- 6SN1123-1AA00-0JA1
In Stock
Ships by Sunday, June 28
Fast Shipping Available
Require for Quote:
Need more help? You may also find the answer in our FAQ section
We provide 1 year warranty for all remaining parts.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online.
If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.
Amikon offers a wide range of components, products and services related to industrial automation. We have a large surplus of stocks and are also distributors of new products from a variety of quality manufacturers.
Technical specifications for 6SN1123-1AA00-0JA1
-
Product Model6SN1123-1AA00-0JA1
-
Product ParametersSIMODRIVE 611 POWER MODULE
-
Tariff Code8537101190
-
Country of originGERMANY
-
Place of shipmentXiamen, China
-
In stock1 unit
-
Estimated Shipping Size15.2x29x50cm
-
ManufacturerSiemens
-
Weight11.35 kg
-
DC Link Voltage600 V DC
-
DC Link Current (Max.)300 A
-
DC Link Capacitance3300 µF
-
Output Frequency0 to 600 Hz
-
Feed Motor (Servo)100 A
-
Main Spindle Motor120 A
-
Operating Temperature0 to 45°C
-
Storage Temperature−25 to +55°C
Description
The SIEMENS 6SN1123-1AA00-0JA1 is a single-axis power module from the SIMODRIVE 611 drive system. It is designed for high-power applications with a maximum DC link current rating of 300 A. The module employs internal cooling, but an addon fan or cooling hose is required to achieve the full rated power output.
The power module operates from a 600 V DC link supplied by a SIMODRIVE 611 infeed or regenerative feedback module. It is rated for feed motors at 100 A and main spindle motors at 120 A. The module provides adjustable pulse frequency with a standard setting of 4 kHz and an output frequency range from 0 to 600 Hz.
The power module operates from a 600 V DC link supplied by a SIMODRIVE 611 infeed or regenerative feedback module. It is rated for feed motors at 100 A and main spindle motors at 120 A. The module provides adjustable pulse frequency with a standard setting of 4 kHz and an output frequency range from 0 to 600 Hz.
Alternative Names
6SNII23-IAA00-0JAI
6SN1123-1AAOO-0JA1
6SNII23-IAAOO-0JAI
6SNII23 IAA00 0JAI
6SN1123 1AAOO OJA1
6SN1123-AA000JA1
Information
Overview
Manuals
Application Notes
Product Applications
Safety & Wiring
Features:
- SIMODRIVE 611 power module
- Single-axis configuration
- 300 A transistor current capacity
- 120 A spindle motor rating
The module supports a rated feed motor current of 100 A and a rated spindle motor current of 120 A, making it suitable for heavy-duty machining centers, milling machines, lathes, grinding equipment, and automated production machinery. A transistor current capacity of 300 A enables the drive to handle dynamic load changes and acceleration demands associated with high-performance motion systems.
The 6SN1123-1AA00-0JA1 Siemens SIMODRIVE 611 Power Module may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
Siemens 6SN1123-1AA00-0JA1 SIMODRIVE 611 Power Module Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The power module operates within the SIMODRIVE 611 architecture and is commonly integrated with Siemens SINUMERIK CNC controllers. Through the common DC bus structure, multiple drive modules can share power resources, improving efficiency and supporting coordinated multi-axis machine operation.
Internal cooling is incorporated into the module design; however, Siemens specifies the use of an additional cooling fan or cooling hose arrangement to ensure proper thermal management under industrial operating conditions.
- Portal/Gantry Mills: Large CNC mills shaping aerospace components and locomotive frames
- Boring Mills (HBM/VBM): Drill large-diameter deep holes into heavy castings
- Multi-Spindle Turning Centers: Production lathes with multiple spindles for automotive parts
- Servo Press Lines: High-tonnage stamping presses forming car body panels
- Decoilers/Levelers/Slitters: Unwind, flatten, and cut steel coils into strips
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Hazardous Voltage Warning: Dangerous residual voltages are still present up to 30 minutes after disconnecting power. Always verify that no hazardous voltages are present using a meter before working on the system.
Motor & Cable Matching: The rated current of the motor must match the drive converter. Size the motor feeder cable cross-section to accommodate the drive's rated current.
Technical notes
It requires a separate SIMODRIVE 611 control unit (such as the 6SN1118 series) for axis control and closed-loop regulation. The module includes integrated protection functions for overcurrent, overvoltage, undervoltage, overtemperature, ground fault, and short-circuit conditions.
FAQs
-
What is the 6SN1123-1AA00-0JA1?
+The Siemens 6SN1123-1AA00-0JA1 is a 1-axis SIMODRIVE 611 power module designed for high-performance industrial CNC and motion control systems -
What is the cooling requirement for this module?
+The module is designed with internal cooling, but an additional add-on fan or hose cooling is required to prevent overheating during operation -
What is the 6SN1123-1AA00-0JA1? What is the primary function of this module?
+It serves as a drive amplifier that manages power delivery and precise closed-loop speed/torque control for AC servo motors or main spindles in complex industrial machines.
