ALL MANUFACTURERS

Scalar Unit

6621125D1
Scalar Unit
Bailey 820 Line Controller

Circuit Board Extender for Test/Troubleshooting

405002000
Circuit Board Extender
for Test/Troubleshooting
Bailey 820 Line Controller

CLC03/CLC04 Display Faceplate

258580A1
AB00141 Kit CLC Faceplate
Bailey 820 Line Controller

SLC01/SLC02/SLC71/SLC72 Panel Gasket

1951781A1
SLC01/SLC02/SLC71/SLC72
Panel Gasket
Bailey 820 Line Controller

MCS KEYBOARD INTERFACE ASSEMBLY

1948520E1
MCS KEYBOARD INTERFACE ASSEMBLY
BAILEY INFI90

COILED CABLE TO HANDHELD TERMINAL

1948517D1
COILED CABLE TO HANDHELD TERMINAL
BAILEY INFI90

POWER SUPPLY BOARD

1948517D1
POWER SUPPLY
110/220VAC
50/60HZ
80WBAILEY INFI90

Termination Module

1.17.1109.00
Termination Module
BAILEY INFI90

1SAP150100R0271
CONTROL BOARD 4MB ETHERNET 24VDC

KJ4001X1-CC1 4-Wire Terminal Block

KJ4001X1CC1
DISCONTINUED BY MANUFACTURER
TX TERMINAL BLOCK
4 WIRE
32MA
30 VDC
250 VAC

12P0623X062
DISCONTINUED BY MANUFACTURER
FISHER-ROSEMOUNT EMERSON
I/O TERMINAL BLOCK
KJ4001X1-CA1

Controller Module

Input Voltage Range:24 V DC
Operational Range: 15–30 V DC
Typically 2–5 mA per channel
High-Level (ON): ≥18 V DC
Low-Level (OFF): ≤5 V DC
Response Time:≤ 1 ms

Analog Input Module

Profibus DP gateway module

Integration: Acts as a DP Slave or Master
Data Transfer Rate: Up to 12 Mbps
Max Nodes: 125 nodes per segment
Voltage: 24 V DC (±10%)
Isolation: 500 V AC
Connector: 9-pin D-sub or terminal block
Cable Length: Up to 1,200 meters

1C31166G02
DISCONTINUED BY MANUFACTURER
SERIAL LINK CONTROLLER
RS485
4 WIRE
EMOD+PMOD
R1120 CPU

51404109175
MODULE

51402755100
DISCONTINUED BY MANUFACTURER
K4LCN-4
PROCESSOR CARD

3AUA0000108650
PANEL BUS ADAPTER KIT
FIELDBUS KIT
FDPI-02
RJ-11 CONNECTOR
USE WITH CONTROL UNIT

5704F Fire Control Card

05704-A-0146
5704F Fire Control Card
4 Fire Zone Inputs
2 Switched DC Outputs
Single 3 Function Remote Input.
Up to 16 Configurable Relay Outputs
