ALL MANUFACTURERS

POWER SUPPLY MODULE

PW44150
POWER SUPPLY MODULE
FOR V NET POWER
1.4AMP
100-120VAC
50/60HZ

Power Supply Module

Input Voltage:100–120 V AC
Input Frequency: 50/60 Hz
Maximum Power Consumption: 200 VA
Output Voltage: Typically 24 V DC
Operating Temperature: -10°C to +55°C (14°F to 131°F)
Storage Temperature: -25°C to +70°C (-13°F to 158°F).
Humidity: 5–95% RH (non-condensing)

COUPLER MODULE

Ethernet Ports: 2 ports
Data Transfer Rate: Up to 100 Mbps
Power Supply Voltage: 24 V DC (±10%)
Power Consumption: 8–12 W
Operating Temperature: -10°C to +55°C (14°F to 131°F)
Storage Temperature: -25°C to +70°C (-13°F to 158°F)
Humidity: 5–95% RH (non-condensing)

Vnet/IP COMMUNICATION MODULE

Power Supply:24 V DC
Power Consumption:≤5 W
Operating Temp.:-20°C to +70°C
Humidity:10–90% RH (non-condensing)

RADIAL VENTIALTOR

RADIAL VENTIALTOR
230VAC
4KW
RH35B2EK

RADIAL VENTILATOR

RADIAL VENTILATOR
220V 50/60HZ RH28M-2EK
3F HYBRID BEARING

MEMORY MODULE

Input Type: Digital (24 V DC)
Signal Voltage Range: 0-30 V DC
Input Logic: TTL/CMOS-compatible
Isolation: Optocoupler isolation (≤500 V)
Output Type: Transistor (24 V DC)
Switching Capacity: Up to 2 A per channe

CENTRAL PROCESSING UNIT

CENTRAL PROCESSING UNIT
SIMADYN D PM5
32 BIT
WITH BINARY / ABSOLUTE AND INCREMENT INPUTS
L AND C BUS

VARIABLE FEQUENCY DRIVE

VARIABLE FEQUENCY DRIVE
30HP 380-500VAC
50-60HZ
39AMPS
CHASSIS/PANEL MOUNT

Bus controller module

Series:Genius Bus I/O
Part Number:IC697BEM731F
Operating Voltage:5.0 Volt DC
Backplane Current:1.3 Amps
Bus Cable:Belden 9182 type cable
Module Width:Single Slot
Description:Genius I/O Bus Controller
Application:IC66 PLC System
Location:IC66 PLC Rack
Connectors:3PL and 1PL Ports
LED Indicators:3 LED Indicators
Average Weight:2.0 Pounds

CENTRAL PROCESSING UNIT

IC697CPU711
DISCONTINUED BY MANUFACTURER
CENTRAL PROCESSING UNIT
64 MHZ
32-BIT FLOATING
1 MBYTE MEMORY
12K DISCRETE I/O
SERIES 90-70

Discrete input module

Series:PACSystem RX3i
Manufacturer:GE Fanuc
Part Number:IC694MDL645A
Rated Voltage:24 Volts DC (positive or negative logic)
No of Channels:Sixteen (16)
Input points:16 (1 group)
Wiring configuration:Positive / Negative Logic
Input Current:7 Milliamperes
Input signal range:0-30 VDC
Nominal Input voltage:24 VDC
Input current:7 mA per channel
Off state voltage:0 - +5 VDC
On state current:3.2 mA
Off state current:1.1 mA
On response time, typical:7 ms
On response time, maximum:7 ms
Product Lifecycle Status:Active

Analog input module

Series:PACSystem RX3i
Manufacturer:GE Intelligent Platform (GE IP); Emerson Automation (Current)
Part Number:IC694ALG221A
No of Channels:Four (4) input channels
Product Type:Input Module
Nominal Input signal:0-20 mA; 4-20 mA
Module Type:Analog
Channel update rate:2 ms
Product Description:Analog input module
Digital Resolution:12 bit
LED:1 Green "Module OK" LED
Common Mode Voltage:200 volts
Input Filter Response:325 Hz
Product Lifecycle Status:Active
Hot-Swapping:Not Supported
Accuracy:0.1 % full scale
Input filter response:325 Hz
Input impedance:250 ohms
Linearity:< 1 Least Significant Bit

