Technical specifications for AIO216
-
Product ModelAIO216
-
Product ParametersAnalog Input/Output Module
-
Tariff Code8537101190
-
Country of originAustria
-
Place of shipmentXiamen, China
-
In stock1 unit
-
Estimated Shipping Size5.3x7.2x11.8cm
-
Manufacturerbachmann
-
Weight0.22 kg
-
Number16 channels
-
Digital resolution16 bit
-
Measuring range±105 % of nominal range
-
Permitted common mode voltageMax. ±1 V
-
Refresh cycle time100 µs
-
Filter slope> 80 dB/decade
-
Input impedance Max300 Ω
-
Shunt short-circuit proofUp to +24 V
-
External withstand voltage±24 V
-
Input impedance> 100 kΩ
-
Temperature range-100 °C to +800 °C
-
Output voltage±10 V
-
Output current Max10 mA
Description
The AIO208 and AIO216 modules enable the measuring or output of all standard analog signals. The AIO208 offers 8 channels and the AIO216 16 channels compactly in a single module. The standard signal types for current (0 to 20 mA and 4 to 20 mA) and voltage ranges (±10 V to ±10 mV) allow the connection of a wide range of sensors and actuators. A minimum 14 bit resolution makes it possible to also measure signals that do not fully utilize the measuring range (e.g. 0 to 5 V) with a sufficiently high resolution.
Temperatures are playing an important role in an increasing number of processes. These modules therefore also support Pt100/Pt1000 in 2-, 3- and 4-wire measuring circuits, as well as all standard thermocouples. For each channel, a second channel with unused signal types can be used in addition to the primary configured signal type. For example, a current output can be assigned to a voltage input so that up to twice the number of channels per module are provided. This enables one module to cover virtually all analog signal measuring tasks instead of having to use many different modules for each signal type. A costeffective solution that simplifies logistics and servicing. Different modes can be combined and set simply using a configuration wizard in the SolutionCenter engineering tool.
Temperatures are playing an important role in an increasing number of processes. These modules therefore also support Pt100/Pt1000 in 2-, 3- and 4-wire measuring circuits, as well as all standard thermocouples. For each channel, a second channel with unused signal types can be used in addition to the primary configured signal type. For example, a current output can be assigned to a voltage input so that up to twice the number of channels per module are provided. This enables one module to cover virtually all analog signal measuring tasks instead of having to use many different modules for each signal type. A costeffective solution that simplifies logistics and servicing. Different modes can be combined and set simply using a configuration wizard in the SolutionCenter engineering tool.
Alternative Names
AIO 216
AIO2I6
AI0216
A1O216
A10 2I6
Information
Overview
Manuals
Application Notes
Product Applications
Backplane Mechanical Mounting
Features:
- 8 channels AIO208, 16 channels AIO216
- Analog inputs and outputs
- Resolution: 16 bit input with filter, 14 bit output
- High-speed frequency input capability
- Filter adjustable from 4 kHz to 0.5 Hz per channel
- All outputs overload, short circuit and external voltageproof
- Measuring range monitoring freely adjustable (±105 %)
- Galvanic isolation for the system 500 V
BACHMANN AIO216 enables one module to cover virtually all analog signal measuring tasks by allowing a second channel with unused signal types to be used in addition to the primary configured signal type; for example, a current output can be assigned to a voltage input so that up to twice the number of channels per module are provided, making the solution cost-effective and simplifying logistics and service.
The AIO216 BACHMANN Universal Analog Input/Output Module may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
BACHMANN AIO216 Universal Analog Input/Output Module Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
AIO216 provides robust output protection with all outputs being overload-proof, short-circuit-proof, and external voltage-proof, and includes measuring range monitoring freely adjustable to ±105%, with error messages on overload, overtemperature, and undervoltage of the supply.
AIO216 features 500V galvanic isolation for the system and an optional condensation-proof ColdClimate design, with different modes combinable and set simply using a configuration wizard in the SolutionCenter engineering software.
- Renewable Energy (Wind Power):Bearing/gearbox temps & pitch/yaw (ColdClimate option)
- Industrial Process Control:Reads transmitters; commands valves/drives
- Machinery & Manufacturing:Adjustable filters (4kHz-0.5Hz) for load cells/feedback
- Condition Monitoring Systems (CMS):CMSadvanced sensor logging for fault identification
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
De-energize the rack: Shut off all power supplying the Bachmann M1 controller system backplane before handling modules.
Align the module: Position the AIO216 over an open slot on the backplane, ensuring the bus connector pins line up perfectly.
Seat the hardware: Press firmly until the module clicks completely flat against the backplane rail structure.
Secure the screws: Tighten the integrated top and bottom retaining screws to 0.5 Nm torque to guarantee vibration resistance.
Technical notes
BACHMANN AIO216 supports multiple selectable modes per channel including analog voltage input (±10V to ±10mV), analog current input (0/4 mA to 20 mA), temperature sensors (Pt100/Pt1000 in 2-, 3-, and 4-wire measuring circuits), thermocouples (types J, K, T, N, E, R, S, B), analog voltage output (±10V), and analog current output (0/4 mA to 20 mA), allowing the connection of a wide range of sensors and actuators.
FAQs
-
What is the AIO216 ?
+The Bachmann AIO216 Universal Analog Input/Output Module is a versatile 16-channel module that condenses multiple signal types into a single compact device -
What signal types does the AIO216 support?
+Each of the 16 channels is independently configurable to support voltage (± 10 V to ± 10 mV) and current (0 to 20 mA, 4 to 20 mA). It also handles temperature measurements (Pt100/Pt1000 in 2-, 3-, or 4-wire configurations) and standard thermocouples. -
How are the input filters configured?
+The digital filter cut-off frequency is configurable on a channel-by-channel basis, ranging from 4 kHz to 0.5 Hz, with a filter slope of > 80 dB/decade. -
Is the AIO216 protected against harsh conditions?
+Yes. All outputs are overload-proof, short-circuit-proof, and protected against external voltages. For extreme environments, an optional ColdClimate (CC) variant is available, providing condensation-proof operation.
