- 900B16-0001
· Product image is representative; revision or series may vary. Contact us to request a specific version.
Require for Quote:
Need more help? You may also find the answer in our FAQ section
Warranty Policy
We provide 1 year warranty for all remaining parts.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
Return Notice
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
How to order?
We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online.
If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.
Parts Availability
Amikon offers a wide range of components, products and services related to industrial automation. We have a large surplus of stocks and are also distributors of new products from a variety of quality manufacturers.
Technical specifications for 900B16-0001
-
Product Model900B16-0001
-
Product ParametersAnalog Output Module
-
Tariff Code8537101190
-
Country of originUSA
-
Place of shipmentXiamen, China
-
Estimated Shipping Size13.3x15.2x3.2cm
-
ManufacturerHoneywell
-
Weight0.25 kg
-
Outputs per module16, isolated in 4 groups of 4 outputs
-
Current0 to 21.0 mA
-
Load resistance750 ohms max
-
Galvanic Isolation500VDC group to group
-
Galvanic Isolationfrom logic500 VDC
-
Accuracy0.1% full scale at reference conditions
-
Modules per rack2 max when powered from internal 24V backplane powe
-
D/A Resolution13+ bits
-
Power SupplyLoading5V ; 350 mA max24V ; 700 mA max
-
Terminal Block36 Position – Euro style
Description
900B160001
MODULE
PLC MODULE
16 CHANNEL
ANALOG OUTPUT
MODULE
PLC MODULE
16 CHANNEL
ANALOG OUTPUT
Information
Overview
Manuals
Technical notes
Product Applications
Terminal Blocks and Hardware Keying
Features:
- 16 Scalable 0–21.0 mA Current Output Channels
- 500 VDC Galvanic Isolation
- High 13+ Bit Resolution with ±0.1% Full Scale Accuracy
- User-Defined Failsafe Values & Rate-of-Change Limiting
- Ultra-Compact IP20 Design with Quick-Commissioning Application Macros
- Versatile I/O & Fieldbus Expandability
The 900B16-0001 part number follows Honeywell's HC900 ordering convention: 900B designates an analog output module; 16 indicates 16 channels; and 0001 specifies the standard 0–21.0 mA current output variant with Euro-style terminal block compatibility. The module occupies a single slot in the HC900 rack and connects to field wiring via a 36-position Euro-style terminal block (Model 900TCK-0001), which provides robust, vibration-resistant screw clamp connections for up to 16 current loop circuits plus power and ground
The 900B16-0001 Honeywell Analog Output Module may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
Honeywell 900B16-0001 Analog Output Module Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Each of the 16 output channels is independently configurable to any current span within the 0 to 21.0 mA range. While the industry-standard 4–20 mA range is most commonly used, the extended 0–21.0 mA capability allows for over-range and under-range signaling—for example, a 3.8 mA signal can indicate a sensor fault, while a 21.0 mA signal can indicate an out-of-range process condition. This flexibility eliminates the need for external signal conditioners and simplifies alarm strategy implementation. The module supports a maximum load resistance of 750 Ω per channel, accommodating long cable runs and high-impedance actuator coils without signal degradation.
- Plastic & Polymer Extruders:Screw-drive motors & barrel-zone induction heaters
- Extrusion Coating Systems:Die lip position signals for thickness consistency
- Pulp & Paper Mills:Multi-drive motor arrays for paper tensile strength
- Pipeline Pumping Stations:Throttle control valves & variable speed line pumps
- Water Treatment Centrifuges:Primary chemical dosing pumps for pH/additive control
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Hardware Keying: Remove the matching plastic tab combinations on the terminal block before mating it to the module. This hardware keying stops low-voltage analog cards from being accidentally connected to high-voltage digital terminal blocks.Disconnecting Field Power: While the module itself is hot-swappable, external loop or field instrumentation power must be switched off before unplugging the terminal block assembly.
FAQs
-
What is the 900B16-0001?
+The 900B16-0001 is a 16-channel Analog Output (AO) module designed for the Honeywell HC900 Process & Safety System. It is typically used for 0 to 20mA output signals. -
Which controllers are compatible with this card?
+The module integrates exclusively with the legacy Honeywell ControlEdge HC900 process and safety controller racks. -
What is the function of the Honeywell 900B16-0001?
+It delivers 16 channels of analog current output. Each channel is software-configurable within a 0 to 21.0 mA range to accommodate standard 4–20 mA industrial field devices. -
How are the output channels isolated?
+The card features 2500 Vrms galvanic isolation to protect internal system logic from field surges. The 16 channels are divided into four separate isolated groups (4 channels per group) to balance high density with robust electrical isolation.
