PRODUCT DESCRIPTION
PFEA112-65 Enclosed Web Tension Electronics
ABB PFEA112-65 is enclosed web tension electronics combining two load-cell inputs, analog signal outputs and PROFIBUS DP communication. Its wall-mounted IP65 version provides a local display and configuration keys for presenting the sum, difference or individual load-cell signals in the documented measurement arrangement.
The analog outputs provide voltage and current signals with selectable filtering, while PROFIBUS transfers measurement values and diagnostic status separately. Correct load-cell polarity, wrap gain and scaling are essential when commissioning or exchanging the unit. Retain the enclosure version, supply arrangement and configured communication settings.
The analog outputs provide voltage and current signals with selectable filtering, while PROFIBUS transfers measurement values and diagnostic status separately. Correct load-cell polarity, wrap gain and scaling are essential when commissioning or exchanging the unit. Retain the enclosure version, supply arrangement and configured communication settings.
BEFORE YOU BUY
Confirm the complete Enclosed Web Tension Electronics
ACTUAL APPLICATIONS
Relevant contexts for PFEA112-65
These categories reflect documented ABB portfolio contexts, not proof of suitability for every installation. Exact-model selection remains subject to the approved configuration.
-
01 · PULP & PAPER
Pulp and Paper Conversion and Printing
Graphic printing and commercial publishing servicesPaper converting and industrial paper supply -
02 · TEXTILES & NONWOVENS
Textile and Nonwoven Fabric Conversion
Technical textiles and nonwoven fabric servicesTextile finishing and specialist fabric conversion -
03 · PLASTICS & PACKAGING
Flexible Packaging and Polymer Film Conversion
Packaging printing and flexible packaging supplyPolymer films and industrial packaging services
Technical specifications for PFEA112-65
-
Product ModelPFEA112-65
-
Spare Model3BSE050091R65
-
Product ParametersEnclosed Web Tension Electronics
-
ManufacturerABB
-
Enclosed-unit AC supply85-264 V AC
-
Mains frequency47-63 Hz; technical-data table
-
Electronics power consumption8 W at 24 V DC
-
Enclosed-unit fuseSlow blow, 2 A, 250 V
-
Load-cell excitation0.5 A rms, 330 Hz
-
Load-cell input channels2
-
Input impedance10 kohm
-
Voltage output0-10 V; range -5 to +11 V; maximum load 5 mA
-
Current output4-20 mA; range 0-21 mA; maximum load 550 ohm
-
Analog output response15 ms step response; 35 Hz bandwidth, before extra filtering
-
Extra output filter settings30 / 75 / 250 / 750 / 1500 ms
-
Wrap gain adjustment0.5-20
-
Enclosure protectionIP65 / NEMA 4
-
Fieldbus interfacePROFIBUS DP slave; RS-485; maximum 12 Mbit/s
-
PROFIBUS measurement encoding2 values; each signed 16-bit, two-complement
View all additional
Alternative Names
PFEA 112-65
PFEA112 IP65 tension electronics
Enclosed PROFIBUS web tension electronics
SYSTEM & REPLACEMENT CHECK
Information needed before ordering
Three direct checks to secure your system integration and minimize ordering risks.
Information
System integration
Replacement check
Manuals & support
SYSTEM INTEGRATION
Integrate PFEA112-65 in the documented PFEA112 tension electronics arrangement
PFEA112-65 belongs to the enclosed PFEA112 web tension measurement arrangement. Two load-cell inputs supply the displayed sum, difference and individual measurements. Retain the exact enclosed-version identity and verify its incoming supply separately from the unsealed IP20 version.
Analog voltage and current outputs have separately selected scaling and filtering. PROFIBUS DP uses RS-485 and carries two signed measurement values with diagnostic status. Analog output scaling does not automatically determine the PROFIBUS measuring range or load division.
Check load-cell polarity, the documented connection diagram, wrap gain and bus configuration before commissioning. For valid PROFIBUS tension data, status bits zero through four must all be clear. An updating numerical value alone is not evidence that the measurement is healthy.
Features:
- Two load-cell inputs and analog outputs
- Independent PROFIBUS scaling and status
- Enclosed-version supply verification
PFEA112 uses PROFIBUS DP, not the PFEA122 Ethernet interfaces. Accept tension data only with the documented healthy status.
INTERCHANGEABILITY
Verify PFEA112-65 before replacement
Match PFEA112-65 and its complete supplied article reference before exchange. The shared manual also covers PFEA111 and PFEA122, but their fieldbus functions differ. A similar front panel or enclosure does not establish equal communications, wiring or setup requirements.
Record the load-cell data, polarity, wrap gain, zero reference, analog filters, output scaling and PROFIBUS settings. The manual distinguishes default from user-defined fieldbus scaling. Do not reset the unit merely to recover a familiar display without retaining the approved configuration.
