Technical specifications for 1756-TBNH
-
Product Model1756-TBNH
-
Spare Model1756TBNH 1756-TBNH/A
-
Product ParametersControlLogix 20 Pin Screw Terminal Block
-
Tariff Code8537101190
-
Country of originUSA
-
Place of shipmentXiamen,China
-
Estimated Shipping Size5.2x4.5x12.8cm
-
ManufacturerAllen-Bradley
-
Weight0.15 kg
-
Clamp TypeScrew-Clamp
-
Pins 20-PinConnection
-
Backplane Current (5Volts)1,200 milliamps
-
Backplane Current (24 Volts)2.5 milliamps
-
Power Dissipation (Max)6.19 Watts
-
Wire Size20 AWG
Description
1756TBNH
TERMINAL BLOCK
CONTROLLOGIX
REMOVABLE
20 POSITION
NEMA SCREW CLAMP BLOCK
22 - 14 AWG
TERMINAL BLOCK
CONTROLLOGIX
REMOVABLE
20 POSITION
NEMA SCREW CLAMP BLOCK
22 - 14 AWG
Revisions
Revision Part #
Also known as
Information
Overview
Manuals
Technical notes
Product Applications
Assembly and Installation
Features:
- ControlLogix
- 20-Pin Screw Terminal Block
- 20 AWG
The 1756-TBNH Allen-Bradley 20-Pin Screw Terminal Block may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
Allen-Bradley 1756-TBNH 20-Pin Screw Terminal Block Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The Allen-Bradley 1756-TBNH is a Removable Terminal Block (RTB) for 1756 I/O modules. It is an I/O module accessory and must be ordered separately. The 1756-TBNH provides flexibility in interconnecting 1756 I/O modules and industrial plant wiring. It plugs into the front of the I/O module. The 1756-TBNH removable terminal block is a 20-position NEMA screw-clamp.
Each I/O module has many applications ranging from high-speed digital processing to process control. In ControlLogix architecture, input and output status is shared among multiple controllers in the same or different chassis using producer-consumer technology. The 1756-TBNH RTB is intended for use in a clean and dry industrial environment with a 0-60 °C operating temperature and a 30g operating shock.
- Manufacturing & Assembly:Controls robots & conveyor lines
- Process Control:Monitors continuous process signals
- Energy Management:Manages power & electrical loads
- Automotive & Aerospace:Drives motion control systems
- Building Automation:Controls HVAC & lighting systems
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Housing Assembly: Align the side edges of the RTB with the grooves in the plastic housing and slide it in until it snaps into place.
Mounting the RTB:
Ensure the module is already securely installed in the chassis.
Unlock the locking tab at the top of the module.
Align the RTB guides with the module guides and press evenly until the latches snap.
Locking: Slide the locking tab down to secure the RTB to the module.
- What happens next
- Get the quote now Write Email to INFO@AMIKON.CNEmail confirmation You will get an email confirming that we have received your enquiry.Dedicated Account Manager One of our team will be in touch to confirm your part(s) specification and condition.Your quote You will receive a comprehensive quote tailored to your specific needs.Need Moore Help? Get fast and efficient help from our experienced sales or customer service teams.
- Delivery and payment
- Delivery
Logistic partners UPS, FedEx and DHL
International delivery available
Same day dispatch from warehouse inventory
Warranty
All parts new original are covered by Amikon 12 month warranty
Returns
No hassle returns policy
Dedicated customer support team
Payment options
We accept Bank transfers and the following methods of payment:
For more information, please visit our dedicated payments page.
- Why Choose Amikon Limited?
When it comes to industrial automation, reliability, speed, and trust matter. At Amikon Limited, we go beyond just supplying parts — we deliver confidence.
- ● Extensive Inventory Reach: Nearly 1 million automation parts at your fingertips, including legacy and obsolete models.
- ● 20+ Years of Expertise: Trusted by engineers, project managers and government companies worldwide for our professional service.
- ● Quality You Can Trust: Each unit is strictly inspected by the warehouse staff to ensure product quality
- ● Fast Global Shipping: We help you minimize downtime with express logistics worldwide.
- ● 1-Year Warranty Available: Peace of mind with every purchase backed by one year warranty guarantee.
Whether you're maintaining legacy systems or building future-ready projects, Amikon Limited is your dependable partner in precision and performance.
FAQs
-
What is the 1756-TBNH ？
+The Allen-Bradley 1756-TBNH is a 20-position, NEMA-style screw-clamp Removable Terminal Block (RTB) used with ControlLogix I/O modules. -
What types of wire does the 1756-TBNH accept?
+It accepts 0.33...2.1 mm² (22…14 AWG) solid or stranded copper wire, with a rated temperature of 90 °C (194 °F) or higher. -
What is the 1756-TBNH screw torque?
+The recommended torque is 0.8–1 N•m (7–9 lb•in) -
Which modules is 1756-TBNH used with?
+It is commonly used with various ControlLogix digital I/O modules, such as the 1756-IC16, 1756-IB16, and 1756-OB16I. -
Is 1756-TBNH compatible with safety modules?
+While it works with many standard modules, some security modules (such as 1756-OBV8S) require a specific security version, 1756-TBNHS.
