What is the 1786-RPFRL?

The Allen-Bradley 1786-RPFRL is a ControlNet Long-Distance Fiber Ring Repeater Module designed to extend ControlNet communication distances, create physical ring topologies for media redundancy, and convert signals between copper and fiber media.

What is the function of the 1786-RPFRL module?

It acts as a repeater to extend network length, provides immunity to electromagnetic interference (EMI), and supports a ring topology where a single media failure does not break the communication link.

What topology does it support?

It is designed for ring topologies, allowing for a redundant optical link. If a single media failure occurs between repeaters, the communication link will remain active.

What are the environmental limits?

The module operates optimally between 0 to 60°C (32 to 140°F) with a relative humidity of 5% to 95% (non-condensing).

Get Parts Quote

Name

Company *

Phone *

Email *

Address

City

State / Province / Region

Zipcode

Country

Quantity *

Part Number *

Manufacturer

Preferred Condition

Additional Information

Cancel

1786-RPFRL

Name: 1786-RPFRL
Brand: Allen-Bradley
SKU: 1786RPFRL

Call us: +86-18020776786

Delivery time
Please indicate your delivery time

Product image is representative; revision or series may vary. Contact us to request a specific version.

Product Information

Product Describe

RING REPEATER
CONTROLNET
FIBER
DUAL FIBER OPTIC CHANNEL
DIN RAIL MOUNTING
FOR 62.5/125 UM MULTI-MODE
USE TO 10000 M

Technical specifications for 1786-RPFRL

Product Model

1786-RPFRL
Spare Model

1786RPFRL
Product Parameters

RING REPEATER
Tariff Code

8537101190
Country of origin

USA
Place of shipment

Xiamen, China
Estimated Shipping Size

10.5x10.6x6.8cm
Manufacturer

Allen-Bradley
Weight

0.18 kg
Power consumption

2.8 W max
Communication rate

5 Mbps
Mounting orientation

Any mounting orientation
Relay contact connector voltage

30V DC, max
Relay contact connector current consumption

1 mA, min; 900 mA, max
Isolation voltage

50V (continuous)
Temperature, operating

0…60 °C (32…140 °F)
Temperature, surrounding air, max

60 °C (140 °F)
Temperature, nonoperating

-40…85 °C (-40…185 °F)

Factory New

These are new and current items that are procured from the manufacturer.
New No Package

These parts are new. They have not been used, but their original packaging is no longer available.
New In Opened Package

These parts are new. They have not been used, but their original packaging has been opened or the packaging is significantly aged.
New In Sealed Package

Parts are new. They have not been used and still have their original package seal intact.
New in Original Package

These parts are new. The packages were not originally sealed by their original manufacturer.

Warranty Period & Disclaimer

Amikon is not an authorized distributor unless otherwise specified, representative, or affiliate of the manufacturer of this product. All trademarks and documents are the property of their respective owners and are provided for identification and informational.

FAQs

What is the 1786-RPFRL?+

The Allen-Bradley 1786-RPFRL is a ControlNet Long-Distance Fiber Ring Repeater Module designed to extend ControlNet communication distances, create physical ring topologies for media redundancy, and convert signals between copper and fiber media.
What is the function of the 1786-RPFRL module?+

It acts as a repeater to extend network length, provides immunity to electromagnetic interference (EMI), and supports a ring topology where a single media failure does not break the communication link.
What topology does it support?+

It is designed for ring topologies, allowing for a redundant optical link. If a single media failure occurs between repeaters, the communication link will remain active.
What are the environmental limits?+

The module operates optimally between 0 to 60°C (32 to 140°F) with a relative humidity of 5% to 95% (non-condensing).
