PRODUCT DESCRIPTION

HIEE200130R0002 AFC094 AE02 ARCnet Control Panel

ABB HIEE200130R0002 AFC094 AE02 is an ARCnet control panel for compatible legacy drive-converter and excitation configurations. It provides the local operator interface for the connected control application.

The panel combines a 240 x 64-dot LCD with control keys and plant-function keys with LEDs. It supports contact inputs, changeover relay outputs, ARCnet communication and serial interfaces; displayed functions and key assignments depend on the connected controller and panel configuration.
ACTUAL APPLICATIONS

Application context for HIEE200130R0002 AFC094 AE02

HIEE200130R0002 AFC094 AE02 provides a local operator interface in compatible legacy converter and excitation configurations. Relevant fields include power generation, mining and metal production. Suitability depends on the connected controller, ARCnet configuration, firmware, panel wiring and documented assignments of the supplied hardware.
  • 01 · POWER GENERATION

    Electricity Generation and Energy Production

    Thermal Power Generation ProcessesIndustrial Combined Heat Production
  • 02 · MINING

    Mining Production and Mineral Processing

    Mineral Extraction and ProcessingOre Grinding and Beneficiation
  • 03 · METALLURGY

    Metal Production and Metallurgical Processing

    Primary Metal Production ProcessesIndustrial Metal Rolling Processes

Technical specifications for HIEE200130R0002 AFC094 AE02

  • Product Model
    HIEE200130R0002 AFC094 AE02
  • Spare Model
    AFC094AE02
  • Product Parameters
    ARCnet Control Panel
  • In stock
    9 units
  • Manufacturer
    ABB
  • LCD resolution
    240 x 64 dots
  • Text display format
    8 lines x 40 characters
  • Control keys
    10
  • Plant function keys
    16, with LEDs
  • Contact input channels
    4
  • Relay outputs
    3, changeover contacts
  • Auxiliary supply outputs
    3 x 24 V/0 V
  • Download interface
    RS-485
  • Printer interface
    RS-232
  • Panel fieldbus
    ARCnet
  • Analog value display
    8 values
  • Bargraph display
    4 values
  • Error message display
    8 messages
  • Contrast adjustment
    Potentiometer
  • Processor architecture
    16-bit, 80C196
View all additional

Alternative Names

HIEE200130R0002 AFC094 AE02 UNITROL Excitation Systems ARCnet Control Panel Excitation Systems 240 x 64 dots lcd resolution
SYSTEM & REPLACEMENT CHECK

Information needed before ordering

Three direct checks to secure your system integration and minimize ordering risks.

Information

System integration Replacement check Manuals & support
SYSTEM INTEGRATION

Integrate HIEE200130R0002 AFC094 AE02 arcnet control panel

Integrate HIEE200130R0002 AFC094 AE02 as the documented arcnet control panel in its compatible UNITROL Excitation Systems configuration. Match the complete product label, connection arrangement and installed hardware revision before making changes.
Compare lcd resolution (240 x 64 dots) and text display format (8 lines x 40 characters) with the engineering design. Check every applicable electrical and environmental limit in the supplied documentation; compatibility depends on the connected equipment and selected configuration.
