3 Volt and 5Volt outputs, with up to 1.0 Amp on the 3.3V output. Module backplane currentconsumption is summarized in appendix C.
When mounted on the CPU or NIU module, this power supply serves as the main powersupply for the station. It can also be used as a supplemental power supply when mountedon a Power Supply Booster Carrier. Refer to the Power Supply Booster Carrier section ofchapter 4 for more information
- Energy & Power Generation:Powers GE Speedtronic Mark II turbine control
- Water & Wastewater:Powers PLCs for pump/flow/environmental monitoring
- Manufacturing & Automotive:CNC, conveyors & material handling for high-volume production
- Oil & Gas/Petrochemical:Class I Div 2 certified for hazardous process control
- HVAC & Building Automation:Backplane power for large-scale heating/cooling/ventilation
- Automotive & Material Handling:Powers motors, gearboxes & clutch brakes on assembly lines
- Industrial Machinery:Main power for PLC stations in chemical, food & textile factories
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Terminal Connections: Connect the AC Line (L) and Neutral (N) to the designated input terminals.
System Grounding: For safety and noise reduction, the system must have a common ground potential. Ensure the frame ground is properly connected during installation.
Safety Warning: Always turn off power before replacing or wiring modules in hazardous locations to prevent explosion hazards (Class I Div 2).
FAQs
-
What is IC200PWR102?
+The GE Fanuc IC200PWR102 is a VersaMax 120/240VAC Expanded 3.3V Power Supply designed to provide backplane power (5 VDC and 3.3 VDC) for CPUs, NIUs, and I/O module -
What is the input voltage for the IC200PWR102?
+It supports both 120 VAC (nominal) and 240 VAC (nominal), depending on the jumper configuration. -
Can the IC200PWR102 be used as a secondary power supply?
+Yes, it can be mounted to a Power Supply Booster Carrier to serve as a supplemental or secondary power supply. -
What is the operating temperature range of IC200PWR102?
+The operating temperature range of this module is 0°C to 60°C (32°F to 140°F). -
What is the difference between the IC200PWR102 and the IC200PWR101?
+The IC200PWR102 serves as a direct replacement for the IC200PWR101 and offers expanded power capacity.
