Technical specifications for SDCS-PIN-H01 3ADT318800R1501
-
Product ModelSDCS-PIN-H01 3ADT318800R1501
-
Product ParametersInterface Board
-
Tariff Code8537101190
-
Country of originSWEDEN
-
Place of shipmentXiamen, China
-
Estimated Shipping Size25x23.2x5cm
-
ManufacturerABB
-
Weight0.8 kg
-
Control Supply24 V dc
-
On-Board Rails+5 V dc 4 A
-
Gate Drive±15 V differential
-
Isolation1 500 V dc
-
Operating Temp–20 °C … +60 °C
-
Storage Temp–40 °C … +85 °C
-
Humidity5 – 95 % RH non-condensing
Description
SDCSPINH01
POWER INTERFACE BOARD
FOR DCS880 DRIVES
115/230 VAC INPUT AUX SUPPLY
3ADT318800R1501
POWER INTERFACE BOARD
FOR DCS880 DRIVES
115/230 VAC INPUT AUX SUPPLY
3ADT318800R1501
Information
Overview
Manuals
Technical notes
Product Applications
Core Functions
Features:
- Integrated Power Supply
- Armature Bridge Control
- Field Exciter Control
- Auto-Adaptive Voltage
The DCS-PIN-H01 3ADT318800R1501 ABB Power Interface board may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
ABB DCS-PIN-H01 3ADT318800R1501 Power Interface board Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The SDCS-PIN-H01 is designed for DCS880 converter modules sizes H1 ... H5 (20 A ... 1190 A).It has 4 different functions:
1. The power supply for all internal voltages of the whole drive and the connected options (H1 ... H5).
2. Control of armature bridge including high ohmic measurement of DC- and AC voltage and an interface forthe current transformer measuring the armature current (H1 ... H5).
3. Control of the OnBoard field exciter and field current measurement (H1 ... H4).
4. An automatic adaptation of the auxiliary voltage of either 230 VAC or 115 VAC (H1 ... H5).The board is connected to ground at points ( ) inside the module.The board is used for mains supply voltages from 100 V up to 500 V (IEC) / 525 V (UL) and 600 V.
The DCS880 provides an automatic adjustment for current and voltage measurement, burden resistor settingsand 2-Q or 4-Q operation by means of setting parameters in the firmware.
- Metals and Mining: Mills and processing equipment
- Marine & Cranes: Winches and propulsion systems
- Material Handling & Processing: Conveyors, mixers, and pumps
- Industrial Automation: Used in motion control systems to provide power regulation
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Internal Power Supply: Provides all internal voltages for the drive and connected options (H1–H5).
Armature Bridge Control: Manages the armature bridge, including high-ohmic measurement of DC and AC voltages and current transformer interfacing.
Field Exciter Control: Controls the OnBoard field exciter and measures field current (H1–H4).
Voltage Adaptation: Automatically adapts to auxiliary voltages of either 115 VAC or 230 VAC
FAQs
-
What is the ABB SDCS-PIN-H01?
+The SDCS-PIN-H01 is a Power Interface Board designed for ABB DCS880 and similar industrial DC drives. It acts as a crucial interface between the high-voltage power part and the control electronics -
Where is the SDCS-PIN-H01 used?
+It is primarily used in the ABB DCS880 series industrial DC drives. It is used for voltage measurement of the main circuit, providing high-ohmic resistor paths (typically 5 MΩ for 500 V units) to monitor AC and DC voltages. -
What is the difference between SDCS-PIN-H01 and SDCS-PIN-51?
+Both are power interface boards, but they differ in their specific applications and voltage handling capabilities. The SDCS-PIN-H01 is often used within the DCS880 range, while older variants might be found in DCS800 or DCS 500B. -
Is the SDCS-PIN-H01 compatible with Safe Torque Off (STO)?
+Yes, the SDCS-PIN-H01 plays a role in the functional safety of the DCS880, allowing the main contactor to be opened via hardware supervision of the motor current. -
What SDCS-PIN-H01 are the key connection points?
+It connects to the SDCS-CON-H01 via flat cables and uses terminals for field supply (XAUX/X99) and mains voltage monitoring.
