Siemens

COMMUNICATION MODULE

INTERFACE MODULE MNI/MBI APACS MNET
Power Supply:24V DC
Operating Temperature:
0°C to 50°C (32°F to 122°F)
Storage Temperature:
-20°C to 70°C (-4°F to 158°F)
Humidity Tolerance:5% to 95% non-condensing
Mounting Type:DIN rail mounted

PCU 50 Panel Control Unit

Electronic control unit

SINUMERIK PCU 50.3B-C
electronic control unit
CM370; 1.5 GHz; 1x 512 MB RAM 24 V DC;
Windows XP Professional for embedded systems

SM421 Digital Input Module

INPUT MODULE
DIGITAL
SIMATIC S7-400
SM 421 INPUT
16 CONTROLLABLE INPUTS
120/230 VAC
12 WATT
80 MA

Terminal Module

Thyristor module

Thyristor module
500 A, 1600 V
Output DC Power Capacity:Up to 800-2400 Amps
Voltage Ratings:400-840V AC
Trigger Level:20 mA max
Isolation Level:4000V rms

IGBT MODULE

Collector-Emitter Voltage: 1200 V or 1700 V
Gate-Emitter Voltage:±20 V (max)
Continuous Collector Current: 25–50 A
Peak Collector Current: 75–100 A
Turn-On Time：50–100 ns
Turn-Off Time：150–300 ns
Operating Temperature: -40°C to +125°C
Storage Temperature: -40°C to +150°C

CPU1215C Compact Unit

Active Line Module

SINAMICS PWB AC FSG 480V 380A

CSM 1277 Compact Switch Module

MM4 Mailbox Module

MEMORY MODULE
SIMADYN D MM4
32 BIT
L- AND C-BUS
2 MB RAM SYSTEM
ERROR SIGNAL OUTPUT

Y-LINK F. CONNECT. OF 1CHANNEL DP-SLAVES

Profibus Bus Unit for IM157 DPV1

TB30 Terminal Board

SINAMICS / SIMOTION
TERMINAL BOARD
TB30 FOR
CONTROL UNIT CU320-X
SIMOTION D4X5-X

Power Module
