MC Interface Board
Input Voltage: Typically 24 V DC
Current Consumption:100-200 mA
Operating Temperature: -20°C to 60°C
Storage Temperature:-40°C and 85°C
Humidity: 5% to 95% non-condensing humidity
Field Kit
Series: SDCS
Operating Voltage: Typically 24V DC
Power Consumption: 5-10 W
Current Consumption: 200-400 mA
Operating Temperature Range: -20°C to 70°C (-4°F to 158°F)
Storage Temperature Range: -40°C to 85°C (-40°F to 185°F)
PU516 Engineering Module
3BSE013064R1
DISCONTINUED BY MANUFACTURER
PU516 ENGINEERING BOARD
Tariff Code: 8517620050
Country of Origin: Sweden
SDCS-CON2 Control BoardS
SDCSCON2
DISCONTINUED BY MANUFACTURER
PC BOARD
MAIN DRIVE CONTROL BOARD
DCS500
24 VDC
DATX 100 Pulse Transformer Board
Isolation Voltage: Typically ≥4 kV.
Input/Output Ratio: 1:1 or custom turns ratio .
Frequency Range: Optimized for 1–50 kHz
Primary Voltage: 5–24 V DC
Peak Current: 2–5 A
PROFIBUS Redundancy Link Module
3BDZ000398R1
PROFIBUS REDUNDANCY LINK MODULE
150 MA
24 VDC
CONVERTS NON-REDUNDANT
PROFIBUS LINE TO TWO REDUNDANT
LINES OR VICE VERSA
AMPLIFIES SIGNAL FORM / AMPLITUDE
MONITORS ERROR STATUS
RLM01
Modulebus Cluster Modem
3BSE037760R1
TB840A
Tariff Code: 8517620050
ASEA BROWN BOVERI
MODULEBUS CLUSTER MODEM
Country of Origin: India, Sweden
ANALOG OUTPUT MODULE
ANALOG OUTPUT MODULE
8 CHANNEL
0-20 MA
14 BIT
500/850 OHMS
USE MODULE TERMINATION UNIT
Feedback Module Pulse Encoder
INTERFACE MODULE
FOR PULSE ENCODER
15/24 VDC DIFFERENTIAL
SINGLE ENDED FOR ACS800/DCS800
Analog output module
16 analog outputs, output signal 0/4 ... 20 mA,
channel-by-channel configuration
Load: max. 700 Ohm
Monitoring of loads
Channel-by-channel isolation of outputs
Module is capable of redundant operation
Digital communication with field devices according to
HART protocol (Version 5.0 / 5.1)
Monitoring of modules
Power Supply Unit
3BSE003390R1
DISCONTINUED BY MANUFACTURER
POWER SUPPLY UNIT
115VAC
50/60HZ
24VDC
25AMP
SA167
Tariff Code: 8504409520
Country of Origin: Sweden
Stromberg Pulse Amplifier Board
SNAT634PAC
DISCONTINUED BY MANUFACTURER
PULSE AMPLIFIER BOARD
(61049452)