Discrete input module

Series:PACSystem RX3i
Manufacturer:GE Fanuc
Part Number:IC694MDL645D
Rated Voltage:24 Volts DC (positive or negative logic)
No of Channels:Sixteen (16)
Input points:16 (1 group)
Wiring configuration:Positive / Negative Logic
Input Current:7 Milliamperes
Input signal range:0-30 VDC
Input Voltage Range:0 to 30 Volts DC
Nominal Input voltage:24 VDC
On State Voltage:11.5 - 30 VDC
Off state voltage:0 - +5 VDC
On state current:3.2 mA
Off state current:1.1 mA
On response time, typical:7 ms
On response time, maximum:7 ms
Product Lifecycle Status:Active

PowerFlex 755 AC DRIVE

AC DRIVE
AIR COOLED
POWERFLEX 755
AC INPUT WITH PRECHARGE
IP20/IP00
OPEN TYPE
400 VAC / 540 VDC
7.5 KW / 10 HP
15.4 AMP
FILTERING
JUMPER INSTALLED
INTERNAL TRANSISTOR

INPUT MODULE

IC600BF832
DISCONTINUED BY MANUFACTURER
INPUT MODULE
SERIES SIX
115 VAC
32 POINT

PowerFlex 753 AC DRIVE

AC DRIVE
AIR COOLED
POWERFLEX 755
AC INPUT WITH PRECHARGE
IP20/IP00
OPEN TYPE
400 VAC / 540 VDC
4 KW / 5 HP
8.7 AMP
FILTERING
JUMPER INSTALLED
INTERNAL TRANSISTOR
NO HIM

PowerFlex 753 AC DRIVE

AC DRIVE
AIR COOLED
POWERFLEX 755
AC INPUT WITH PRECHARGE
IP20/IP00
OPEN TYPE
400 VAC / 540 VDC
4 KW / 5 HP
8.7 AMP
FILTERING
JUMPER INSTALLED
INTERNAL TRANSISTOR
NO HIM

PowerFlex 753 AC DRIVE

AC DRIVE
AIR COOLED
POWERFLEX 755
AC INPUT WITH PRECHARGE
IP20/IP00
OPEN TYPE
400 VAC / 540 VDC
2.2 KW / 3 HP
5 AMP
FILTERING
JUMPER INSTALLED
INTERNAL TRANSISTOR
NO HIM

PowerFlex 753 AC DRIVE

AC DRIVE
AIR COOLED
POWERFLEX 755
AC INPUT WITH PRECHARGE
IP20/IP00
OPEN TYPE
400 VAC / 540 VDC
1.5 KW / 2 HP
3.5 AMP
FILTERING
JUMPER INSTALLED
INTERNAL TRANSISTOR
NO HIM

PowerFlex 753 AC DRIVE

AC DRIVE
AIR COOLED
POWERFLEX 755
AC INPUT WITH PRECHARGE
IP20/IP00
OPEN TYPE
400 VAC / 540 VDC
0.75 KW / 1.00 HP
2.1 AMP
FILTERING
JUMPER INSTALLED
INTERNAL TRANSISTOR
NO HIM

PowerFlex 753 AC DRIVE

AC DRIVE
AIR COOLED
POWERFLEX 753
AC INPUT WITH PRECHARGE
IP20/IP00
OPEN TYPE
690 VAC / 932 VDC
250 KW / 335 HP
263 AMP
FILTERING
JUMPER INSTALLED
NO INTERNAL TRANSISTOR

PowerFlex 753 AC DRIVE

AC DRIVE
AIR COOLED
POWERFLEX 753
AC INPUT WITH PRECHARGE
IP20/IP00
OPEN TYPE
600 VAC / 810 VDC
185 KW / 250 HP
242 AMP
FILTERING
JUMPER INSTALLED
NO INTERNAL TRANSISTOR
NO HIM

PowerFlex 753 AC DRIVE

AC DRIVE
AIR COOLED
POWERFLEX 753
AC INPUT WITH PRECHARGE
IP20/IP00
OPEN TYPE
600 VAC / 810 VDC
185 KW / 250 HP
242 AMP
FILTERING
JUMPER REMOVED
NO INTERNAL TRANSISTOR

PowerFlex 753 AC DRIVE

AC DRIVE
AIR COOLED
POWERFLEX 753
AC INPUT WITH PRECHARGE
IP20/IP00
OPEN TYPE
600 VAC / 810 VDC
55 KW / 75 HP
77 AMP
FILTERING
JUMPER REMOVED
INTERNAL TRANSISTOR
