Technical specifications for 3BHE014070R0101 PP C905 AE101
-
Product Model3BHE014070R0101 PP C905 AE101
-
Spare Model3BHE014070R0101 PPC905AE101
-
Product ParametersCONVERSOR CONTROL BOARD
-
Tariff Code8537101190
-
Country of originSweden
-
Place of shipmentXiamen, China
-
Estimated Shipping Size25x11x3cm
-
ManufacturerABB
-
Weight0.25 kg
-
Power Supply24 V DC (±10%)
-
Power Consumption8-20 W (typical)
-
Operating Voltage24 V DC nominal
-
Signal LevelsTTL, 0-10 V, 4-20 mA
-
Operating Temperature0°C to +60°C
-
Storage Temperature-40°C to +85°C
-
Humidity5-95% RH (non-condensing)
Description
3BHE014070R0101
PPC905AE101
230VAC to 480VAC
CONVERSOR CONTROL BOARD
PPC905AE101
230VAC to 480VAC
CONVERSOR CONTROL BOARD
Information
Overview
Manuals
Technical notes
Product Applications
Physical Installation Steps
Features:
- CCB-2 drives control board
- ABB ACS6000 series
- Converter control board
- Integrated Direct Torque Control (DTC) Platform
The ABB 3BHE014070R0101 PP C905 AE101, designated as the CCB-2 COMPLETE (Converter Control Board), is a specialized control board spare part designed for ABB's ACS6000 medium-voltage AC drive systems. As an essential component within the drive's Control Unit (COU), this board forms a critical layer of the control hierarchy that governs power conversion, motor regulation, and system protection in heavy industrial applications such as metals processing, marine propulsion, mining, and large-scale material handling.
The 3BHE014070R0101 PP C905 AE101 ABB CCB-2 drives control board may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
ABB 3BHE014070R0101 PP C905 AE101 CCB-2 drives control board Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The CCB-2 serves as the interface and control backbone for the ACS6000's power modules, including the Active Rectifier Unit (ARU), Inverter Unit (INU), and Exciter Unit (EXU). It works in close coordination with the AMC (Application and Motor Controller) board—a digital signal processor that functions as the heart of the drive control system—to execute ABB's industry-leading Direct Torque Control (DTC) platform. DTC provides fast, accurate, and stepless control of motor flux and torque from zero to full speed, delivering optimal speed accuracy and negligible torque ripple across the entire operating range without requiring a motor-mounted speed encoder in many configurations. The CCB-2 facilitates the high-speed switching logic and gate control signals necessary for the IGCT (Integrated Gate Commutated Thyristor) power semiconductors used in the ACS6000's three-level voltage source inverter topology.
- Medium Voltage Drives (ACS6000/PCS600):CCB-2 converter board: motor speed/torque regulation
- Process Industries:Continuous control for petrochem/chemical/pharm
- Power Generation:Turbine/boiler control & aux system automation
- Marine Services:Shipboard drive & industrial automation
- Machine Tools & Robotics:Motors for robotics, printing & textile equipment
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Remove Old Unit: Disconnect all external terminal blocks, optical fiber cables, and ribbon connectors from the faulty board. Unscrew the mounting fasteners and slide the unit out.
Mount the New Board: Align the new board with the cabinet sub-rack or mounting standoffs. Secure it firmly using the original factory screws to ensure proper structural grounding.
Reconnect Wiring: Reattach all spring terminal blocks, digital I/O leads, and communication lines. Ensure each connection is firmly seated to prevent signal noise.
Connect Fiber Optics: Plugin the optical fiber lines to their respective channels. Do not exceed the minimum bend radius of the fiber cables.
FAQs
-
What is the 3BHE014070R0101？
+ABB CCB-2 (Converter Control Board) drives control board, often associated with PPC905AE101. It is used for AC drive control in industrial automation applications -
What is the core function of this module?
+The unit serves as a central processor board inside industrial frequency converters or excitation systems. -
What built-in safety protections are featured?
+The board architecture integrates essential protection features including overcurrent/overload safety, overvoltage mitigation, short-circuit defense, and overtemperature thresholds. -
Is this product brand new?
+Yes, ABB 3BHE014070R0101 PP C905 AE101 is brand new, original, unused, and factory sealed
