FS-TSGAS-1624
Need Help? Contact US!
Call us: +86-18020776786
Proper, Ready.
Delivery time
Please indicate your delivery time
Product Information
Product Describe
Digital Input Field Termination Assembly
Safe gas / flame detector input FTA
0-20 mA, 16 channels
Power supply distribution
to each transmitter (500 mAT fused)
Safe gas / flame detector input FTA
0-20 mA, 16 channels
Power supply distribution
to each transmitter (500 mAT fused)
Technical specifications for FS-TSGAS-1624
-
Product ModelFS-TSGAS-1624
-
Product ParametersDigital Input Field Termination Assembly
-
Tariff Code8537101190
-
Country of originUSA
-
Place of shipmentXiamen, China
-
Estimated Shipping Size17.1x7x5.8cm
-
ManufacturerHoneywell
-
Weight0.22 kg
-
ApprovalsCE, TUV, UL, CSA, FM
-
Number of inputchannels16
-
Power requirements24 V DC external, 3 mA
-
Input current0-25 mA
-
Input resistance500 Ω (± 5%)
-
Output voltage0-4 V DC
-
Accuracy0.1%
-
Fuse rating500 mA
-
Voltage rating AC250 V
-
Voltage rating DC300 V
-
Factory New
These are new and current items that are procured from the manufacturer. -
New No Package
These parts are new. They have not been used, but their original packaging is no longer available. -
New In Opened Package
These parts are new. They have not been used, but their original packaging has been opened or the packaging is significantly aged. -
New In Sealed Package
Parts are new. They have not been used and still have their original package seal intact. -
New in Original Package
These parts are new. The packages were not originally sealed by their original manufacturer.
Warranty Period & Disclaimer
Amikon is not an authorized distributor unless otherwise specified, representative, or affiliate of the manufacturer of this product. All trademarks and documents are the property of their respective owners and are provided for identification and informational.
FAQs
-
What is FS-TSGAS-1624?+The Honeywell FS-TSGAS-1624 (or FC-TSGAS-1624) is a Fail-Safe Gas-Flame Detector Input Field Termination Assembly (FTA) designed for use with the Honeywell Safety Manager system.
-
What is the function of the FS-TSGAS-1624?+It is a 16-channel field termination assembly used to connect analog inputs (0–20 mA or 4–20 mA) from field sensors, such as gas or flame detectors, to the safe controller.
-
What systems is this compatible with?+It is designed for the Honeywell Safety Manager system and specifically acts as an interface to the SAI-1620m analog input module.
-
What happens if the module fails?+The FS (Fail-Safe) designation indicates that it is designed to fail in a safe state, maintaining the integrity of the safety system.
-
How many input channels does it support?+The module supports 16 analog input channels (0–20 mA) with a common 0 V reference.
Get a quick price fo FS-TSGAS-1624
whatsapp
Inquiry
Our customer support team is always on call to help you with any form of consultation. You can inquire by phone or use us on the product page and "contact us" View Amikon terms and conditions
Product
MORE INFORMATION
Overview
Manuals
Technical notes
Product Applications
Installation & Mounting Instructions
Features:
- Fail-safe Gas -Flame detector inputFTA
- 0 - 20 mA, 16 channels
- theinterface between gas/ flame detector
The field termination assembly module FS-TSGAS-1624 is theinterface between gas/ flame detectors in the field and the fail-safehigh-density analog input module 10105/2/1 in the FSC system.The FS-TSGAS-1624 module has sixteen analog input channels whichmay be used for both safety-related and non-safety-relatedapplications. The FS-TSGAS-1624 module uses a SIC-C-12 systeminterconnection cable to transfer the 16 input signals to a (redundantpair of) 10105/2/1 module(s).The FTA module has a universal snap-in facility for standard DIN ENrails, and screw terminals for connection of power supply, ground andfield wiring.
The FS-TSGAS-1624 Honeywell Fail-safe Gas -Flame detector inputFTA may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
Honeywell FS-TSGAS-1624 Fail-safe Gas -Flame detector inputFTA Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The FS-TSGAS-1624 module has three main functions:• linear direct conversion of 0(4)-20 mA DC field signals to thesignal levels of the fail-safe high-density analog input module10105/2/1,
power supply distribution to each transmitter (500 mAT fused),
enable monitoring of the external power connected to the FSTSGAS-1624 module.
The input circuit of each channel consists of a high-precision resistorwhich converts the input current (0 to 20 mAT) to the input voltagefor the high-density analog input module 10105/2/1. The power to theanalog transmitter is fused (500 mAT) per channel. Each analog inputhas its own terminal for the field cable shield.
- Emergency Shutdown Systems (ESD):Triggers facility shutdown on hazardous gas/flame detection
- Fire and Gas (F&G) Systems:Input interface for combustible/toxic gas & flame monitoring
- Critical Process Protection:Processes 0-20 mA safety signals with Honeywell Safety Manager
- Turbomachinery:Control/protection loops for large turbines & compressors
- Pipeline Infrastructure:Leak monitoring across extensive pipeline networks
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Rail Mounting: The module features a universal snap-in provision for standard DIN EN rails (TS32 or TS35 × 7.5).
Space Requirements: Ensure a used rail length of at least 226 mm (8.90 in) to accommodate the module's dimensions.
Orientation: Mount the FTA securely to prevent vibration, as violent shaking can damage internal circuitry.
