Technical specifications for NGDR-07C NGDR-07 FF1400R12IP4
-
Product ModelNGDR-07C NGDR-07 FF1400R12IP4
-
Spare Model68980135B
-
Product ParametersIGBT MODULE
-
Tariff Code8537101190
-
Country of originswedeb
-
Place of shipmentXiamen, China
-
Estimated Shipping Size23x13.8x2cm
-
ManufacturerABB
-
Weight0.24 kg
-
Collector-Emitter Voltage1200V
-
Continuous DC Collector Current1400A
-
Repetitive Peak Collector Current2800A
-
Total Power Dissipation7.65kW
-
Gate-Emitter Peak Voltage±20V
Description
IGBT MODULE
1400 AMP
1200 V
HALF-BRIDGE DUAL MODULE
4KV AC 1 MIN INSULATION
1400 AMP
1200 V
HALF-BRIDGE DUAL MODULE
4KV AC 1 MIN INSULATION
Information
Overview
Manuals
Technical notes
Product Applications
Safety Precautions
Features:
- 1200 V / 1400 A PrimePACK™ 3 Half-Bridge Configuration
- Trench/Fieldstop IGBT4 with Self-Limiting Short-Circuit Capability
- Extended Junction Temperature Operation
- 4 kV AC Insulation with High Creepage & Clearance Distances
The NGDR-07C NGDR-07 FF1400R12IP4 ABB IGBT module kit may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
ABB NGDR-07C NGDR-07 FF1400R12IP4 IGBT module kit Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Electrically, the FF1400R12IP4 is rated for 1200 V collector-emitter blocking voltage (VCES) and 1400 A continuous DC collector current (IC nom) at a case temperature of 100 °C, with a repetitive peak surge current of 2800 A for 1 ms pulses. This massive current capability accommodates high-torque motor starts, regenerative braking, and transient overload events inherent to heavy-industry drive cycles and traction applications. The integrated Emitter Controlled 4 (EC4) freewheeling diode is matched to the IGBT for soft recovery behavior, minimizing conduction losses while suppressing voltage overshoots during hard commutation.
- Motor Drives:AC inverter drives: regulates motor acceleration
- Wind Turbines:Megawatt converters: stabilizes grid energy
- High Power Converters:High thermal switching reliability for industrial setups
- 3-Level Applications:Multi-level inverters: lower THD, higher efficiency
- Auxiliary Inverters:Mass transit: powers AC/lighting onboard
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Discharge Time: Ensure the ABB drive's main breaker is locked out and tag-out procedures are strictly followed. Wait at least 15 to 20 minutes for the drive's large DC bus capacitors to fully discharge below a safe threshold (measure with a reliable voltmeter before touching any terminals).
ESD Protection: IGBT gates are highly sensitive to Electrostatic Discharge (ESD). Keep the module's conductive terminal sleeves in place until the control lines are ready to be attached.
FAQs
-
What is the NGDR-07C NGDR-07 FF1400R12IP4?
+The ABB NGDR-07C (and NGDR-07) is a protection trigger and driver board used in heavy-duty industrial drives (like the ABB ACS600). It mounts directly onto the FF1400R12IP4 IGBT power module to provide high-speed fault detection, equipment protection, and drive communication. -
