ABB

AO module

Channel Type:AO
Number of Output Channels:16
Long Description:4-20mA, 1-5VDC
2x8 Ch Group Isolated
Use Base xBS01-EPD

Field Exciter Power Module

Input Voltage: 500 VAC or 420 VDC
Current Rating: 50 A
Frequency Compatibility: 50/60 Hz
Output Control Mode: Pulse Width Modulation (PWM)
Operating Temperature Range: -20°C to +70°C
Protection Rating: IP20

Bus Connection Module

Auxiliary power supply Powered from host device (5V dc)
Burden ~ 0.4 W Max
Max data transfer rate 1.25 Mbps
Operating temperature range -10...55°C
Storage temperature range -40...70°C

Power interface board

Application: DCS800 DC Drives
Operating Temperature:0°C to +55°C
Storage Temperature:-25°C to +70°C
Humidity:Up to 95%, non-condensing

AC-DC/DC-DC Power supply Converter Moudle

Range: 85 V to 264 V AC
Frequency: 50/60 Hz
Primary DC Output Voltage: 24 V DC
Total Output Power: 160 W
Primary Output Current: 6.7 A
Storage Temperature: -20°C to 85°C
Operating Temperature: 0°C to 60°C

Synchron Transformer

Rated Power: 5 VA (Volt-Ampere)
Primary Voltage: 110 V (Volts)
Secondary Voltage: 9 V (Volts)
Rated Power Capacity: 5 VA
Frequency: 50/60 Hz

Synchron Transformer

Rated Power: 10 MVA
Primary Voltage: 7 kV
Secondary Voltage: 0 kV
Frequency: 50 Hz or 60 Hz

Rigi Crowbar Drive PCB

Power Supply:24V
Operating Temperature Range
Typically -20°C to +60°C
Storage Temperature Range
-40°C to +85°C

Interface Board

24 VDC
Low power design
typically <10 W
Multiple I/O ports for
interfacing with sensors
actuators, and controllers.
Optimized for high-speed
communication to minimize latency

Prog.Logic Controller

Memory Size:642 kB
Memory Type User Data:RAM
Controller Processing Time:0.00008 ms
Analog Inputs:2
Analog Outputs:1
Number of Digital Inputs:6
Number of Digital Outputs:6
Number of Digital Configurable I/Os:0
Input Voltage Type:DC
Rated Voltage (Ur):24 V DC
Supply Voltage:20.4 … 28.8 V DC

3-phase Contactor

Type: 3-phase contactor
Rated Operational Voltage (Ue): 690 V AC
Control Circuit Voltage: 100-250 V AC/DC
Rated Current: 10 A
Rated Insulation Voltage (Ui):1000 V AC
Operating Temperature:-40°C to +70°C
Storage Temperature:-40°C to +80°C

Processor Module

PM564RPETH
1SAP121000R0001
2AMP
120-240VAC
24VDC
4W

Current measurement scaling board

Function: 4-20 mA
Input impedance: Typically 250 Ω
Accuracy: ±0.5% of full scale
Voltage supply : Typically +24V DC (±10%)
Operating Temperature Range: Typically -20°C to +60°C.
Storage Temperature Range: Typically -40°C to +85°C

CPU Ccontrol I/O Board

Digital Inputs: 24V DC
Analog Inputs: 4-20mA or 0-10V
Power Supply:24V DC
Operating Temperature Range:0°C to +60°C

I/O Control Module

Digital Inputs: 24V DC
Analog Inputs: 4-20mA or 0-10V
Power Supply:24V DC
Operating Temperature Range:0°C to +60°C

CHARGING CONTROL BOARD

Input Voltage:380-480V
Charging Voltage Range:12V to 600V DC
Current Rating:10A to 100A
Operating Temperature Range:-10°C to +60°C
Storage Temperature:-20°C to +70°C

Quad Elephant Inverter Rectifier Power Board

DC Output:DC 500-800V
Current Rating:100A to 200A
Continuous Current Rating:150A
Switching Frequency:10-20 kHz
Storage Temperature:-20°C to +70°C
Operating Temperature Range:-10°C to +55°C

Programmable Logic Controller

Memory Size:642 kB
Memory Type User Data:RAM
Controller Processing Time:0.00008 ms
Analog Inputs:2
Analog Outputs:1
Number of Digital Inputs:6
Number of Digital Outputs:6
Number of Digital Configurable I/Os:0
Input Voltage Type:DC
Rated Voltage (Ur):24 V DC
Supply Voltage:20.4 … 28.8 V DC

KONE Elevator Pulse Encoder Interface Module

Power Supply: Typically 24 V DC
Max Input Frequency: Typically 100 kH
Input Voltage Level: Usually 5V or 24V
Operating Voltage Range: 18-30V DC
Operating Temperature: -10°C to +55°C
Storage Temperature: -20°C to +70°C

ANALOG IO EXTENSION

Supply Voltage:
Typically 24V DC or 48V DC
Voltage: 0-10 V, ±10 V, 0-5 V.
Current: 4-20 mA
Operating Temperature: Typically -10°C to +55°C
Storage Temperature: Around -40°C to +70°C

Interface Board

Supply Voltage:Likely 24V DC or 48V DC
Current Consumption:150 mA to 500 mA
Operating Temperature:  -10°C to +55°C
Storage Temperature: -40°C to +70°C

Control Panel 10.4

Memory Size User Data:256 MB
Memory Size User Program:256 MB
Memory Type User Data:Flash Disk
Memory Type User Program:DDR RAM
Power Consumption (@Pcons):24 W
Power Supply:24 (18 ... 30) V DC
Product Main Type:CP651
Product Name:Control Panels
Operation 0 ... +50 °C
Storage -20 ... +70 °C

Control Panel 5.7 TFT touch screen

Memory Size User Data:128 MB
Memory Size User Program:256 MB
Memory Type User Data:Flash Disk
Memory Type User Program:DDR RAM
Power Consumption (@Pcons):16.8 W
Power Supply:24 (18 ... 30) V DC
Product Main Type:CP630
Product Name:Control Panels

Control Panel

Memory Size User Data:256 MB
Memory Type User Data:Flash Disk
Memory Type User Program:DDR RAM
Power Consumption (@Pcons):24 W
Power Supply:24 (18 ... 30) V DC
Product Main Type:CP651
Product Name:Control Panels

DRIVE MOTION CONTROL

DRIVE MOTION CONTROL
4AMP
3PHASE
48-63HZ
480V
