ALL MANUFACTURERS

Replacement electronics module

9-pos. D-SUB plug/socket
Incoming/Outgoing Remote Bus
ST local bus connector
500 kbps
I/O component
Smart Terminal ST
modular

Enhanced Logic Manager Module

Input Voltage:Typically 24 VDC
Power Consumption:Around 25 W
Operating Temperature Range:Typically -20°C to 60°C
Storage Temperature Range:-40°C to 85°C.
Relative Humidity:5% to 95% non-condensing.

Power Supply

POWER SUPPLY
230 VAC

Printed circuit board

Input Voltage: Typically 24 V DC
Operating Temperature Range:
Typically -30°C to +70°C (-22°F to 158°F)
Storage Temperature Range:
 -40°C to +85°C (-40°F to 185°F)

Signal conditioner

Voltage at min. GAP:−1.6 V
Voltage at max. GAP:−17.6 V
Dynamic range:16 V
Output impedance:500 Ω
Short-circuit current:45 mA
Voltage:−20 to −32 V*
Current:−13 mA ±1 mA (−25 mA max.)

Optical ESB Bus Repeater Module

Type: Optical ESB Bus Repeater Module
Bus System: ESB
Connector Type: SC or LC connectors
Operating Voltage: Typically 24 V DC
Operating Temperature Range: -10°C to 60°C (14°F to 140°F)
Power Consumption: Typically low, around 3-5W

Single Board Computer

Processor:Typically powered by a PowerPC 7448
Memory:512 MB to 2 GB DDR2 RAM
CompactFlash or Solid-State Drive (SSD)
Bus Speed: 40 MHz
Voltage: Typically  5V DC
Power Consumption: 20-50W
Operating Temperature: Typically 0°C to 70°C (-40°C to +85°C)
Storage Temperature: Typically -40°C to +85°C.
Humidity: 5% to 95% relative humidity

Point I/O module

Series:POINT I/O
Module Type:Serial Interface Module
Key Switch Position:2
Voltage Range:10-28.8 volts DC
Supply Voltage:24 volts DC nominal
Supply Current:15mA at 24 volts DC

MBUS+ PROG BRIDGE

Communication port protocol:Modbus Plus
Communication port support:RS232
Modbus Plus bridges and repeaters
characteristics:Programmable
Bridge
Mounting support:Panel Enclosure
Number of port:4
Rated supply voltage:115...220 V AC 24 V DC

SSI Module

Product Description:Serial Synchronous Interface (SSI) module
SSI Channels:1
Product Family:1734 POINT I/O
Supply Voltage:10-28.8 Volts DC
Part Number:1734-SSI
POINTBus Current:110 milliamps
Power Dissipation:0.94 Watts
No of SSI channels:One (1) SSI port
Supply current :110mA @ 24V dc
Operating Temperature:-20 to 55oC (-4 to 131oF)
Storage Temperature:-40 to 85°C (-40 to 185°F)

INVERTER POWER BOARD

INVERTER POWER BOARD
LOW VOLTAGE CONVERTER
INPUT: 0.7 AMP 320-1244 VDC
OUTPUT: 3 AMP 32 VDC 180 W
IP00

8mm Eddy Current Sensor

Linear Measurement Range 2 mm (80 mils)
Initial Air Gap 0.5 mm (20 mils)
Incremental Scale Factor (ISF)
ISO: 8 V/mm (203.2 mV/mil) ± 5%@
temperature range 0 to 45°C(+32 to +113°F)
Deviation from best fit straight line(DSL)
± 0.025 mm (± 1 mil)@
temperature range 0 to 45°C(+32 to +113°F)
Minimum Shaft Diameter 25 mm (0.79”)

TELEPERM XP FUM 210 MODULE

Part Number: 6DP1210-8AC
System: TELEPERM XP
Input Voltage: 24 V DC
Power Consumption: 15 W
Operating Temperature: -5°C to 45°C

