Technical specifications for BSFC-01C 3AXD50000006072
-
Product ModelBSFC-01C 3AXD50000006072
-
Product ParametersCharging Control Board
-
Tariff Code8537101190
-
Country of originSWEDEN
-
Place of shipmentXiamen, China
-
Estimated Shipping Size24.8x8x6.3cm
-
ManufacturerABB
-
Weight0.4 kg
-
Temperature Measurement Range-20°C to +80°C
-
Operating Temperature-10°C to +50°C
-
Storage Temperature-20°C to +70°C
-
Humidity5-95% non-condensing
-
Input Voltage Range380-480V AC (3-phase)
-
Output Voltage12-600V DC
-
Charging Current10-100A
-
Efficiency>92%
Description
The ABB BSFC-01C 3AXD50000006072 Charging Control Board serves as a core electronic component within ABB drive systems, managing DC bus pre-charge operations. Engineered for industrial frequency converters such as the ACS880 series, this board performs current-limited charging of DC-link capacitors during power-up, suppressing excessive inrush current at the moment of line closure to protect rectifier modules, capacitor banks, and upstream grid infrastructure from surge damage.
Alternative Names
BSFC-01C
3AXD50000006072
3AXD5OOOOOO6O72
BSFC-O1C
BSFC-0IC
BSFC-0IC 3AXD50000006072
BSFC-O1C 3AXD50000006072
8SFC-01C 3AXD50000006072
BSFC-O1C 3AXO50000006072
Information
Overview
Manuals
Engineering Considerations
Product Applications
Electrical Terminal Connections
Features:
- DC Bus Capacitor Pre-Charge Control for ACS800
- Switch and Fuse Operation Control
- 230V AC, 50/60 Hz Control Power Input
It is primarily utilized within the ABB ACS800 and DCS800 power inverter configurations. It incorporates thyristor firing logic, voltage sensing circuitry, and charge-completion arbitration, automatically regulating the charging profile based on DC bus voltage ramp characteristics. Once capacitor voltage crosses the predefined threshold, the board issues a bypass command to close the main contactor or bypass relay, ensuring seamless handover from pre-charge to normal running mode.
The BSFC-01C 3AXD50000006072 ABB CHARGING CONTROL BOARD may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
ABB BSFC-01C 3AXD50000006072 CHARGING CONTROL BOARD Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The ABB BSFC-01C 3AXD50000006072 is a specialized charging control board / switch fuse controller predominantly utilized as a replacement spare part within industrial ABB ACS800 AC drive systems. It functions as a critical safety and power management subsystem, regulating the DC bus pre-charging phase or switch-fuse operations to prevent inrush current damage when power is applied to the drive modules
- Power Generation:Boiler/exhaust gas & turbine temps
- Chemical & Petrochemical Processing:Reactor, column & fluid line heat
- Oil & Gas:Data for remote extraction & refineries
- Water & Wastewater Treatment:Liquid handling & climate tracking
- Manufacturing & Metallurgy:Furnace, casting & curing temps
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
High-Voltage Interface (Main Terminal Strips): Reconnect the 230V AC (50/60 Hz) auxiliary power supply feeds and the auxiliary contacts tracking the state of the mechanical main switch fuse.
Control / Interlock Signal Bus: Secure the pluggable control wire blocks into the low-voltage logic signal ports (such as the charging state feed, interlock chain loop, and output enable lines going back to the core RMIO/BCU board stack). Ensure all wire jacket markers match their original terminals.
Technical notes
It incorporates thyristor firing logic, voltage sensing circuitry, and charge-completion arbitration, automatically regulating the charging profile based on DC bus voltage ramp characteristics. Once capacitor voltage crosses the predefined threshold, the board issues a bypass command to close the main contactor or bypass relay, ensuring seamless handover from pre-charge to normal running mode.
FAQs
-
What is the function of the ABB BSFC-01C?+It functions as a charging control board (or switch fuse controller) designed to manage and safely monitor the DC link capacitor charging cycle within industrial variable speed drivess
-
Which drive models utilize the BSFC-01C?+It is commonly deployed as part of dynamic component service kits for multi-drive systems, specifically including the ACS800-104A, ACS800-104BV2, ACS800-104C, and ACS800-104DV2 configurations.
-
Does the board require an external power supply?+Yes, while it manages high-voltage charging logic up to 480 VAC, it requires a separate 24 V DC input to power its integrated control logic and fiber optic communication systems.
-
How does it safeguard the drive during startup?+When the charging switch is turned on, the board permits current to flow safely through charging resistors to ramp up the inverter capacitors. Concurrently, it interlocks the system, preventing the main inverter from initializing or the primary DC disconnector switch from shutting prematurely until charging completes.
