MICROLOGIC 6.0 E
Need Help? Contact US!
Call us: +86-18020776786
Proper, Ready.
Delivery time
Please indicate your delivery time
Product Information
Product Describe
MICROLOGIC 6.0 E
control unit Micrologic 6.0 E
Compact NS 630b to 1600 drawout
LSIG protections
control unit Micrologic 6.0 E
Compact NS 630b to 1600 drawout
LSIG protections
Technical specifications for MICROLOGIC 6.0 E
-
Product ModelMICROLOGIC 6.0 E
-
Product ParametersControl unit
-
Tariff Code8537101190
-
Country of originFrance
-
Place of shipmentXiamen, China
-
Estimated Shipping Size30.5x8.5x8.5cm
-
ManufacturerSchneider Electric
-
Weight1.05 kg
-
RangeComPacT
-
Range of productComPacT NS630b...1600 new generation
-
Product or component typeTrip unit
-
Trip unit nameMicroLogic 6.0 E
-
Trip unit technologyElectronic
-
Range compatibilityComPacT NS630b...1600
-
Network frequency50/60 Hz
-
Factory New
These are new and current items that are procured from the manufacturer. -
New No Package
These parts are new. They have not been used, but their original packaging is no longer available. -
New In Opened Package
These parts are new. They have not been used, but their original packaging has been opened or the packaging is significantly aged. -
New In Sealed Package
Parts are new. They have not been used and still have their original package seal intact. -
New in Original Package
These parts are new. The packages were not originally sealed by their original manufacturer.
Warranty Period & Disclaimer
Amikon is not an authorized distributor unless otherwise specified, representative, or affiliate of the manufacturer of this product. All trademarks and documents are the property of their respective owners and are provided for identification and informational.
FAQs
-
What is the Micrologic 6.0 E？+The Schneider Micrologic 6.0 E is an advanced electronic trip unit used primarily in Masterpact and Compact NS circuit breakers
-
Why is the LCD display screen blank?+The internal LCD screen requires an external auxiliary 24V DC power supply to remain operational. If the 24V DC supply is disconnected or lost, the display turns off, though the trip unit will still provide basic circuit protection via internal current transformers.
-
Can I configure the MicroLogic 6.0 E remotely?+Yes. Before integrating the breaker into power monitoring software like Power Monitoring Expert, users can configure settings remotely via a PC using the Schneider Electric Remote Setting Utility (RSU).
-
Is this product brand new?+Yes, SCHNEIDER MICROLOGIC 6.0 E is brand new, original, unused, and factory sealed
Get a quick price fo MICROLOGIC 6.0 E
whatsapp
Inquiry
Our customer support team is always on call to help you with any form of consultation. You can inquire by phone or use us on the product page and "contact us" View Amikon terms and conditions
Product
MORE INFORMATION
Overview
Manuals
Technical notes
Product Applications
Step-by-Step Installation Procedure
Features:
- control unit Micrologic 6.0 E
- LSIG protections
- Masterpact NW drawout
The Micrologic 6.0E Schneider Electric Control unit may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
Schneider Electric Micrologic 6.0E Control unit Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Protection functions are fully adjustable via front-panel dials and digital menus. Long-time protection (L) features adjustable current setting Ir (0.4–1.0 × In) and tripping delay tr (0.5–24 seconds at 6 × Ir), with a 20-minute thermal memory that prevents unnecessary trips during short-term overloads while ensuring protection against sustained overheating. Short-time protection (S) offers adjustable pickup Isd (1.5–10 × Ir) and delay tsd (0–0.4 seconds) with selectable I²t ON/OFF curves for enhanced discrimination with downstream devices. Instantaneous protection (I) provides fixed or adjustable pickup li (2–15 × In) for immediate clearing of high-magnitude short-circuits. Ground-fault protection (G) features adjustable pickup Ig (0.2–1.0 × In for ratings <1250 A; 500–1200 A for ≥1250 A) and delay tg (0.1–0.4 seconds) with I²t ON/OFF options, protecting against earth leakage that could indicate insulation degradation or personnel hazards.
- Thermal Memory Protection:20-min memory prevents overheating during repeated startups
- Ground-Fault Isolation (51G):Breaks on internal fault; prevents chassis electrification
- Overcurrent & Short-Circuit Tuning:LSIG tuning handles inrush; prevents nuisance trips
- Harmonic Distortion Monitoring:Measures VSD harmonics to protect automated systems
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Remove the Accessory Cover: Loosen the structural screws securing the front plastic accessory facade of the circuit breaker frame and pull the cover away.
Disconnect Internal Wiring Blocks: If you are upgrading an older or different style unit, safely pull out the secondary green plug-in wire harnesses (such as the 12-pin background communications connector) located near the top boundary.
Slide Out the Existing Unit: Loosen the dual retention locking screws built into the bottom edges of the old module and carefully slide it outward along its alignment rails.
