Allen-Bradley

ControlLogix 6 Pt Enhanced TC In Module

1756IT6I2
DISCONTINUED BY MANUFACTURER
DISCONTINUED SINCE 03/31/2017
INPUT MODULE
6 POINT
ANALOG
ENHANCED ISOLATED THERMOCOUPLE
20 PIN
INPUT RANGE: -12-78 MV / -12-30 MV
1.4 UV/BIT
RESOLUTION: 16 BIT

PLC-5/60L Processor

1785L60L
DISCONTINUED BY MANUFACTURER 2014
PROCESSOR MODULE
PLC 5/603.3 AMP
5 VDC

Flex 8 Point Analog Input Module

INPUT MODULE
8 SINGLE ENDED
ANALOG
FLEX I/O
60 MA
24 VOLT DC
FLEXBUS: 5 VDC / 15 MA

ControlLogix Enet/IP Comms Module

ETHERNET/IP COMMUNICATION BRIDGE MODULE
CONTROLLOGIX
10/100 MBPS
24 VDC
3 MA
128 LOGIX CONNECTIONS
Tariff Code: 8517620050
Country of Origin: United States

ControlLogix AC Power Supply

Nom Input Voltage:120/240VAC
Input Voltage Range:85-265VAC
Isolation Voltage:250 Volts Continuous
Max Inrush Current :30 Amperes
Current Capacity:
Input Voltage:120-240 Volts AC
Voltage Range:85-265 Volts AC
Input Power:100 Watts
Input Frequency:47-63 Hertz
Power Output:75 Watts at 60 Celsius
Chassis:Series A or B
Location:Chassis - Left Side

Flex 32 Point Digital Combination Module

1794IB16XOB16P
INPUT/OUTPUT MODULE
FLEX I/O
DISCRETE
DC
16 POINTS
24VDC
SINKING INPUT
SOURCING OUTPUT
ELECTRONICALLY PROTECTED
OPEN STYLE
DIN MOUNT
IP20

ControlLogix High Speed Counter Module

Inputs:3 per Counter
Module Type:High Speed Counter Module
Outputs:4-Point
Backplane Current (5Volts):300 milliamps
Backplane Current (24 Volts):3 milliamps
Power Dissipation (Max):5.6 Watts at 60 Celsius
Count Range:0-16, 214, 777
Removeable Terminal Blocks:1756-TBCH, 1756-TBS6H
Location:Chassis (Any Slot)

Kinetix 2000 4 Axis Slim Power Rail

2093PRS4
KINETIX 2000 POWER RAIL
FOUR AXIS
SERVO
Tariff Code: 8537109070
Country of Origin: Korea

Kinetix 2000 Axis Module

2093AM02
SERVO DRIVE
3KW
230 VAC
9.76 AMP
3PHASE
AXIS MODULE
Tariff Code: 8504909550
Country of Origin: Korea

Kinetix 2000 Shunt Module

2093ASP06
SHUNT MODULE
KINETIX 2000
BUS IN 325VDC
CONTROLIN .05AMP 240-425VDC
INTERNAL SHUNT 15OHM 50W
POWER RAIL MOUNTABLE
Tariff Code: 8504508000
Country of Origin: Korea

ControlLogix 36 Pin Screw Terminal Block

1756TBCH
TERMINAL BLOCK
CONTROLLOGIX
REMOVABLE
36 PIN CAGE CLAMP BLOCK
WITH STANDARD HOUSING
22 - 14 AWG

MicroLogix 1500 24 Point Controller

PLC BASE
MICROLOGIX 1500
120VAC POWER
12 RELAY OUTPUTS
(12) 24VDC INPUTS / RELAY OUTPUTS

SLC 8 Point Resistance Input Module

1746NR8
RTD/REISTANCE INPUT MODULE
8POINT
SLC-500
55MA 24VDC
100MA 5VDC

PVP6 700 Keypad LED Display Module

Resolution:640 x 480
Product Type:Operator Terminals
Supported Operator Input: Keypad
Display Type:Color active-matrix TFT

SLC 16 Point Digital Output Module

1746OW16
OUTPUT MODULE
SLC 500
16 POINT
RELAY
250 VAC
125 VDC
Tariff Code: 8538903000
Country of Origin: Malaysia, Japan

MicroLogix 1400 32 Point Controller

1766L32BXB
CONTROLLER
MICROLOGIX 1400
20 INPUTS
12 FAST 24 VDC INPUTS
8 NORMAL 24 VDC INPUTS
6 RELAY OUTPUTS
3 FAST 24 VDC OUTPUTS
3 NORMAL 24 VDC OUTPUTS
24 VDC POWER
Tariff Code: 8537109060
Country of Origin: Singapore

CompactLogix 2 Pt A/O C and V Module

Conversion Rate:2.5 ms
Power Supply Distance rating:8
Step response:2.9 ms
Current draw @ 5.1V:120 mA
Heat Dissipation:2. 36 W
Module Type:Analog Output Module
Input Type:Analog
Communication Cable:2 Point
Shipping Weight:2 lbs.
Shipping Dimensions:8 x 8 x 5 in.
Series:A and B

1791D0B8P
DISCONTINUED BY MANUFACTURER 05/31/2011
DNET 24 VDC COMPACTBLOCK I/O
8 OUT SOURCE
BASE
COMPACTBLOCK I/O DEVICENET OUTPUT BASE 24VDC 8-OUT

ControlLogix 16 Pt Digital Relay Module

1756OW16I
I/O MODULE
16 CHANNEL
2 AMP
125/240 VAC
10 MA PER POINT
Tariff Code: 8538903000
Country of Origin: United States

PowerFlex 700S DriveLogix Kit

20DDL2CKE1
DRIVE CONTROL UPGRADE KIT
CONTRIL MODULE
POWERFLEX 700S
WITH EXPANDED CASSETTE AND DRIVELOGIX5730
PHASE II

CMPLX 512KB Enet DI/O Controller

1769L23EQB1B
DISCONTINUED BY MANUFACTURER 09/30/2016
COMPACTLOGIX
ETHERNET/IP PROCESSOR
ONE RS-232 PORT
512 KBYTE MEM
16 DIGI INPUTS/24 VDC
16 DIGITAL OUTPUTS/24V DC
4 ANALOG INPUT
2 ANALOG OUTPUT
6 HIGH SPEED INPUT / 4 HIGH SPEED OUTPUT
24VDC
Tariff Code: 8537109060
Country of Origin: Malaysia

MicroLogix 1000 Controller Unit

1761L32AAA
DISCONTINUED BY MANUFACTURER
PLC
MICROLOGIX 1000
DIGITAL
32I/O
120/240VAC
(20) 120 VAC DIGITAL INPUTS
(10) TRIAC OUTPUTS
(2) RELAY OUTPUTS
Tariff Code: 8537109060
Country of Origin: United States

Digital Output Module

1794OB16PXT
OUTPUT MODULE
FLEX I/O
DISCRETE
DC
16 POINTS
24 VDC SOURCING OUTPUT
ELECTRONICALLY PROTECTED
EXTENDED TEMPERATURE -20 TO +70 DEG
OPEN STYLE
DIN MOUNT
IP20

Remote I/O Adapter Module

Product Family:SLC 500
Port Universal Remote I/O Adapter
Connectors:Wiring Arm 1771-WB
Backplane Current (at 5 Volts):1.0 Amps
Communication Port:Remote I/O (RIO)
Operating Temperature:32°F to 140°F (0°C to 60°C)
Storage Temperature:-40°F to +185°F (-40°C to +85°C)
Backplane Current:1 mA at 5V dc
Lower Connector Keying 16 to 18
