Technical specifications for 8C-PAINA1 51454470-175
-
Product Model8C-PAINA1 51454470-175
-
Spare Model51454470-175
-
Product ParametersAnalog Input Module
-
Tariff Code8537101190
-
Country of originUSA
-
Place of shipmentXiamen, China
-
In stock1 unit
-
Estimated Shipping Size6x15.2x14.3cm
-
ManufacturerHoneywell
-
Weight0.3 kg
-
Input Channels16 Channels
-
Voltage Rating24 VDC
-
Module current rating105m A
-
Operating Temperature0 to 60 ℃
-
Storage temperature-40 to 85 ℃
-
A/D Converter Resolution16 bits
-
Input Range4-20 mA (through 250 Ω)
-
Normal Mode Rejection Ratio, at 60 Hz19 dB
-
Crosstalk, dc to 60 Hz-60 dB
-
Input Scan Rate50 ms
-
Maximum Input Voltage± 30 Volts
-
Galvanic Isolation1000 VAC RMS or ±1000 VDC
Description
The HONEYWELL 8C-PAINA1 is an Analog Input – Single Ended module for the Honeywell Series 8 I/O system, providing 16 channels of analog input capability for process control applications. The 8C-PAINA1 accepts current inputs from transmitters and sensing devices, typically supporting 4–20 mA DC inputs for traditional field devices such as process transmitters, delivering reliable and accurate analog signal acquisition for the distributed control system.
The 8C-PAINA1 incorporates extensive self diagnostics to continuously monitor module health, channel integrity, and signal validity, ensuring dependable operation in demanding industrial environments. The 8C-PAINA1 supports optional redundancy, allowing a second IOM to be added directly to the IOTA without any external cabling or redundancy control devices, thereby enhancing system availability for critical process control applications.
The 8C-PAINA1 provides a fast loop scan capability, ensuring that process variables are updated rapidly to support responsive control strategies. Power flexibility is a key design feature of the 8C-PAINA1, with internal or external field power selection available to accommodate diverse installation requirements. The 8C-PAINA1 includes on-board excitation power, eliminating the need for extra power supplies to power field devices and the associated craft-wired marshalling, which reduces overall installation complexity and cost.
The 8C-PAINA1 incorporates extensive self diagnostics to continuously monitor module health, channel integrity, and signal validity, ensuring dependable operation in demanding industrial environments. The 8C-PAINA1 supports optional redundancy, allowing a second IOM to be added directly to the IOTA without any external cabling or redundancy control devices, thereby enhancing system availability for critical process control applications.
The 8C-PAINA1 provides a fast loop scan capability, ensuring that process variables are updated rapidly to support responsive control strategies. Power flexibility is a key design feature of the 8C-PAINA1, with internal or external field power selection available to accommodate diverse installation requirements. The 8C-PAINA1 includes on-board excitation power, eliminating the need for extra power supplies to power field devices and the associated craft-wired marshalling, which reduces overall installation complexity and cost.
Information
Overview
Manuals
Application Notes
Product Applications
Field Connections & Wiring
Features:
- 16-Point Single-Ended Analog Input
- Extensive Self Diagnostics
- Optional Redundancy
- Fast Loop Scan
- Internal or External Field Power Selection with On-Board Excitation
Each of the 16 channels is single-ended and interfaces with field devices through a 250 Ω precision resistor. The module employs a 16-bit A/D converter with a hardware accuracy of ±0.075% of full-scale at 23.5°C ± 2°C, and ±0.15% of full-scale across the full operating temperature range of 0°C to 60°C. The input scan rate is 50 ms per channel. A single-pole RC filter provides -3 dB attenuation at 6.5 Hz with 19 dB normal mode rejection at 60 Hz, and channel-to-channel crosstalk is rated at -60 dB from DC to 60 Hz.
The 8C-PAINA1 51454470-175 HONEYWELL Analog Input – Single Ended may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
HONEYWELL 8C-PAINA1 51454470-175 Analog Input – Single Ended Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The 8C-PAINA1 draws 105 mA at 24 VDC and includes onboard excitation power, eliminating the need for external marshalling power supplies. It supports module removal and insertion under power for online maintenance.
The module is conformal coated (G3-rated) for protection in corrosive or humid industrial environments. It mounts on Series 8 I/O Termination Assemblies (IOTA), including the 8C-TAIXA1 (6-inch non-redundant), 8C-TAIXB1 (12-inch redundant), and their uncoated equivalents.
Environmental ratings include an operating temperature range of 0°C to +60°C, storage temperatures from -40°C to +85°C, and 0% to 95% non-condensing relative humidity. The module withstands vibration of 5 g from 10 Hz to 2 kHz and shock of 50 g at 11 ms.
- Power Generation: Monitors generator trips, turbine interlocks, breaker openings, and ESD triggers with millisecond precision
- Oil & Gas: Logs safety valve states, gas alarms, compressor trips, and pressure switches in refineries/offshore platforms
- Chemical Process: Tracks batch reactor states, interlocks, and valve positions to prevent thermal runaway
- Metals/Mining: Manages safety interlocks and E-stops across kilns, conveyors, and melting furnaces
- Water/Wastewater: Supervises critical alarms, pump failures, and isolation valves across utility networks
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Terminal Blocks: The Series 8 IOTA utilizes two-level "detachable" terminal blocks to land field wiring without needing complex marshalling panels.
Channel Configuration: The module features 32 discrete input channels.Power Modes: You can configure the module to use internal field power (on-board excitation) or external field power.
Cable Requirements: Use shielded twisted pair (STP) cables. Route signal cables away from areas with high Electromagnetic Interference (EMI) or Radio Frequency Interference (RFI).
Alternative Names
8C-PAINA1 51454470-I75
8C-PAINA1 5145447O-175
8C-PAINA1 51454A70-175
8C-PAINA1 5I454470-175
8C-PAINAI 51454470-175
8C-PA1NA1 51454470-175
BC-PAINA1 51454470-175
8C PAINA1 51454470 175
8C PAINA1 51454470 I75
8C PAINA1 5145447O 175
8C PAINA1 51454A70 175
8C PAINA1 51454470 175
8C PAINAI 51454470 175
8C PA1NA1 51454470 175
Technical notes
The 8C-PAINA1 features galvanic isolation, providing electrical separation between the system and field sides to protect control electronics from field-side electrical disturbances and ensuring safe, reliable signal transmission. As part of the Series 8 I/O family, the 8C-PAINA1 benefits from an innovative design that combines the I/O Module and field terminations in the same area, with the IOM plugging into the IOTA to eliminate the need for a separate chassis. The 8C-PAINA1 utilizes two-level detachable terminals for landing field wiring, providing easier plant installation and maintenance.
FAQs
-
What is the 8C-PAINA1?
+The Honeywell 8C-PAINA1 (51454470-175) is a 16-channel, non-HART analog input module for the Honeywell Series 8 I/O platform used in Experion PKS and Experion LX systems -
Does it power the field devices directly?
+Yes, it supplies transmitter field power through its associated I/O Termination Assembly (IOTA). This built-in excitation power eliminates the need to wire external power supplies or marshalling components. -
Does the 8C-PAINA1 module support HART communication?
+No, the 8C-PAINA1 is a non-HART analog input module. For HART-compatible analog inputs, users typically use the 8C-PAIHA1 module instead. -
Can modules be removed or inserted while powered?
+Yes, module removal and insertion under power (hot-swapping) is supported. This allows you to replace or maintain the module without needing to shut down the entire control system
