Technical specifications for HDZ-60-30C 1VCF349750S0909
-
Product ModelHDZ-60-30C 1VCF349750S0909
-
Spare ModelHDZ-60-30C
-
Product ParametersEnergy Storage Motor
-
Tariff Code8537101190
-
Country of originSWEDEN
-
Place of shipmentXiamen, China
-
Estimated Shipping Size9.5x8.5x20.5cm
-
ManufacturerABB
-
Weight2.3 kg
-
Rated Voltage (DC)110–132 V DC
-
Rated Voltage (AC)110–127 V AC
-
Motor DesignationM-MS-MAS
-
Certification LevelLevel 2
-
Speed140 r/min (rpm)
-
Operating Temperature-10°C to +60°C
-
Dielectric Strength2000 V AC, 50 Hz (1 minute)
Description
HDZ-60-30C
1VCF349750S0909
Energy Storage Motor
Certification Level 2
Motor M-MS-MAS
aux voltage 110-132Vdc, 110-127Vac
for HD4VD4/R ESH complete with motor limit switch
1VCF349750S0909
Energy Storage Motor
Certification Level 2
Motor M-MS-MAS
aux voltage 110-132Vdc, 110-127Vac
for HD4VD4/R ESH complete with motor limit switch
Information
Overview
Manuals
Technical notes
Product Applications
Electrical Connections
Features:
- Energy Storage Motor
- for HD4VD4/R ESH complete with motor limit switch
- Certification Level 2
The HDZ-60-30C 1VCF349750S0909 ABB Energy Storage Motor may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
ABB HDZ-60-30C 1VCF349750S0909 Energy Storage Motor Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The ABB HDZ-60-30C (1VCF349750S0909) is a geared motor operator used to automatically charge the closing springs of medium-voltage circuit breakers. Below are the technical notes for its installation, operation, and maintenance.The motor is designed to recharge the circuit breaker's operating mechanism springs immediately after every closing operation. It includes an internal limit switch that automatically cuts off the power supply once the springs reach the fully charged state.
- Circuit Breaker Spring Charging:Charges closing springs for ABB VD4, HD4, Vmax & EVD4 breakers
- Medium-Voltage Switchgear:Air or gas-insulated switchgear for power flow management
- Renewable Energy Integration:Wind/solar farm substations for grid stabilization via reliable switching
- Industrial Power Management:Peak shaving & load balancing in metals, mining & oil/gas plants
- Utilities & Substations:Multi-shot autoreclosing to clear transient faults & restore power
- Data Centers:Ensures critical protection breakers reset instantly after trip
- Marine & Ports:Onboard energy & propulsion control in harsh environments
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Wiring: Connect the motor leads to the internal terminal board (usually marked -MS).
For standard 110-130V AC/DC units, polarity is typically not critical for AC, but follow the +/- markings for DC.
Limit Switch: Ensure the motor is wired in series with the internal limit switch (-S3). This switch must open the circuit once the "Spring Charged" state is reached to prevent motor burnout.
Alignment: Position the motor unit (M) onto the support bracket located on the left side of the operating mechanism.
Coupling: Ensure the motor's output shaft gear meshes perfectly with the primary gear of the spring-charging shaft.
Fastening: Secure the motor using the mounting screws provided in the kit. Tighten firmly to prevent vibration-induced loosening, which can cause gear misalignment.
FAQs
-
What is the power rating of the HDZ-60-30C?+The motor supports a rated power of 30 kW.
-
What is the operating voltage for this motor?+The motor operates on a voltage range of 110-132 Vdc or 110-127 Vac.
-
What is the ABB 1VCF349750S0909?+It is a motor used for charging the operating mechanism springs of ABB medium-voltage circuit breakers (e.g., HD4, VD4/R ESH). It is often referred to as a "Motor Charging Kit" or "Spring Charging Motor".
-
Which circuit breakers are compatible with this motor?+It is designed to work with ABB circuit breakers such as the HD4 and VD4/R ESH types.
