The MVI56-MCMR is a Modbus Master/Slave module for ControlLogix, optimized for remote rack applications (ControlNet) by using a reduced 42-word I/O mapping.

How do I prevent data from resetting to 0 during a power loss?

You can use the Initialize Input Image parameter to cache values from the processor so they are not reset to zero during a module reset or power loss.

How do I set the serial port (RS-232/422/485)?

Jumpers are located at the bottom of the module labeled COM1, COM2, and Setup, allowing you to select the physical standard.

What is the pass-thru difference?

While the MCM supports pass-through for mapping read/write commands, the MCMR requires reading from one address range and writing to another if configured as a slave.

How to configure the module?

The MVI56(E)-MCMR is configured via ProSoft Configuration Builder (PCB) and uses ladder logic Add-On Instructions (AOI) for integration into RSLogix 5000.

Get Parts Quote

Name

Company *

Phone *

Email *

Address

City

State / Province / Region

Zipcode

Country

Quantity *

Part Number *

Manufacturer

Preferred Condition

Additional Information

Cancel

MVI56-MCMR

Name: MVI56-MCMR
Brand: ProSoft
SKU: MVI56MCMR
Availability: InStock

Call us: +86-18020776786

Delivery time
Please indicate your delivery time

Product image is representative; revision or series may vary. Contact us to request a specific version.

Product Information

Product Describe

MVI56MCMR
MODBUS COMMUNICATION MODULE
CONTROLLOGIX
REDUCED DATA BLOCK
5-24 VDC
ETHERNET/IP
CONTROLNET

Technical specifications for MVI56-MCMR

Product Model

MVI56-MCMR
Spare Model

MVI56MCMR
Product Parameters

Modbus Master/Slave Remote Chassis
Tariff Code

8537101190
Country of origin

USA
Place of shipment

Xiamen, China
Estimated Shipping Size

3.5x14x14.5cm
Manufacturer

ProSoft
Weight

0.25 kg
Backplane Current at 5 VDC

800 mA
Backplane Current at 24 VDC

3 mA
Minimum Phase Wire Size

1.3 mm²
Slots

1 slot
Rack

Remote rack

Factory New

These are new and current items that are procured from the manufacturer.
New No Package

These parts are new. They have not been used, but their original packaging is no longer available.
New In Opened Package

These parts are new. They have not been used, but their original packaging has been opened or the packaging is significantly aged.
New In Sealed Package

Parts are new. They have not been used and still have their original package seal intact.
New in Original Package

These parts are new. The packages were not originally sealed by their original manufacturer.

Warranty Period & Disclaimer

Amikon is not an authorized distributor unless otherwise specified, representative, or affiliate of the manufacturer of this product. All trademarks and documents are the property of their respective owners and are provided for identification and informational.

FAQs

What is MVI56-MCMR?+

The MVI56-MCMR is a Modbus Master/Slave module for ControlLogix, optimized for remote rack applications (ControlNet) by using a reduced 42-word I/O mapping.
How do I prevent data from resetting to 0 during a power loss?+

You can use the Initialize Input Image parameter to cache values from the processor so they are not reset to zero during a module reset or power loss.
How do I set the serial port (RS-232/422/485)?+

Jumpers are located at the bottom of the module labeled COM1, COM2, and Setup, allowing you to select the physical standard.
What is the pass-thru difference?+

While the MCM supports pass-through for mapping read/write commands, the MCMR requires reading from one address range and writing to another if configured as a slave.
How to configure the module?+

The MVI56(E)-MCMR is configured via ProSoft Configuration Builder (PCB) and uses ladder logic Add-On Instructions (AOI) for integration into RSLogix 5000.

Get a quick price fo MVI56-MCMR

*Quantity

*E-mail

Company

*Mobile

*Content

Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Get a Quote

For more information on how your data is processed and stored by Amikong please read our privacy policy.

Inquiry

Control system parts

Required delivery time

ask

Our customer support team is always on call to help you with any form of consultation. You can inquire by phone or use us on the product page and "contact us" View Amikon terms and conditions

Product

MORE INFORMATION

Overview Manuals Technical notes Product Applications Comparison with Related Models

Features:

Communication module
ControlLogix
Modbus Communication Module with Reduced Data Block

Specific to the ControlLogix series, the MVI56-MCMR serves as a communication module that supports Modbus protocol functionality. It is versatile in its operation, with the ability to function effectively within a temperature spectrum of 0 to 60 °C. This compact module requires installation in one slot of a remote rack.

The module operates with a significant backplane current draw of 800 mA at 5 VDC, while minimal power consumption is noted at just 3 mA when using a 24 VDC supply. The design necessitates a minimum phase wire size of 1.3 mm², ensuring compatibility across various wiring configurations.

For connectivity, the MVI56-MCMR module incorporates LED indicators that assist in providing visual status updates. Additionally, it supports multiple communication interfaces such as RS-232, RS-485, and RS-422, allowing a baud rate range from 110 baud up to 115200 baud, making it adaptable for different networking needs.

The MVI56-MCMR ProSoft Communication Module may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).

ProSoft MVI56-MCMR Communication Module Manuals, Datasheets, Drivers, Link

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

The ProSoft Technology MVI56-MCMR (and enhanced MVI56E-MCMR) is a Modbus Master/Slave module for Rockwell Automation ControlLogix, specifically optimized for remote chassis applications using ControlNet. It uses a reduced 42-word Input/Output image (compared to the 250-word MVI56-MCM) to minimize bandwidth impact, with two configurable serial ports supporting RS-232, 422, and 485

Water and Wastewater: Manages processes by exchanging data between control systems and remote monitoring stations.
Food Processing: Used in automated production lines for monitoring and control.
Oil and Gas: Integration in pipelines and offshore platforms for remote data acquisition.
Mining, Pulp, and Paper: Connects disparate legacy equipment to modern ControlLogix systems in harsh environments.

This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.

Data Block Size: The MVI56-MCM uses a large 250-word input and 248-word output mapping. The MVI56-MCMR

Network Optimization: The MCMR is specifically designed for ControlNet applications. Its smaller I/O size is easier to schedule in RSNetworx and has a lower impact on other remote I/O bandwidth.

Configuration Method: The MCM is typically configured via ladder logic controller tags. The MCMR is configured using an offline file created in ProSoft Configuration Builder (PCB).

Pass-Thru Feature: Only the MCM supports Modbus Pass-Thru, which allows a master to issue Read and Write commands to the same address. On the MCMR, you must use separate address ranges for Read and Write operations.
