Technical specifications for LTM09C016K
-
Product ModelLTM09C016K
-
Product ParametersLCD DISPLAY PANEL
-
Tariff Code8537101190
-
Country of originJapan
-
Place of shipmentXiamen, China
-
In stock1 unit
-
Estimated Shipping Size26.4x17.8x1.2cm
-
ManufacturerToshiba
-
Weight0.55 kg
-
Diagonal Size9.4
-
Panel Typea-SiTFT-LCD, LCM
-
Display TypeTN, Normally White
-
Number of Pixels640(RGB)×480, VGA
-
Pixel StructureRGB Vertical Stripe
-
Form FactorFlat Rectangle
-
Aspect Ratio4:3 (H:V)
Description
The TOSHIBA LTM09C016K is a 9.4-inch a-Si (amorphous silicon) TFT-LCD display module with VGA resolution of 640 × 480 pixels. The panel features an RGB vertical stripe pixel format with 84 PPI pixel density and supports 262,144 colors (18-bit color depth).
The display area measures 192 mm × 144 mm with a 4:3 aspect ratio. The module uses CCFL (Cold Cathode Fluorescent Lamp) backlighting with two lamps, requiring an external inverter for operation. Typical brightness is 250 cd/m² with a contrast ratio of 300:1.
The LTM09C016K interfaces via parallel RGB TTL signals with 18-bit data width (6 bits per color channel). Horizontal and vertical sync signals, data clock, and data enable are required for proper timing. The logic supply voltage is 3.3 V with typical power consumption of 6.5 W.
The display area measures 192 mm × 144 mm with a 4:3 aspect ratio. The module uses CCFL (Cold Cathode Fluorescent Lamp) backlighting with two lamps, requiring an external inverter for operation. Typical brightness is 250 cd/m² with a contrast ratio of 300:1.
The LTM09C016K interfaces via parallel RGB TTL signals with 18-bit data width (6 bits per color channel). Horizontal and vertical sync signals, data clock, and data enable are required for proper timing. The logic supply voltage is 3.3 V with typical power consumption of 6.5 W.
Alternative Names
LTM09C0I6K
LTM09CO16K
LTMO9C016K
LTMO9COI6K
Information
Overview
Manuals
Technical notes
Product Applications
Operational Precautions
Features:
- 9.4-Inch Compact Form Factor
- VGA Resolution with 4:3 Aspect Ratio
- 9-Bit Color Capability
- TN Transmissive Display Technology
- Single CCFL Edge-Lit Backlight
- Generous Effective Display Area
The Toshiba LTM09C016K is a classic 9.4-inch diagonal amorphous silicon (a-Si) Thin-Film Transistor Liquid Crystal Display (TFT-LCD) module. Primarily designed for industrial control panels, legacy medical diagnostics, and specialized testing equipment, the LTM09C016K delivers standard VGA rendering with a traditional 4:3 aspect ratio.
The LTM09C016K Toshiba 9 Bit Farb TFT may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
Toshiba LTM09C016K 9 Bit Farb TFT Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The physical construction of the display features a transmissive-type TN (Twisted Nematic) panel, which naturally operates in a "normally white" state. This ensures excellent contrast and text legibility, which is critical for operators reading real-time process data or system coordinates. The display's pixel layout is configured in an RGB vertical stripe pattern, maximizing horizontal clarity for alphanumeric text and simple graphical user interfaces (GUIs). To illuminate the screen, Toshiba integrated a single CCFL (Cold Cathode Fluorescent Lamp) backlight system positioned at the top of the frame in an edge-lit configuration. This design choice helps maintain a slim profile and reduces the thermal footprint of the display during long-term operation.
- Industrial Automation & Control Systems:Monitors high-speed machinery in automated manufacturing
- Human-Machine Interface (HMI):Toshiba panels & consoles for industrial process interactio
- Point of Sale (POS) & Kiosks:Robust displays for POS terminals & self-service kiosks
- Medical Diagnostic Equipment:Ultrasound & imaging devices requiring precise visuals
- Telecommunications Monitoring:Signal processing & network monitoring for critical infrastructure
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Power Sequencing: Always power on the logic circuit before or simultaneously with the backlight to prevent "latch-up" or permanent damage to the TFT-LCD panel.
Screen Burn-in: Like most legacy TN panels, displaying a static high-contrast image for extended periods can cause image retention. Use a screen-saver function if supported by your controller.
Cleaning: Use only a soft, dry cloth or a cloth dampened with a small amount of isopropyl alcohol. Avoid pressurized water or harsh industrial solvents.
Technical notes
Typical applications include industrial HMI panels, medical displays, test and measurement equipment, portable devices, and embedded systems requiring a compact VGA-resolution LCD display. The LTM09C016K is suitable for replacement and refurbishment of legacy industrial displays and control panel interfaces.
FAQs
-
What is the LTM09C016K?
+The Toshiba LTM09C016K is a 9.4-inch, a-si TFT-LCD display module widely used in industrial machinery, medical equipment, and legacy CNC control panels. -
Can LTM09C016K be used as a regular computer monitor?
+No. Although it uses a standard VGA resolution, it is an industrial/embedded component. It does not have standard consumer-grade interfaces such as HDMI or DisplayPort and requires a specific controller board or older equipment to function. -
What is the lifespan of the CCFL backlight?
+CCFL backlights typically last between 20,000 to 50,000 hours. Over time, these lamps may dim, flicker, or turn pink, which is a common indicator that the backlight or the entire display module needs replacement. -
What is the resolution of the LTM09C016K?
+This panel uses an RGB vertical stripe format and has a VGA resolution, which is 640 x 480 pixels. -
What type of backlight does LTM09C016K use?
+It typically uses a single CCFL (Cold Cathode Fluorescent Lamp) as its backlight.
