OUTPUT MODULE

Brand:GE Fanuc
Series:Series 90-30
Range:-10 to +10 Volts
Part Number:IC693ALG390
Product Description:Analog Voltage Output
No of Channels:2
External Supply Voltage Range:18 to 30 VDC
External Supply Voltage Ripple:10%
Isolation:1500 Volts RMS field to the logic side
Update Rate:5 ms all channels
Resolution:2.5 mV
Accuracy:+/- 5 mV at 25 degrees Celsius

POWER SUPPLY

IC694PWR321
POWER SUPPLY
120/240 VAC
125 VDC STANDARD

Relay Output module

Series:Series 90-30
Manufacturer:GE Fanuc
Part Number:IC693MDL930
Product Description:Discrete output module
Product type:Digital I/O
Relay outputs:8
Product Description:Relay Output module
Output switching capacity:4 Amps
5 to 30 volts DC 5 to 250 volts AC, 50/60 Hz
No of Channels:Eight (8)
Minimum load:10 mA
Maximum inrush current:5 Amperes
Response time:15 ms

OUTPUT MODULE

IC694MDL741
OUTPUT MODULE
12/24 VDC
0.5 AMP
16 POINTS
NEGATIVE LOGIC

POWER SUPPLY

IC694PWR331
POWER SUPPLY
24 VDC
HIGH CAPACITY
FOR RX3I

OUTPUT MODULE

OUTPUT MODULE
12/24 VDC
POSITIVE LOGIC
32 POINTS
INTERFACE USES FUJITSU CONNECTOR

SERVO DRIVE

AKDP00306NBEC000
SERVO DRIVE
BRUSHLESS
3 AMP
1/3 PHASE
120/240 V
W/ ETHERCAT

DP/AS-i Link Advanced

SIMATIC NET,
DP/AS-INTERFACE LINK ADVANCED;
GATEWAY PROFIBUS
DP/AS-INTERFACE WITH MASTER PROFILE M3, M4 ACC.
TO EXTENDED AS-I SPEC.
V3.0 FOR INTEGRATION IN PROFIBUS DP;
DOUBLE MASTER WITH DISPLAY;
DEGREE OF PROTECTION IP20.

RACK 10 SLOT

TKFXX102
RACK 10SLOT COATED
5.1VDC - 15/6AMP
24VDC - 2.8/2.8AMP
3.3VDC - 4/4AMP

Power Supply Unit

18…32V DC (24V DC nom)
24 Volts DC
240 KB

Standard Operator Terminal

18…32V DC (24V DC nom)
Panelview 300
24 Volts DC
240 KB
PanelView 300 Standard Operator Terminals
Monochrome transflective LCD with LED backlight

Universal Variable Speed AC Drive

10 HP/7.5 KW 380V to
Inverter 380
480V ±10%
3PH 9.5A
Position control/Digital lock
Programmable logic functions
Two programmable thresholds
Mains dip ride through
Frequency slaving
Catch a spinning motor
Eight preset speeds/accelerations/decelerations

AC inverter

Control Techniques Unidrive
Classic 4kW
Inverter 380...480V AC
3PH 9.5A
Position control/Digital lock
Programmable logic functions
Two programmable thresholds
Mains dip ride through
Frequency slaving
Catch a spinning motor
Eight preset speeds/accelerations/decelerations
Injection and dynamic breaking

logic module

230RCE,logic module
Display PS/I/O: 115V/230V/relay
8 DI/4 DO, memory
230 V AC/DC
400 blocks, modular expandable

ESB Bus Node Units

100-120 V AC
24 V DC
200 VA, 120 W
24 V DC power supply

ESB Bus Node Units

100-120 V AC
24 V DC
200 VA, 120 W
24 V DC power supply

Duplexed Field Control Unit

For Vnet/IP and FIO, for 19-inch Rack Mountable
100–120 V AC power supply
220–240 V AC power supply
Basic type
LFS1500 Control Function for Field Control Station (for Vnet/IP and FIO)

ESB Bus Interface Slave Module

8, isolated
4 to 20 mA
24 mA
270 Ω (20 mA) to 350 Ω (4 mA)

Current Input Module

16, isolated
4 to 20 mA
270 Ω (20 mA) to 350 Ω (4 mA)
±16 µA
230 mA (5 V DC), 540 mA (24 V DC)

Power Supply Module

Power Supply Module
Two modules in case of
dual-redundant configuration.
Power supply to the I/O modules
and supply power to the transmitters
The power supply terminals use M4 screws

FASTBUS-Modules

FASTBUS master modules with 1 or 2 FO interfaces
FASTBUS slave modules with 1 or 2 FO interfaces
FASTBUS slave modules with integrated power supply
Up to 15 distributed substations
Distances to between 2 stations:
40 m for POF cables
150 m for HCS cables
180 m for special HCS cables
Status display (RUN/ERR) and display for fiber type
Minimal signal delay

Analog Input Module

2 or 4 analog inputs
Input current 0 to 20 mA
Input impedance 75 Ω
Resolution: 16 bit
Refresh cycle time 250 ms / channel
Galvanic isolation of channels
Galvanic isolation from system
Monitoring of internal voltages

Processor module

CPU module ME203/EN (33MHz)
8MB DRAM / 512kB SRAM
8MB file-flash
1x Eth100
1x RS232
1x RS232/422/485
Integrated power supply 17W
PCC slot

CPU module

CPU module 386EX (33MHz)
8MB DRAM / 512kB SRAM
8MB file-flash
1x CAN/CANopen
1x RS232
1x RS232/422/485
Integrated power supply 17W
PCC slot

Serial Interface Module

4 interfaces on one module
Any number of interfaces possible per controller
RS232 / RS422 / RS485 can be combined
High speed interfaces with up to 1.5 Mbaud
Auto-flow control for automatic handshake
Integrated terminating resistors (connect/disconnect)
Interfaces galvanically isolated
Galvanic isolation from system and between interfaces 500 V
