ABB

Robot Rubber Gasket

Manufacturer: ABB
Model Number: 3HNM09802-1
Product Type: Robot Rubber Gasket
Temperature Resistance:  -40°C to +120°C

CABLE PRESSURE TRANSDUCER

High precision within ±0.5%
Output Signal:Standard 4-20 mA
Typically around 250 ohms for 4-20 mA output
Operating temperature range: -40°C to +85°C
Storage temperature range: -50°C to +100°C
Operating Voltage:24 VDC

TEACH PENDANT

Human-Machine Interface
Screen Size: Typically 8-10 inches
Operating Temperature Range: -10°C to +45°C
Storage Temperature Range: -25°C to +70°C
Humidity: 5% to 95% (non-condensing)

Safety Board

Operating Voltage: 24 VDC
Operating Temperature: 0°C to +55°C
Storage Temperature: -25°C to +70°C
Humidity: 5% to 95% non-condensing
Shock and Vibration Resistance:
Meets IEC 60068-2-27 for shock.
Meets IEC 60068-2-6 for vibration.

Interface Card

Operating Voltage: 24 VDC
Operating Temperature Range: 0°C to +55°C
Storage Temperature Range: -25°C to +70°C
Humidity: 5% to 95% (non-condensing)
Profibus, DeviceNet, and CAN Bus systems

Control Card

Operating Voltage: 24 VDC
Serial Port: Supports RS-232/RS-485
Operating Temperature Range: 0°C to +55°C
Storage Temperature Range: -25°C to +70°C
Humidity: 5% to 95% (non-condensing)

Motherboard

Model Number: MCOB-02
Part Number: 3HNE09204-1
Product Type: Motherboard
Input Voltage: 24 VDC
Operating Temperature Range: 0°C to +55°C
Storage Temperature Range: -25°C to +70°C
Humidity: 5% to 95% (non-condensing)

Serial Measurement Unit

Model: SMU-02
Part Number: 3HNE07835-1
Function: Serial Measurement Unit
Country of Origin: Norway
Customs Tariff Number: 85371090

SMB-01 TOP ASSEMBLY

3HNA006142001
SMB-01 TOP ASSEMBLY

Control module

Power Supply: Typically 24 V DC (±20%)
Power Consumption: Around 10 W
Operating Temperature Range: -20°C to +60°C
Storage Temperature Range: -40°C to +85°C
Humidity: 5% to 95% (non-condensing)
Protocols Supported: CAN, Modbus

Optical Modem

Transmission Media: Optical Fiber
Modulation Type: 4B3T
Data Transmission Rate: Up to 2.5 Mbps
Fiber Optic Ports: 1 or 2
Electrical Interface: RS-232 or RS-485
Power Supply: 24 V DC ±20%
Operating Temperature Range: -40°C to +70°C
Storage Temperature Range: -40°C to +85°C
Relative Humidity: 5% to 95% (non-condensing)

Optical Modem

Transmission Media: Optical Fiber
Modulation Type: 4B3T
Data Transmission Rate: Up to 2.5 Mbps
Fiber Optic Ports: 1 or 2
Electrical Interface: RS-232 or RS-485
Power Supply: 24 V DC ±20%
Operating Temperature Range: -40°C to +70°C
Storage Temperature Range: -40°C to +85°C
Relative Humidity: 5% to 95% (non-condensing)

Cessor module

CPU Type: ARM Cortex A9
Clock Frequency: 800 MHz
RAM: 64 MB
Flash Memory: 64 MB
Supported Protocols: Modbus TCP, Ethernet/IP
Operating Temperature: -25°C to +60°C
Storage Temperature: -40°C to +85°C
Humidity: 5% to 95% (non-condensing)

POWER INTERFACE BOARD

Compatibility: DCS800 series drives
Operating Temperature:
Typically -10°C to +55°C (14°F to 131°F)
Humidity: humidity up to 95%

POWER INTERFACE BOARD

Compatibility: DCS800 series drives
Operating Temperature:
Typically -10°C to +55°C (14°F to 131°F)
Humidity: humidity up to 95%

Control motherboard

Power Supply: 24V DC
Operating Temperature :
-10°C to +60°C (14°F to 140°F)

COMMUNICATION BOARD

Series: SDCS
Operating Voltage: Typically 24V DC
Power Consumption:  5-10 W
Current Consumption: 200-400 mA
Operating Temperature Range: -20°C to 70°C (-4°F to 158°F)
Storage Temperature Range: -40°C to 85°C (-40°F to 185°F)

Ethernet Adapter module

Estimated min. lifetime: 100 000 h
All materials UL/CSA-approved
Maximum Segment Length:
100 m / 328 ft
Topology: Star
Serial Communication Type:
Half or Full Duplex
Transfer Rate: 10Mbps or 100Mbps

FAN CENTRIFUGAL

Typical operating range: 230V AC
Frequency: 50/60 Hz
Speed: Up to 2500 RPM
Maximum airflow: ~800-1500 m³/h
Operating Temperature Range:
-20°C to 60°C (-4°F to 140°F)
Storage Temperature:
-30°C to 70°C (-22°F to 158°F)

FlashDrop

PC cable
Battery charger
Battery charger (AC power) cable
with a set of plugs
User Manual
DrivePM CD

Analog input module

Number of Input Channels:
Typically 4, 8, or 16 channels
Voltage: 0–10V DC or ±10V DC
Current:4–20mA or 0–20mA
Resolution: 12-bit, 14-bit, or 16-bit resolution
Operates at 24V DC
Operating Temperature:
0°C to 60°C (32°F to 140°F).
Storage Temperature:
-25°C to 85°C (-13°F to 185°F).
Humidity: 5% to 95% relative humidity

Power Supply Board

AC input: 100-240V AC, 50/60 Hz
DC input: accepts 24V DC
Operating Temperature:
0°C to 60°C (32°F to 140°F)
Storage Temperature:
-20°C and 85°C (-4°F to 185°F)
Humidity: 5% to 95% RH non-condensing

Digital Input Module

Power line carrier (PLC) links
Fiber-optic links
Copper wires / pilot cables
Microwave-radio links

Interface Card Module

Power line carrier (PLC) links
Fiber-optic links
Copper wires / pilot cables
Microwave-radio links

PCB BOARD

Voltage Rating: Typically
24V DC or 110V-240V AC
Operating Temperature:
Typically  0 to 70°C (32°F to 158°F)
Storage Temperature:
Generally -20°C to 70°C (-4°F to 158°F)
Humidity: Designed for
environments with 30-85% RH
