RE22P-2DT.3I.1R
Need Help? Contact US!
Call us: +86-18020776786
Proper, Ready.
Delivery time
Please indicate your delivery time
Product Information
Product Describe
RE22P-2DT.3I.1R
Centrifugal Fan
Single inlet impeller with
backward curved blades
Centrifugal Fan
Single inlet impeller with
backward curved blades
Technical specifications for RE22P-2DT.3I.1R
-
Product ModelRE22P-2DT.3I.1R
-
Product ParametersCentrifugal Fan
-
Tariff Code8537101190
-
Country of originUSA
-
Place of shipmentXiamen, China
-
Estimated Shipping Size27.3x15.2x16.3cm
-
ManufacturerZiehl-Abegg
-
Weight9 kg
-
Rated Voltage(V)3~400
-
Size(mm)220
-
Max.Air Flow(m³/h)1610
-
Max.Pressure(Pa)1190
-
Input Power(W)1100
-
Speed(rpm)2650
-
Connection diagram1360-106XA
-
Factory New
These are new and current items that are procured from the manufacturer. -
New No Package
These parts are new. They have not been used, but their original packaging is no longer available. -
New In Opened Package
These parts are new. They have not been used, but their original packaging has been opened or the packaging is significantly aged. -
New In Sealed Package
Parts are new. They have not been used and still have their original package seal intact. -
New in Original Package
These parts are new. The packages were not originally sealed by their original manufacturer.
Warranty Period & Disclaimer
Amikon is not an authorized distributor unless otherwise specified, representative, or affiliate of the manufacturer of this product. All trademarks and documents are the property of their respective owners and are provided for identification and informational.
FAQs
-
What type of fan is the RE22P-2DT.3I.1R?+It is a centrifugal fan (P-series) with backward-curved blades. It is typically used as a free-running motor impeller (without spiral housing), designed for high-performance extraction applications.
-
What are the primary electrical ratings?+The fan is rated for a voltage of 3~ 400V and has an input power of approximately 1100W. It typically operates at a rated current of 1.8A and a speed of 2650 rpm.
-
What material is the fan constructed from?+It features blades made of stainless steel and is housed in a standard spiral housing with a discharge flange and fastening bracket.
-
What is the performance range?+This model provides a maximum airflow of 1610 m³/h and a maximum static pressure of 1190 Pa
Get a quick price fo RE22P-2DT.3I.1R
whatsapp
Inquiry
Our customer support team is always on call to help you with any form of consultation. You can inquire by phone or use us on the product page and "contact us" View Amikon terms and conditions
Product
MORE INFORMATION
Overview
Manuals
Technical notes
Product Applications
Electrical Connection
Features:
- High-Efficiency Backward-Curved Impeller
- Compact External Rotor Motor Design
- Variable Speed Control
- Rugged Railway-Grade Construction
- Maintenance-Free Ball Bearings
The RE22P-2DT.3I.1R ZIEHL-ABEGG Centrifugal Fan may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
ZIEHL-ABEGG RE22P-2DT.3I.1R Centrifugal Fan Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
At the heart of the unit is the integrated external rotor motor, a design pioneered by ZIEHL-ABEGG to minimize the axial footprint of the fan assembly. This compact integration not only allows for installation in tight compartments—such as train HVAC units or electronics cooling racks—但 also ensures that the motor is directly cooled by the moving airstream, enhancing its thermal resilience. The "3I.1R" configuration denotes specific electrical and mechanical ratings tailored for industrial reliability, featuring corrosion-resistant surface treatments and a robust housing that can withstand the mechanical stresses of high-speed transit. Whether used in climate control systems or for cooling critical power electronics, the RE22P-2DT.3I.1R stands as a benchmark for energy efficiency, durability, and German engineering precision.
- Railway & Transport: Suitable for demanding, high-requirement applications, including rail vehicles
- Clean Room Technology: Used in clean room workstations
- Machinery & Production: Suitable for packaging machines, manufacturing equipment, and cooling electronic components
- Industrial Ventilation: Used in air handling units, ventilation systems, and extraction systems
- HVAC & Refrigeration: Ideal for cooling, temperature control, and dehumidification in industrial plants
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Voltage: Connect to a 3-phase 400V power supply.
Protection: The thermal overload protection must be connected and functional.
Wiring: All cable glands must be firmly tightened to ensure sealing.
Safety: Ensure all electrical installation conforms to local safety standards.
