- TPC1061TI
In Stock
Ships by Sunday, August 9
Fast Shipping Available
· Product image is representative; revision or series may vary. Contact us to request a specific version.
We provide 1 year warranty for all remaining parts.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online.
If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.
Amikon offers a wide range of components, products and services related to industrial automation. We have a large surplus of stocks and are also distributors of new products from a variety of quality manufacturers.
Technical specifications for TPC1061TI
-
Product ModelTPC1061TI
-
Product ParametersTPC Human Machine Interface HMI
-
Tariff Code8537101190
-
Country of originUSA
-
Place of shipmentXiamen, China
-
In stock1 unit
-
Estimated Shipping Size27.3x19.2x4cm
-
ManufacturerMCGS
-
Weight1 kg
-
Resolution1024×600
-
The brightness of the LCD screen200cd / ㎡
-
Touch screenResistive
-
Power supply24VDC
-
Rated Power5W
-
CPU motherboardARM CPU, 600MHz
-
Memory128M
-
Storage devices128M FLASH
-
Operating Temperature0 ℃ to 45 ℃
-
Operating Humidity5% to 90%
-
Vibration frequency10-57Hz 57-150Hz
Description
The MCGS TPC1061TI Human Machine Interface (HMI) is a 10.2-inch industrial operator panel designed to provide intuitive visualization and control for industrial automation systems. Powered by a 600 MHz ARM Cortex-A8 processor, it features a 1024 × 600 TFT LCD, 65,536-color display, 128 MB RAM, and 128 MB Flash memory, delivering responsive graphics and reliable operation for machine monitoring and process control. Integrated 10/100 Mbps Ethernet, RS-232, RS-485, and USB Host/Client interfaces allow seamless communication with PLCs and other industrial devices.
The MCGS TPC1061TI Human Machine Interface (HMI) operates from a 24 VDC ±20% power supply with a typical power consumption of 5.5 W. Its IP65-rated front panel, compact 274 × 193 mm design, and panel-mount construction make it suitable for demanding industrial environments. Running the MCGS Embedded Runtime, the terminal supports machine visualization, alarm management, trend display, data logging, and communication with a wide range of PLC platforms, making it an effective solution for modern industrial automation systems.
The MCGS TPC1061TI Human Machine Interface (HMI) operates from a 24 VDC ±20% power supply with a typical power consumption of 5.5 W. Its IP65-rated front panel, compact 274 × 193 mm design, and panel-mount construction make it suitable for demanding industrial environments. Running the MCGS Embedded Runtime, the terminal supports machine visualization, alarm management, trend display, data logging, and communication with a wide range of PLC platforms, making it an effective solution for modern industrial automation systems.
Information
Overview
Manuals
Application Notes
Product Applications
Data & Communication Ports
Features:
- 10.1-Inch TFT Touch Screen Display
- High-Performance Embedded Processor
- Multiple Communication Interfaces
- Wide Operating Temperature Range
The TPC1061TI features a 10.1-inch TFT LCD display with high resolution, delivering clear and vivid visualization of process data, alarms, trends, and operator interfaces. The touch screen of the TPC1061TI supports resistive touch technology, enabling precise input even when operators are wearing gloves. The display panel of the TPC1061TI is designed for continuous industrial operation with excellent brightness and contrast characteristics.
The TPC1061TI MCGS Human Machine Interface may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
MCGS TPC1061TI Human Machine Interface Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The TPC1061TI supports advanced HMI functionality including real-time data display, historical trend analysis, alarm management with priority levels, recipe management for batch processes, and user access control with multi-level password protection. The TPC1061TI can store historical data locally and supports data export for further analysis. The TPC1061TI also supports remote monitoring capabilities when connected to networks, enabling centralized management of distributed automation systems.
The TPC1061TI is designed for easy installation and maintenance. The TPC1061TI supports panel mounting with standard cutout dimensions, and the compact design of the TPC1061TI optimizes space utilization in control cabinets. The TPC1061TI operates from a 24V DC power supply, which is standard in industrial automation systems. The low power consumption of the TPC1061TI contributes to energy-efficient operation.
- Factory Automation: Central console for assembly lines, robotics, and conveyors to track throughput
- Packaging: Controls sealing, filling, and labeling cycles on high-speed packaging equipment
- CNC/Metalworking: Graphical interface for inputting programs and overseeing tool status
- HVAC: Monitors temperature, air pressure, and energy consumption in large networks
- Water/Wastewater: Integrates with PLCs for purification, filtration, dosing, and valve sequencing
- Textile/Printing: Manages motor sync, tension, and patterns on presses and weaving looms
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
COM1 (RS-232): Configured via a standard DB9 male terminal. Typically used to communicate with classic PLCs or for localized debugging protocols.
COM2 (RS-485): Utilized for multi-drop networks, standard Modbus RTU, or extended runs to variable frequency drives (VFDs) and controllers. Ensure correct wiring matching for A (+) and B (-) terminals.
Ethernet (10/100M): RJ45 port used for modern networked automation (such as communicating with a Siemens S7-200 SMART or Omron PLC over TCP/IP subnets).
USB Ports: Features 1 USB Host port (for inserting FAT32 formatted flash drives to perform system flashing, backup, or data logging tasks) and 1 USB Client port (for firmware uploads via PC software).
Alternative Names
TPC1061T1
TPC106ITI
TPC1O61TI
TPCI061TI
Technical notes
The TPC1061TI is built to withstand demanding industrial conditions. The TPC1061TI features a robust aluminum alloy housing that provides excellent heat dissipation and mechanical durability. The front panel of the TPC1061TI is rated IP65 for protection against dust and water jets, making the TPC1061TI suitable for installation in factory floor environments where exposure to moisture and particulates is common. The TPC1061TI operates reliably in ambient temperatures from 0°C to +50°C.
FAQs
-
What is the TPC1061Ti ?
+The MCGS TPC1061Ti is a 10.2-inch industrial Human-Machine Interface (HMI) widely used in automated control and monitoring systems. -
How do I calibrate an unresponsive touch screen?
+If the touch screen becomes unresponsive or misaligned, navigate to the Start Properties screen and wait for 30 seconds. The system will automatically launch the calibration wizard. Use a stylus or finger to press and hold the center of the crosshair until the cursor moves to the next point. -
How do I clean and maintain the TPC1061Ti?
+Use a soft, lint-free cloth lightly dampened with water or a mild, non-abrasive cleaner. Never use harsh chemicals or pour liquid directly into the HMI openings. Ensure the operating environment stays within the temperature range of 0℃ to 45℃. -
Which programming software does this HMI use?
+It uses the proprietary MCGS Configuration Software ecosystem (such as MCGS Embedded version). This platform offers built-in tools for real-time databases, object animation, and graphical system layout.
