Technical specifications for 1756-IB32
-
Product Model1756-IB32
-
Spare Model1756IB32
-
Product ParametersControlLogix 32 Pt 12/24V DC D/I Module
-
Tariff Code8537101190
-
Country of originUSA
-
Place of shipmentXiamen, China
-
Estimated Shipping Size23.3x18.2x5.3cm
-
ManufacturerAllen-Bradley
-
Weight0.3 kg
-
Inputs32 (16 points/group)
-
Voltage category12/24V DC sink
-
Operating voltage range10…31.2V D
-
Current draw @ 5.1V120 mA
-
Current draw @ 24V2 mA
-
Total backplane power0.66 W
-
Power dissipation, max6.2 W @ 60 °C (140 °F)
-
Thermal dissipation21.1 BTU/hr @ 60 °C (140 °F)
-
Off-state voltage, max5V
-
Off-state current, max2.27 mA
-
On-state current, min4.8 mA @ 10V DC
-
On-state current, max5.5 mA @ 31.2V DC
Description
INPUT MODULE
32 POINT
DIGITAL
10-31 VDC
36 PIN
5.5 MA
CONTROLLOGIX
32 POINT
DIGITAL
10-31 VDC
36 PIN
5.5 MA
CONTROLLOGIX
Revisions
Revision Part #
Also known as
Information
Overview
Manuals
Technical notes
Product Applications
Key Installation Steps
Features:
- High-Density 32-Point Capacity
- Wide 24V DC Operating Range
- Advanced Software Debouncing
- Change-of-State (COS) Detection
The 1756-IB32 input module from Allen Bradley, part of the ControlLogix family, offers robust functionality for various control applications. It supports 32 individual inputs with a configuration that allows for 16 points per group. Operating voltage spans from 10 volts to 31.2 volts DC, catering to a variety of signaling needs. This module has a current draw of 120 milliamps when receiving 5.1 volts and a mere 2 milliamps with 24 volts present.
The 1756-IB32 Allen-Bradley Input Module may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
Allen-Bradley 1756-IB32 Input Module Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Power consumption is efficient, with total backplane power measured at 0.66 watts. The maximum power dissipation reaches 6.2 watts when the operating temperature is at 60 degrees Celsius, alongside a thermal dissipation rate of 21.1 BTU/hr at this temperature. The input module features enhanced performance with a maximum off-state voltage capped at 5 volts and an upper limit on off-state current of 2.27 milliamps.
In terms of operational thresholds, the on-state current must be at least 4.8 milliamps, achievable at 10 volts DC, while it may peak at 5.5 milliamps when 31.2 volts DC is supplied. The device can withstand a maximum inrush current of 250 milliamps without issue, allowing for flexible operation in dynamic environments. The input impedance is noted at 5.67 kΩ when running at maximum voltage. This input module is housed in an open-style enclosure, providing ease of access and installation for integration into larger control systems.
- Conveyor & Material Handling Systems:High-vibration lines: program retention & data logging
- CNC & Metalworking Equipment:Motor control for CNC & drill presses
- Fluid & Flow Control Systems:Motor pumps, butterfly valves & ignition transformers
- Automated Production Lines:Supports rapid controller reboots after power loss
- Welding Machinery:Used in arc welders & industrial electrical equipment
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Terminal Block (RTB) Wiring: Wire the 36-pin RTB (1756-TBCH recommended) before mounting. The 1756-IB32 uses two groups, each with its own power supply.
Keying: Key the RTB to prevent incorrect module insertion (typically slot 1-3, 3-5).
Module Insertion: With the chassis powered, align the module with the top and bottom chassis guides and slide it in until it snaps.
Secure RTB: Seat the RTB firmly onto the module until the latches lock it in place.
Configuration: 1756-IB32 modules do not use DIP switches. Configuration is done via Studio 5000/RSLogix 5000, which automatically writes settings to the module.
FAQs
-
What is the voltage range?
+The module has a nominal voltage of 24V DC and an operating range of 10–31.2V DC. -
Can it be used in remote I/O?
+Yes, it can be placed in a local chassis with a processor or in a remote chassis via a communication adapter. -
What is the difference between the 1756-IB32 and 1756-IV32?
+The 1756-IB32 is a sinking input module (requires sourcing sensors/devices). The 1756-IV32 is a sourcing input module (requires sinking sensors/devices) -
How are faults diagnosed?
+The 1756-IB32 has a module-fault word containing 32 bits, which corresponds to the status of each of the 32 input channels. This allows for monitoring communications faults and individual channel diagnostics.
