Technical specifications for 1766-L32BWA
-
Product Model1766-L32BWA
-
Spare Model1766L32BWA
-
Product ParametersMICROLOGIX 1400 CONTROLLER
-
Tariff Code8537101190
-
Country of originUSA
-
Place of shipmentXiamen, China
-
Estimated Shipping Size18x11x8.9cm
-
ManufacturerAllen-Bradley
-
Weight0.94 kg
-
Input Power100/240V AC
-
User Power24V DC
-
Embedded Discrete I/O12 Fast 24V DC Inputs 8 Normal 24V DC
-
Inputs12 Relay Outputs
-
Number of I/O24 inputs
-
Power supply voltage100…240V AC
-
Power consumption120 VA
-
24V DC sensor power24V DC @ 250 mA400 µF max
-
Digital24V DCsink/source
-
On-state voltagerange4.5…24V DC, Class 2
Description
1766L32BWA
CONTROLLER
MICROLOGIX 1400
100/240 VAC INPUT POWER
12 (FAST) 24 VOLT DC INPUTS
8 (NORMAL) 24 VOLT DC INPUTS
12 RELAY OUTPUTS
24 VDC USER POWER
CONTROLLER
MICROLOGIX 1400
100/240 VAC INPUT POWER
12 (FAST) 24 VOLT DC INPUTS
8 (NORMAL) 24 VOLT DC INPUTS
12 RELAY OUTPUTS
24 VDC USER POWER
Revisions
Revision Part #
Also known as
Information
Overview
Manuals
Technical notes
Product Applications
Quick Operations Guide
Features:
- MicroLogix 1400 Controller
- (12) Digital Fast 24V DC, (8) Digital Normal 24V DC
- 1 RS232 / RS485; 1 Ethernet; 1 RS232
- Panel Mounting / DIN Rail
This controller has embedded Twelve (12) Fast 24V DC Inputs, Eight (8) standard 24VDC inputs and Twelve (12) Relay outputs. The High-speed inputs support fast switching devices with rated frequency of 100 kHz. The standard 24VDC Inputs is used for general purpose application while the Relay Outputs may be operated with different voltage categories, for energizing electrical loads with different nominal voltage actuations.
The 1766-L32BWA Allen-Bradley MicroLogix 1400 Controller may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
Allen-Bradley 1766-L32BWA MicroLogix 1400 Controller Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The Allen-Bradley 1766-L32BWA is a part of the MicroLogix 1400 Programmable Logic Controller series. It combines the features of previous MicroLogix 1100 controllers, such as EtherNet/IP, online editing capabilities, and an LCD with enhanced features. It also features a backlight on the LCD for setting network configuration, viewing the controller and I/O status, monitoring, and manipulation. The 1766-L32BWA controller requires 120 to 240 VAC input power and has battery-backed RAM. It supports 32 digital I/O points that consist of Twelve (12) digital fast 24 Volts DC inputs, Eight (8) digital normal 24 Volt DC inputs, and Twelve (12) relay outputs. It can be expanded with up to Seven (7) 1762 expansion I/O modules. It has dimensions of 3.5 x 7.08 x 3.43 inches and a weight of 2 pounds. For communication, the 1766-L32BWA has an isolated RS-232/485 port, an Ethernet port, and a non-isolated RS-232 port. It also has an embedded real-time clock to provide a reference for applications that need time-based control. For installation, it has Panel or DIN-Rail mounting options with an open enclosure. It is suitable for use in a clean, dry industrial environment with circuits not exceeding Over Voltage Category II. The 1766-L32BWA controller has various enhanced features that its predecessors lack. The Ethernet port provides DNP3 protocol support as well as a web server and email capabilities. It has 2 Serial ports with DH485/DF1/Modbus RTU/DNP3/ASCII protocol support. It has up to 6 embedded 100 kHz high-speed counters (only for DC controllers).
- Industrial Automation:Discrete & process control for small to mid-size machines
- Material Handling:Conveyors, sorting systems, and assembly lines
- Packaging & Food/Beverage:Packaging machinery and food processing control
- HVAC & Building Automation:Timed lighting, pump control, and environmental management
- Water/Wastewater Treatment:SCADA, remote data logging, and utility monitoring
- OEM Equipment:Commercial machinery like industrial washers/dryers and vending machines
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Safety Practices: Always read precautions regarding Explosion Hazards and Electrostatic Discharge (ESD) before handling internal components or wiring.
Mounting: The controller must be mounted horizontally to allow for proper thermal cooling; vertical mounting is not supported.
Wiring: For the L32BWA, ensure you are using the correct 120/240V AC power source and refer to the specific terminal block diagrams for its 20 digital inputs and 12 relay outputs.
LCD Interface: Use the built-in keypad to monitor I/O status, change IP addresses, or view fault codes directly on the unit.
FAQs
-
What is the 1766-L32BWA?
+The Allen-Bradley 1766-L32BWA is a MicroLogix 1400 programmable logic controller (PLC) widely used in industrial automation for tasks like conveyor control, packaging, and water treatment management. It is designed with 120/240V AC power input and provides 20 digital inputs and 12 relay outputs. -
What are the main I/O capabilities?
+It has 20 digital inputs (12 fast 24V DC inputs and 8 normal 24V DC inputs) and 12 relay outputs. -
Does it have analog I/O?
+The base 1766-L32BWA model does not have built-in analog I/O, but it supports up to seven 1762 expansion I/O modules. -
Is this product brand new?
+Yes, AB 1766-L32BWA is brand new, original, unused, and factory sealed