Expansion Module Safety Relay

440REM4R2
EXPANSION MODULE
GUARDMASTER
GSR EM
MONITORING SAFETY RELAY
1 SINGLE WIRE SAFE INPUT
1 NC SOLID STATE AUX OUTPUT
24 VDC SUPPLY

SAFETY RELAY

440RS12R2
SAFETY RELAY
GUARDMASTER
SINGLE INPUT
1 DUAL CHANNEL UNIVERSAL INPUT
1 N.C. SOLID STATE AUXILIARY OUTPUTS
24 VDC 2.5 W SUPPLY
AC15 250V / 1.5 AMP
DC13 24V / 2 AMP OUTPUT
REPLACES 440R-J23106

POINT I/O Terminal Module

Part Number/Catalog No.:1734-CTM
Series:POINT I/O
Module Type:Terminal Module
Isolation Voltage:250 Volts Continuous
Field Power Supply:1-28.8 Volts DC or 12/240 Volts AC
Field Power Supply Current:4 amps/module

Compact 5000 analog input module

Overvoltage protection, max:± 30V DC
Overcurrent protection, max:±30 mA
Open circuit detection time:2 seconds
Module Keying:Electronic
Number of Inputs:8 Differential Inputs
Number of Outputs:N/A
Voltage Category:N/A
Input Voltage Range:+/- 10 Volts, 0-10 Volts, 0-5 Volts
Output Voltage Range:N/A
Power Dissipation:2.1 Voltage Mode and 2.4 Current Mode
Enclosure Type:None (Open Style)

Guard Locking Proximity Inputs Safety Relay

Product Type: Safety Relay
Model Number: 440R-GL2S2P
Series: Guardmaster
Input Voltage: 24V DC
Voltage Tolerance: -15% to +10%
Current Consumption: Approx. 200mA
Power Consumption: Typically 4.8W
Relay Output Type:
Safety Outputs: 2 NO
Auxiliary Outputs: 1 NC

SMC Flex Smart Motor Controller

Product Line:SMC-Flex
Part Number/Catalog No.:150-F43NBD
Bulletin Number:Solid-State Controller
Controller Ratings:480 Amps,
400 Horsepower at 460 Volts AC
Input Line Voltage:200 to 460 Volts AC
Control Voltage:120 / 240 VAC
Rated Voltage:500 to 575 Volts AC

Digital DC Sinking Output Module

Series:POINT I/O
Module Type:Digital DC Sinking Output Modules
Outputs:8
Output Voltage:24 Volts DC
Electronically Protected:Yes
POINTBus Current:75 milliamps
Output Current:3 amps/module
Power Dissipation:2 Watts

INTEGRATED MEASUREMENT INTERFACE BOX

7KE3188
INTEGRATED MEASUREMENT INTERFACE BOX
19.5 V
3 AMP
A5E01614931
40-Pin Male Header 0.1" 2.54mm Breadboard

DIGITAL OUTPUT MODULE

SIMATIC S5 440
DIGITAL OUTPUT MODULE
NON-FLOATING F
S5-90U/-95U/-100U
ET 100U, ET 200U
4 OUTPUTS 24V DC; 0.5A

DIGITAL INPUT MODULE

SIMATIC S5
Digital input 432
Isolated for S5-115U
16 inputs UC 48 to 60 V

INDUSTRIALETHERNET SWITCH

SCALANCE XB008G
UNMANAGED INDUSTRIALETHERNET SWITCH
FOR 10/100/1000MBIT/S
W. 8 X 10/100/1000MBIT/S
RJ45- ELECTRICALPORTS
FOR ESTABLISHING SMALL STAR- ANDLINE
TOPOGRAPHIES
LED-DIAGNOSTICS, IP20

DP/AS-Interface F-Link

DP/AS-Interface F-Link
gateway PROFIBUS DP/AS-i
for safety-oriented data transmission
from ASIsafe to PROFIBUS-DP-PROFIsafe
Master profile M3/M4 according to
AS-i specification V3.0
degree of protection IP20
spring-loaded terminals
