VM600 RPS6U SIM-275A 200-582-500-013
Need Help? Contact US!
Call us: +86-18020776786
Proper, Ready.
Delivery time
Please indicate your delivery time
This image is for reference only product style, specific date of manufacture and product version, please refer to the actual product delivery!
Product Information
Product Describe
RACK POWER SUPPLY
115VAC 6.4A
230VAC 3.2A
50/60HZ
OUTPUT +5.35VDC (U1): 35A / +12.5VDC (U2): 6A
-12.5VDC (U3): 2A
MAXIMUM OUTPUT POWER 275 WATT
115VAC 6.4A
230VAC 3.2A
50/60HZ
OUTPUT +5.35VDC (U1): 35A / +12.5VDC (U2): 6A
-12.5VDC (U3): 2A
MAXIMUM OUTPUT POWER 275 WATT
Specifications
-
Product ModelVM600 RPS6U SIM-275A 200-582-500-013
-
Spare Model200-582-500-013
-
Product ParametersPower Supply Module
-
Tariff Code8537101190
-
Country of originUSA
-
Place of shipmentXiamen, China
-
Estimated Shipping Size6.2x19.2x26.2cm
-
ManufacturerVibro-Meter
-
weight2.2 kg
-
Nominal input voltage115/230 VACor220 VDC
-
Input voltagerange90 to 132 VACand 180 to 264 VAC
-
Input frequency47 to 63 Hz
-
Efficiency84% typ
-
Inrush current<10 times thenominal input current
-
Output power330 W max
-
Factory adjustment+5.41 VDC ±0.02 V,±12.5 VDC ±0.05 V
-
Ripple and noise<50 mVPEAK-TO-PEAKfor all outputs
