Technical specifications for 9468/32-08-11
-
Product Model9468/32-08-11
-
Product ParametersANALOG UNIVERSAL MODULE
-
Tariff Code8537101190
-
Country of originUSA
-
Place of shipmentXiamen, China
-
Estimated Shipping Size9.7x12.7x6.2cm
-
ManufacturerStahl
-
Weight0.25 kg
-
Max. voltage Uo/Voc24.4 V
-
Max. current Io (2-conductor)80 mA
-
Max. power Po (2-conductor)488 mW
-
Max. current Io (3-conductor)81.8 mA
-
Number of channels8 Ex i inputs/outputs
-
Supply voltage16 V
-
Current consumption220 mA
-
Auxiliary power/system components≥ 1500 V AC
-
Max. signal for input 23.5 mAMax. input short-circuit current24 mA
Description
9468320811
ANALOG UNIVERSAL MODULE
210659
IS1+ HAR
FOR ZONE 1 EX I
24.4 VDC
80 MA
488 MW
BLUE TERMINALS
8 CHANNELS EX I INPUTS/OUTPUTS
16-POLE
AUMH 08 Z1 LED
ANALOG UNIVERSAL MODULE
210659
IS1+ HAR
FOR ZONE 1 EX I
24.4 VDC
80 MA
488 MW
BLUE TERMINALS
8 CHANNELS EX I INPUTS/OUTPUTS
16-POLE
AUMH 08 Z1 LED
Information
Overview
Manuals
Technical notes
Product Applications
Electrical Connection & Wiring
Features:
- 8 channels can be adjusted individually as analog inputs or outputs
- Intrinsically safe inputs/outputsEx ia
- For 0/4…20 mA + HART signals
- Line fault monitoring and LED display per channel
- Diagnostics based on NE107
- Module can be replaced in the hazardous area under power(hot swap)
The 9468/32-08-11 STEEL Analog Universal Module may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
STEEL 9468/32-08-11 Analog Universal Module Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The STAHL 9468/32-08-11 is a high-performance HART analogue universal module designed for use within the IS1+ Remote I/O system in hazardous areas. It features 8 channels that can be individually configured as either inputs or outputs for 2-, 3-, or 4-wire transmitters and positioners, supporting bidirectional HART communication
- Chemical & Petrochemical:Pressure/level transmitters & control valves
- Oil & Gas (Up/Downstream):Compressors, pumps & offshore refinery monitoring
- Pharmaceutical:Cleanroom-safe precision flow meters & reactors
- Marine & Offshore:Engine room & cargo handling controls
- Energy & Utilities:Turbine/generator vibration via analog signals
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Terminals: Uses 16-pole blue terminals (2.5 \(mm^{2}\)) available in screw or spring-clamp versions.
Separation: Intrinsically safe field circuits must maintain suitable separation from non-intrinsically safe wiring as per NEC or CEC standards.
Channel Mapping:
2-wire/3-wire transmitters: Occupy 1 channel.
4-wire transmitters (Active mA-sources): These typically occupy 2 channels. Note that to operate an active 4-wire HART transmitter, a 9164 HART isolator must be connected between each channel.
FAQs
-
What is the 9468/32-08-11?
+The R. STAHL 9468/32-08-11 is a HART Analog Universal Module designed for IS1+ Remote I/O systems, specifically for use in hazardous areas (Zone 1/Class I, Div 1). It handles 8 input/output channels for 2-, 3-, or 4-wire transmitters, or control valves. -
How are 4-wire HART transmitters connected?
+For active 4-wire HART transmitters, a 9164 series isolator must be connected between each channel to ensure proper operation. If the 4-wire transmitter does not require HART communication, the 9164 is not necessary -
Can the 9468/32-08-11 be used for Control Valves/Positioners?
+Yes, the channels can be configured for 0/4 to 20 mA signals, making them suitable for actuators and positioners. -
What kind of diagnostic features does it have?
+The module features LED status/fault indicators for each channel and provides line fault monitoring, ensuring high availability and secure signal processing
