Technical specifications for 6SL3120-1TE31-3AA3
-
Product Model6SL3120-1TE31-3AA3
-
Product ParametersSingle Motor Module
-
Tariff Code8537101190
-
Country of originGermany
-
Place of shipmentXiamen, China
-
In stock1 unit
-
Estimated Shipping Size30.5x45.7x27.9cm
-
ManufacturerSiemens
-
Weight21.3 kg
-
Rated current132A
-
Base load current105A
-
for S6 duty (40%)150A
-
with 600 V DC link voltage71 kW (100) (HP)
-
based on IH57kW (75) (HP)
-
Rated pulse frequency4kHz
-
DC link current158A
-
DC link capacitance2820μF
-
Current requirement1.5A
-
Sound pressure level< 73dB (A)
Description
The Siemens 6SL3120-1TE31-3AA3 is a SINAMICS S120 Single Motor Module for high-performance multi-axis drive systems. The module operates from a DC link voltage of 510 to 720 V DC and delivers a 3-phase 400 V output with a rated output current of 132 A. It is manufactured in the Booksize format and incorporates internal air cooling, making it suitable for installation in compact control cabinets while maintaining efficient thermal management.
The 6SL3120-1TE31-3AA3 operates with a DC link voltage range of 510…720 V DC and provides a rated output current of 132 A at a rated pulse frequency of 4 kHz. The 6SL3120-1TE31-3AA3 has a base load current of 105 A for continuous duty, an S6 duty current of 150 A at 40% duty cycle, and a maximum output current of 210 A for short-term overload conditions. The 6SL3120-1TE31-3AA3 achieves a rated power of 71 kW based on the rated current and 57 kW based on the base load current, with a DC-link current of 158 A for dimensioning external DC connections.
The 6SL3120-1TE31-3AA3 operates with a DC link voltage range of 510…720 V DC and provides a rated output current of 132 A at a rated pulse frequency of 4 kHz. The 6SL3120-1TE31-3AA3 has a base load current of 105 A for continuous duty, an S6 duty current of 150 A at 40% duty cycle, and a maximum output current of 210 A for short-term overload conditions. The 6SL3120-1TE31-3AA3 achieves a rated power of 71 kW based on the rated current and 57 kW based on the base load current, with a DC-link current of 158 A for dimensioning external DC connections.
Information
Overview
Manuals
Application Notes
Product Applications
Mechanical Insertion & Mounting
Features:
- Wide DC Link Voltage Range with High Capacitance
- Integrated Internal Air Cooling with Fan Insert
- Extended Safety Integrated Functions
- DRIVE-CLiQ Communication and Standard Interfaces
The 6SL3120-1TE31-3AA3 includes an integrated DRIVE-CLiQ interface for communication with other components of the SINAMICS S120 drive system. The module supports the optimized pulse pattern and incorporates extended Safety Integrated functions, achieving SIL 2 according to IEC 61508 and Performance Level d (PL d), Category 3 according to EN ISO 13849-1. These functions enable integration into machinery requiring certified functional safety.
The 6SL3120-1TE31-3AA3 SIEMENS SINAMICS S120 drive may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
SIEMENS 6SL3120-1TE31-3AA3 SINAMICS S120 drive Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The 6SL3120-1TE31-3AA3 includes a safe standstill input (enable pulses) for safety-related shutdown, a safe motor brake control with plug-in connector X11 for 24 V DC brake connection, and a temperature sensor input supporting KTY84-130 or PTC thermistors for motor temperature monitoring. The 6SL3120-1TE31-3AA3 supports extended Safety Integrated functions and is certified to SIL 2 according to IEC 61508, PL d according to EN ISO 13849-1, and Category 3 according to EN ISO 13849-1. The 6SL3120-1TE31-3AA3 carries an IP20 / UL open type degree of protection and is certified to CE and cULus standards. The 6SL3120-1TE31-3AA3 supports motor cable lengths up to 100 m shielded and 150 m unshielded, with conductor cross-sections from 2.5…120 mm² at the motor end.
- CNC Machine Tools: Powers heavy-duty milling, turning, and grinding with dynamic axis control and vector torque regulation
- Industrial Robotics: Controls high-payload multi-axis arms requiring fast positioning and functional safety
- Packaging/Textile: Drives synchronized tension lines, high-speed wrapping, and weaving machinery
- Automated Production Lines: Integrated into automotive body shops and assembly plants with high-density booksize layouts
- Material Handling Systems: Controls cranes, conveyors, and ASRS with active regenerative braking support
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Verify clearance: Ensure 80 mm above and 50 mm below the unit for airflow.
Mount unit: Hang the booksize module onto the standard control cabinet mounting panel or DIN profile.
Secure screws: Tighten the lower and upper fastening screws securely to the panel ground.
Install fan: Clip the included fan insert into the bottom of the 132 A module before starting operation.
Alternative Names
6SL3I20-ITE3I-3AA3
6SL312O-1TE31-3AA3
6SL3 120-1TE31-3AA3
Technical notes
The 6SL3120-1TE31-3AA3 requires a 24 V DC electronics power supply with a current demand of maximum 1.50 A, and the 6SL3120-1TE31-3AA3 includes an integrated 24 V DC busbar for connection to adjacent modules. The 6SL3120-1TE31-3AA3 provides three DRIVE-CLiQ sockets for communication and integration into the SINAMICS S120 drive system, and the status of the 6SL3120-1TE31-3AA3 is indicated via two multi-color LEDs on the front panel.
FAQs
-
What are the power ratings?
+Input is DC 600V (operational range 510V to 720V DC), and output is 3-phase AC 400V at 132A (approx. 71 kW). -
What communication interface does it use?
+It features an integrated DRIVE-CLiQ cable interface for reliable data exchange with control units and other SINAMICS S120 components -
Does it support safety functions?
+Yes, it supports extended Safety Integrated functions, achieving SIL 2 (IEC 61508) and PL d, Category 3 (EN ISO 13849-1) compliance. -
What are the environmental constraints?
+The module operates from 0°C to +40°C at full capacity (up to +55°C with power derating) and at altitudes up to 1000 meters without derating.
