PRODUCT DESCRIPTION
ABB control/interface board for power-electronics system maintenance
The ABB 3BHE036342R0101 XD D501 A101, also listed as XDD501A101, is a control/interface board associated by multiple industrial-parts sources with ABB power-electronics platforms, including AC 800PEC and UNITROL installations.
Published sources disagree on the board's exact subfunction and physical specifications. Confirm the complete order code, installed rack position, connectors, project drawings and applicable ABB documentation before replacement or commissioning.
Published sources disagree on the board's exact subfunction and physical specifications. Confirm the complete order code, installed rack position, connectors, project drawings and applicable ABB documentation before replacement or commissioning.
BEFORE YOU BUY
Confirm the complete installed configuration
ACTUAL APPLICATIONS
Where the XDD501A101 fits in power-electronics control systems
Exact use depends on the installed ABB system, rack position, board revision and project documentation.
-
01 · GENERATOR EXCITATION
Excitation-control interface support
Reported for ABB UNITROL 6000 installations linking control functions with power-conversion hardware. -
02 · AC 800PEC
Control-rack interface and power support
Used in AC 800PEC power-electronics environments where board function and rack wiring must be matched to the original design. -
03 · HIGH-POWER CONVERTERS
Converter control system maintenance
Applied as a replacement board in high-power converter control assemblies, subject to full order-code and connector verification.
Technical specifications for 3BHE036342R0101 XD D501 A101
-
Product Model3BHE036342R0101 XD D501 A101
-
Spare ModelXDD501A101
-
Product ParametersMotherboard
-
Country of originSWEDEN
-
In stock1 unit
-
ManufacturerABB
-
Product categoryElectronic board / PCB assembly
-
Variant codeR0101
View all additional
Alternative Names
3BHE036342R0101
XD D501 A101
3BHE036342R0101 XDD501A101
SYSTEM & REPLACEMENT CHECK
Information needed before ordering
Three direct checks to secure your system integration and minimize ordering risks.
Information
System integration
Replacement check
Manuals & support
AC 800PEC ARCHITECTURE
Confirm the complete board identity before integration
ABB 3BHE036342R0101 / XDD501A101 is designed for integration within ABB AC 800PEC power-electronic control systems. It works as part of the control cabinet’s rack, backplane, power and interface architecture, together with the corresponding AC 800PEC controller, I/O modules and application-specific communication hardware.
At plant level, the AC 800PEC platform can integrate with ABB System 800xA and support configured communication interfaces such as ABB Fast Fiber Optic Link, DriveBus (DDCS), Optical ModuleBus, Modbus TCP, IEC 61850 and CANopen. Additional CEX or Anybus modules may provide PROFIBUS, PROFINET, EtherNet/IP, EtherCAT and other fieldbus connections.
Actual compatibility depends on the cabinet configuration, backplane, firmware and system drawings. ABB’s public documentation does not provide a standalone datasheet for this exact board, so its individual voltage, I/O and terminal specifications should be verified before replacement.
Features:
- Complete ABB order code: 3BHE036342R0101
- Board designation: XDD501A101 / XD D501 A101
- Confirm the installed ABB system and project context
The ABB 3BHE036342R0101 / XDD501A101 control/interface board requires the installed ABB system and project context to be confirmed before system integration and commissioning.
INTERCHANGEABILITY
Verify the complete replacement identity before commissioning
ABB 3BHE036342R0101 / XDD501A101 should be replaced only with a unit having the same complete type designation, matching nameplate identification code, and identical hardware and software configuration for the installed AC 800PEC/PCS6000 system.
Before replacement, verify the hardware revision and identification code; rack position and backplane compatibility; connector and optical-fiber arrangement; firmware, software and application-parameter backup; correct cable reconnection and terminal assignment; and the status LEDs and complete system functional test after power-up.
ABB notes that software updates may be required depending on the replaced board. Do not treat another XDD, PDD, PCD or UFC board as a direct substitute without confirmation from ABB or the project hardware documentation.
Features:
- Match the complete 3BHE036342R0101 order code
- Compare board revision, rack position and connectors
- Verify the installed function and project documentation
The ABB 3BHE036342R0101 / XDD501A101 control/interface board requires replacement verification based on the complete identifier, revision, installed function and project documentation before commissioning.
DOCUMENTATION STATUS
Browse the Manuals, Datasheets, Official Documents, Links
Important Notice: Official documents are provided through manufacturer links. Accessories, manuals, cables, calibration data, software, certificates, and other items are not included with this equipment unless listed in the stock item description.Features:
- Available ABB or project document references are confirmed before order
- Software licensing and project backups remain the customer's responsibility
- Accessories are supplied only when listed in the quotation
Documentation for the ABB 3BHE036342R0101 / XDD501A101 control/interface board must be matched to the complete identifier and installed project; confirm manual availability in the written quotation.
