900B08-0202
Need Help? Contact US!
Call us: +86-18020776786
Proper, Ready.
Delivery time
Please indicate your delivery time
Product Information
Product Describe
Analog Outputs 0 to 20mA, 8 Ch
OUTPUT MODULE
ANALOG
8 CHANNEL
221 MA MAX @ 5 VDC
345 MA MAX @ 24 VDC
OUTPUT MODULE
ANALOG
8 CHANNEL
221 MA MAX @ 5 VDC
345 MA MAX @ 24 VDC
Specifications
-
Product Model900B08-0202
-
Product ParametersAnalog Output Module
-
Tariff Code8537101190
-
Country of originUSA
-
Place of shipmentXiamen, China
-
Estimated Shipping Size13.4x3.3x5.4cm
-
ManufacturerHoneywell
-
Weight0.2 kg
-
Outputs per module4 (isolated)
-
Current0 to 21.8 mA, range selectable
-
Load resistance750 ohms max
-
Galvanic Isolation500VDC Channel to Channel
-
Galvanic Isolation from logic600 VDC
-
Accuracy0.1% full scale at reference conditions
-
Modules per rack10 max, up to 12 with product ambient temperature de-rating
-
Minimum current sensing> 3.5 mA per output
-
D/A Resolution12 bits
-
Power Supply Loading5V ; 40mA max24V ; 200mA max
-
Factory New
These are new and current items that are procured from the manufacturer. -
New No Package
These parts are new. They have not been used, but their original packaging is no longer available. -
New In Opened Package
These parts are new. They have not been used, but their original packaging has been opened or the packaging is significantly aged. -
New In Sealed Package
Parts are new. They have not been used and still have their original package seal intact. -
New in Original Package
These parts are new. The packages were not originally sealed by their original manufacturer.
Warranty Period & Disclaimer
Amikon is not an authorized distributor unless otherwise specified, representative, or affiliate of the manufacturer of this product. All trademarks and documents are the property of their respective owners and are provided for identification and informational.
FAQs
-
What is the 900B08-0202？+The Honeywell 900B08-0202 is an 8-channel analog output module (0-20mA) designed for the ControlEdge HC900 Controller and ControlEdge PLC platforms.
-
What is the primary function of the 900B08-0202?+It is a 8-channel, isolated analog output module designed to provide 0 to 20mA (or 4-20mA) signals in the HC900 Process & Safety Controller or ControlEdge PLC systems.
-
How are the channels of 900B08-0202 isolated?+This module provides 500VDC electrical isolation for two sets of outputs: channels 1-4 and channels 5-8.
-
What type of terminal blocks does 900B08-0202 use?+It uses 20-hole screw terminal blocks, available in both fence and European styles, which usually need to be ordered separately.
-
How many modules can be installed per rack?+A maximum of 4 modules can be used per backplane rack when powered from internal 24V backplane power.
Get a quick price fo 900B08-0202
whatsapp
Inquiry
Our customer support team is always on call to help you with any form of consultation. You can inquire by phone or use us on the product page and "contact us" View Amikon terms and conditions
- Product Applications
- Automated control for oil refineries and chemical plants.
- Used in boiler control systems, water treatment facilities and small power generation units.
- For sterilization tanks in pharmaceutical factories and environmental control in clean rooms.
- For gas ratio control and material flow regulation in heating furnaces and sintering equipment.
- What happens next
- Get the quote now Write Email to INFO@AMIKON.CNEmail confirmation You will get an email confirming that we have received your enquiry.Dedicated Account Manager One of our team will be in touch to confirm your part(s) specification and condition.Your quote You will receive a comprehensive quote tailored to your specific needs.Need Moore Help? Get fast and efficient help from our experienced sales or customer service teams.
- Delivery and payment
- Delivery
Logistic partners UPS, FedEx and DHL
International delivery available
Same day dispatch from warehouse inventory
Warranty
All parts new original are covered by Amikon 12 month warranty
Returns
No hassle returns policy
Dedicated customer support team
Payment options
We accept Bank transfers and the following methods of payment:
For more information, please visit our dedicated payments page.
- Why Choose Amikon Limited?
When it comes to industrial automation, reliability, speed, and trust matter. At Amikon Limited, we go beyond just supplying parts — we deliver confidence.
- ● Extensive Inventory Reach: Nearly 1 million automation parts at your fingertips, including legacy and obsolete models.
- ● 20+ Years of Expertise: Trusted by engineers, project managers and government companies worldwide for our professional service.
- ● Quality You Can Trust: Each unit is strictly inspected by the warehouse staff to ensure product quality
- ● Fast Global Shipping: We help you minimize downtime with express logistics worldwide.
- ● 1-Year Warranty Available: Peace of mind with every purchase backed by one year warranty guarantee.
Whether you're maintaining legacy systems or building future-ready projects, Amikon Limited is your dependable partner in precision and performance.
Product
MORE INFORMATION
Overview
Manuals
Technical notes
Signal & Safety Protection
Features:
- Eight 0-21mA outputs
- 4-channel group isolation
- User-defined failsafe value
- Rate of change limit per output
A green blinking status LED on the module indicates whenthe module is being scanned. A red status LED whenmodule or channel diagnostics exist. A user specifiedfailsafe value is supported to allow predictable operation inthe event communication between the module and thecontroller is interrupted.
The 900B08-0202 Honeywell Analog Output Module may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
Honeywell 900B08-0202 Analog Output Module Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
A green blinking status LED on the module indicates whenthe module is being scanned. A red status LED whenmodule or channel diagnostics exist. A user specifiedfailsafe value is supported to allow predictable operation inthe event communication between the module and thecontroller is interrupted.
Outputs are updated synchronous with control execution. Auser-specified rate of change limit may be applied to eachoutput when needed. Requires Euro style 36-terminalterminal block.
A green blinking status LED on the module indicates whenthe module is being scanned. A red status LED whenmodule or channel diagnostics exist. A user specifiedfailsafe value is supported to allow predictable operation inthe event communication between the module and thecontroller is interrupted.
Outputs are updated synchronous with control execution. Auser-specified rate of change limit may be applied to eachoutput when needed. Requires Euro style 36-terminalterminal block.