Isolate and lock the incoming supply before work and observe ESD precautions. After the approved exchange, confirm the mechanical installation, restored settings, output signals and bus status. Investigate cabling and mechanical causes of an unstable zero before assuming that replacement electronics will resolve it.
Features:
- Recorded wrap gain and load-cell data
- Preserved output and fieldbus settings
- Verified polarity and diagnostic status
Isolate and lock the incoming supply before working on PFEA112-65. Preserve calibration and communication settings before exchange.
ABB PFEA112-65 Enclosed Web Tension Electronics Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Features:
- Exact-model data for PFEA112-65
- ABB manual 3BSE029380R0201 Rev E
- Series and ABB product directories
Documentation for PFEA112-65 must match the complete installed product identity, the documented PFEA112 tension electronics configuration and the supplied tension electronics before service.
Also searched as
Important notice
Manuals, software, firmware, cables, calibration data and accessories are included only when listed in the quotation. AMIKON is an independent supplier and is not affiliated with or authorised by the manufacturer.
This content has been produced using multiple sources. Takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
BUYER INFORMATION
Commercial terms without hidden steps
Your written quote confirms the product identity, price, availability, lead time, warranty and shipping terms before payment.
-
01
Shipping & delivery
-
DispatchEligible stock: same / next day
-
CarriersDHL, FedEx or UPS
-
Ship fromXiamen, China
-
Reference size13 × 21.6 × 10.2 cm
-
Reference weight2.05 kg
-
-
02
Payment & customs
-
PaymentBank transfer (T/T)
-
CurrenciesUSD · EUR · GBP · RMB
-
Credit cardsNot accepted
-
HS reference9031809090
-
OriginSweden
-
-
03
Warranty & returns
-
Warranty12 months from AMIKON
-
InspectionLabel, condition and packing checks
-
ReturnsPrior RMA authorisation required
-
CompatibilityConfirm before order
-
OEM warrantyDoes not apply
-
Your written quote confirms the product identity, price, availability, lead time, warranty and shipping terms before payment.
-
Part checked
Full suffix recorded -
Condition checked
Label and appearance -
Packing checked
Antistatic protection -
Tracking supplied
Established couriers -
Sandy Lin
Dedicated account manager · 15+ years
FREQUENTLY ASKED QUESTIONS
Questions buyers ask about PFEA112-65
Direct answers about identity, compatibility, stock, warranty, payment and shipping.
-
How does PFEA112 differ from PFEA111 when a fieldbus connection is required?
PFEA112 adds PROFIBUS DP to the analog measurement functionality described for PFEA111. Do not infer PROFINET or EtherNet/IP support from the shared manual title: those Ethernet interfaces belong to PFEA122. The -65 version also needs the enclosure and power arrangement checked separately. -
Which incoming supply should be checked if the enclosed unit has no display?
For the IP65 enclosure, check the incoming mains connection, its switch and the specified 85-264 V AC range using the applicable safety procedure. The technical-data table specifies 47-63 Hz. Do not apply the unsealed IP20 unit supply instructions to the enclosed unit without checking its actual wiring. -
Can updating PROFIBUS tension values be accepted while a status bit is active?
No. The input buffer carries two signed 16-bit measurement values plus diagnostic status. ABB states that tension data is valid only when status bits 0-4 are all zero; the numerical values can continue updating during an active fault without representing the actual tension. -
Which command can the PLC send through PFEA112 PROFIBUS DP?
The documented command is Zero set. In the output buffer, bit 0 requests zero setting on a transition from zero to one. This does not provide general remote access to every local setup function; retain the approved machine condition and commissioning procedure before initiating a zero adjustment. -
Will changing analog output scaling automatically change the PROFIBUS range?
No. ABB states that voltage and current output scaling does not affect the measurement values transferred through PROFIBUS. Check the separate measuring range and load division in the miscellaneous menu. Returning from user-defined to default PROFIBUS scaling requires the documented factory-default function, so preserve existing settings first. -
Why should cabling be investigated before replacing a unit with an unstable zero?
The fault-tracing guidance associates unstable zero with cabling, interference, screening and mechanical installation. Check the applicable load-cell connection diagram and separate signal and excitation paths as specified. A drifting indication alone does not prove an electronics failure or justify changing the recorded calibration. -
Does the -65 enclosure use the same mounting and synchronization rules as IP20?
No. The IP65 version is wall mounted and requires clearance to open its lid and work in front of it. ABB says synchronization is not required for this wall-mounted enclosed version; the adjacent-IP20 cabinet rule must not be applied indiscriminately. Isolate and lock the supply before working on the electronics. -
Before exchanging PFEA112-65, which recorded settings should maintenance retain?
Retain the complete supplied identity, load-cell nominal load and polarity, wrap gain, output filtering and scaling, plus the PROFIBUS address and measuring range. Verify the original GSD configuration and fault status after the approved exchange. A matching enclosure alone does not establish equivalent communication or measurement configuration.
